Active + Passive PA Speaker System Kit
Dual Loudspeaker Sound Package, 10'' Subwoofers,
Bluetooth Wireless Streaming, Includes (2) Speaker Stands,
Wired Microphone, Remote Control, 1000 Watt
PPHP1049KT
www.PyleUSA.com
SYSTEM FEATURES:
• Dual 10-inch High-Powered Loudspeaker PA Systems
• Includes (1) Active Speaker, (1) Passive Speaker + (2) Stands
• Rugged, Durable & Reliable Sound
• Bluetooth Wireless Music Streaming Ability
• High-Frequency 1.0'' Tweeters
• Compression Driver with Titanium Diaphragm
• 2-Way Full Range Audio Projection
• Built-in Digital Audio Amplier
• XLR Microphone Input
• 1/4’’ SpeakOn (8 Ohm) Input
• 1/4’’ SpeakOn (8 Ohm) Speaker Output
• Aux (3.5mm) Input Jack
• Connect & Stream Audio from External Devices
• USB Flash Drive & SD Memory Card Readers
• Digital LCD Display
• Rear Panel Rotary Dial & Button Control Center
• Master Volume, Mic Volume, Treble, Bass Adjustable
• Integrated Carry Handles
• 35mm Speaker Stand Mount Compatible
• Heavy Duty Engineered ABS Housing
WHAT'S IN THE BOX:
• (1) 10'' Active PA Speaker
• (1) 10'' Passive PA Speaker
• (2) Speaker Stands
• Wired Microphone
• Remote Control
• Power Cable
BLUETOOTH WIRELESS STREAMING:
• Instantly Stream Music from Your Bluetooth Devices
• Works with All Your Favorite Bluetooth Devices
• (iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• Bluetooth Version: 4.0
• Bluetooth Wireless Range: 100'+ Feet
• Bluetooth Network Name: 'Pyle’
1
SPEAKER STANDS:
• Effectively Elevates Speakers for Optimum Sound Performance
• Universal Speaker Compatibility (35mm Insert)
• Easy Setup and Quick Adjustment Control
• Reinforced Steel Support Construction
• Speaker Support Arm Extension
• Rugged and Reliable
• Safety Lock-in Pin
• Foldable for Quick Storage and Transport
• Rubber Capped Tripod Feet Base
• Perfect for On-Stage or Studio Use
• For Professional or Beginner Applications
• Speaker Height Adjustable: 59.1'' to 82.7''
• MAX. Load Capacity: 100 lbs. (50 kgs.) -Each
TECHNICAL SPECS:
• MAX Power Output: 1000 Watt
• Amplier: Class D
• Impedance: 8 Ohm
• T.H.D.: <1%
• Magnet: 20 oz.
• Sensitivity: 92dB (+/-2dB)
• Mic Input Level: <15mV
• Line Input/Output Level: >250mV
• Frequency Response: 65-18kHz
• Digital Audio File Compatibility: MP3, WMA
• Maximum SD/USB Flash Memory Support: 32GB
• Power: 100/240V
• Single Speaker Weight: 18.08 lbs.
• Weight: 46.42 lbs.
www.PyleUSA.com
2
www.PyleUSA.com
PPHP1049KT
1. LCD screen
2. Mp3 control
MODE: USB/SD/BT/FM convertor
: Play / Pause
SCAN: Long press to auto search
under FM radio
FOL: Long press 5 seconds to enter
the folder option function mode
(press the previous/next songs
button to choose the folder)
: Repeat one / Repeat all / Random
: PRE/NEXT under FM mode Long
hold to search lower/ higher station
manually
: Short press to tune to saved station
: Previous Song
Long press for fast rewind
: Next Song
Long press for fast forward
3. USB input
4. SD card input
5. Remote control
6. MIC level control
7. MP3 level control
8. Basscontrol
9. Treble control
10. XLR microphone line input
11. Line input
12. AUX input
13. Master volume
14. Speaker out 8Ohm
15. Main power switch
16. Fused IEC mains inlet
IR
MP 3 CONTR OL DIGITAL DI SPLAY
US B
SD c ard
MI C
LI NE IN
PO WER SWITC H
AC :100-24 0V 5 0/60Hz
8Ω
SP EA KE R OUT
MI C VO L MP 3 VO L
TR EB LE
AU X
MA STER VOL
BA SS
-1 2 +1 2 -1 2 +1 2
3
4
1
2
9
13
14
6
10
16
15
11
12
8
7
5
MI N MA X
MI N MA X
MI N MA X
3
1
2
3
6
5
9
4
8
7
11
10
1. MODE: Switch between USB/SD/BT/FM/LINE IN
2. FOL- : Folder backward
3. FOL+: Folder forward
4. : When USB/SD: Previous Song , Long press for fast rewind
When FM: Swich to backward
5. : When USB/SD: Next Song , Long press for fast forward
when FM: Swich to next channel
6. : Play / Pause
When FM: Auto search
7. VOL+: Increase volume
8. VOL-: Decrease volume
9. EQ: NORMAL, BASS, POP, ROCK, CLASS, JAZZ.
10. 0-9: Choose the music by numbers
11. --/---: Choosing the music by numbers
