USER MANUAL
WHE6874, WHE7074
REFRIGERATION
0000000000 0
REGISTER YOUR FRIDGE
WITH YOUR SMARTPHONE
1
Locate the labe
l
on the inside of
your fridge
Easy register with your smartphone
00000000000
2
Photograph the
camera icon, including
the 4 dots ( )
3
(Australia only
)
© 2017 Electrolux Home Products Pty Ltd. EST_PhotoRegister_Fridge_70x70_Dec17
Text image to 0488 446 622
1. Photograph the camera icon,
including the 4 dots( ).
2. Then text it to 0488 446 622
(Australia only)
CONGRATULATIONS
Dear Customer,
Congratulations and thank you for choosing our
refrigerator. We are sure you will find your new
refrigerator a pleasure to use. Before you use the
relevant sections of this manual, which provides a
description of your refrigerator and its functions.
To avoid the risks that are always present when you
use an electric appliance, it is important that the
refrigerator is installed correctly and that you read
the safety instructions carefully to avoid misuse
and hazards.
We recommend that you keep this instruction
booklet for future reference and pass it on to any
future owners.
After unpacking the refrigerator, please check it is
not damaged. If in doubt, do not use the refrigerator
but contact your local customer care Centre.
The symbols you will see in this booklet have these
meanings:
WARNING
This symbol indicates information concerning your
personal safety.
CAUTION
This symbol indicates information on how to avoid
damaging the refrigerator
IMPORTANT
This symbol indicates tips and information about
use of the refrigerator
ENVIRONMENT
This symbol indicates tips and information about
economical and ecological use of the refrigerator
Conditions of use
This refrigerator is designed and intended to be
used in normal domestic applications only.
Record model and serial number here:
Model number: .......................................................................
Serial number: .........................................................................
CONTENTS
Important safety instructions ………………….…
3
Features at a Glance ……………………….…….…….
4
Installation ………………………………………..…………...
5
Installing Door Handles ……………………………….
7
Connecting Water Supply ………………………….
8
Controls ………………………………………………….……...
10
Automatic Ice & Water Dispenser ….………...
14
Storage Features ………………………………………....
16
Changing the Filter ……………………………………… 20
Food Storage Guide ………………..…………………..
22
Care and Cleaning ……………………….……………….
23
Troubleshooting …………………………..……………... 24
Warranty ……………………………………………………….. 27
2
IMPORTANT SAFETY INSTRUCTIONS
WARNING
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their
safety. Children should be supervised to ensure
that they do not play with the appliance.
• It is essential the power point is properly earthed to
ground. Consult a qualified electrician if you are
unsure.
• Do not use electrical appliances inside the food
storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
• Unplug the refrigerator before cleaning or moving
it to avoid electric shock.
• Never unplug the refrigerator by pulling the
electrical cord as this may damage it. Grip the
plug firmly and pull straight out.
• If the power cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a
hazard.
• Don’t use a steam cleaner. If live components
come into contact with condensing steam, they
may short-circuit or cause an electric shock.
• Do not store explosive substances such as
aerosol cans with a flammable propellant in this
appliance. If pressurised aerosol containers bear the
word ‘flammable’ and/or a small flame
symbol, do not store them inside any refrigerator
or freezer. If you do so you may cause an
explosion.
• Do not damage the refrigerant circuit. This
appliance contains insulation formed with
flammable blowing gases. Avoid safety hazards by
carefully disposing of this appliance.
• If you wish to discard this refrigerator, please
contact your local authorities and ask for the
correct method of disposal.
• When you dispose of your old refrigerators and
freezers, remove any doors. Children can
suffocate if they get trapped inside.
• The plug must be accessible when the appliance
is in position.
• Never try to repair the refrigerator yourself,
only use a qualified or authorized service
person for repairs.
• Never put the appliance in a location that is too
cold or is unprotected, for example in a garage
or on a veranda. The ambient should be above
10°C.
WARNING
R600a refrigerant warning
Th
i
s a
p
pliance contains flammable R600a refrigerant.
Avoid safety hazards by carefully installing, handling,
servicing and disposing of this appliance.
• Ensure that the tubing of the refrigerant circuit
is not damaged during transportation and
installation.
• Leaking refrigerant may cause eye injuries or
ignite.
• The room for installing appliance must be at
least 1m3
per 8g of refrigerant. The amount of
refrigerant in the appliance can be found on the
rating plate inside the appliance.
• If you are unsure of the refrigerant check the
rating plate inside the refrigerator
compartment.
• It is hazardous for anyone other than an
Authorised Service Person to service this
appliance. In Queensland Australia the
Authorisation Service Person MUST hold a Gas
Work Authorisation for hydrocarbon
refrigerants to carry out servicing or repairs
which involve the removal of covers.
• Keep ventilation openings in the appliance
enclosure or in the built-in structure, clear
of
obstruction.
• Do
not
use
mechanical devices or other means
to
ac
celerate
the defrosting process, other than
those recommended by the manufacturer.
3
Note: You must read these warnings carefully
before installing or using the refrigerator. If you
need assistance, contact your customer care
centre. The manufacturer will not accept liability,
should these instructions or any other safety
instructions incorporated in this book be ignored.
FEATURES AT A GLANCE
1
12
Left Snack Zone compartment
23
2
13
24
3
14
25
4
15
26
5
16
27
6
17
28
7
18
29
8
19
30
9
20
31
10
21
32
11
Ice Maker
Air distributor - Multiflow
Deodoriser
Water filter
Flip up glass shelf
Slide/fold glass shelf
Left Spillsafe™ glass shelf
Right Spillsafe™ glass shelf
Crisper shelf cover
FreshSeal™ crisper
FreshSeal™ crisper
22
Right Snack Zone Compartment
Egg Tray
Upper fixed door bin
Left fixed door bin
FlexStor
TM
dairy bin
FlexStor
TM
1/3 bin
FlexStor
TM
2/3 bin
Expandable bin
Bottle storage bin
Adjustable left hinge
33
Adjustable right hinge
FlexSpace™ drawer
FlexSpace™ drawer divider
Upper freezer drawer
Lower freezer basket
Lower freezer basket divider
Refrigerator Door Handle
FlexSpace™ drawer handle
Refrigerator/Freezer control panel
Water and Ice Dispenser Trigger
FlexSpace
TM
drawer control panel
4
INSTALLING YOUR NEW APPLIANCE
Unpacking
ENVIRONMENT
Most of the packing materials are recyclable. Please
dispose of those materials through your local
recycling depot or by placing them in appropriate
collection containers.
Important – check for any damages or marks. If you
find the refrigerator is damaged or marked, you
must report it within 7 days should you wish to
claim for damage/marks under the manufacturers
warranty. This does not affect your statutory rights.
Clean your refrigerator thoroughly following the
instructions in the “Cleaning” section and wipe off
any dust that has accumulated during shipping.
Locating the refrigerator
CAUTION
Automatic aerosol systems (such as insect control)
should not be located adjacent to the product as
the spray may cause long term damage to the
external plastics of the appliance.
Do not put the refrigerator in a location that is too
cold or is unprotected, for example in a garage or
on a veranda. The ambient temperature should be
above 10°C.
Put the refrigerator in a dry place avoiding areas of
high moisture or humidity.
Ensure the
refrigerator is located on an even
surface.
Adequate ventilation around your refrigerator
The diagram below shows the recommended
airspace to allow for ventilation of your refrigerator.
When positioned in a corner area, spacing of
right side at least 260 mm and left side at
least 355 mm on the hinge side will allow the
doors to open enough to enable the removal of
bins and shelves.
5
Front face of bench
aligned to front corner
edge of cabinet.
913
Note: If your refrigerator is placed with
the door hinge side against a wall, you
may have to allow additional space so
the door can be opened wider.
Installing your refrigerator
Allow the following clearances for ease of
installation, proper air circulation, and plumbing
and electrical connections:
Note: Doors are designed to sit proud of
cabinetry (not flush). The clearances shown
above are the recommended minimum
clearances.
749
1782
25 mm
10 mm
10 mm
35 mm
RECOMMENDED
CLEARANCES
355 mm
260 mm
25
mm
Door opening
Your refrigerator should be positioned to allow
easy access to a counter when removing food. For
best use of refrigerator drawers and freezer
baskets, the refrigerator should be in a position
where both can be fully opened.
CAUTION
LED lighting
Your appliance is fitted with long life LED lighting.
In the unlikely event the LED lights should fail, then
the LED lights should be serviced by the service
agent, to avoid a safety hazard. Refer to the
warranty page for contact details.
Cabinet Leveling & Refrigerator Door Alignment
(if necessary)
Guidelines for final positioning of your refrigerator:
• All four corners of the cabinet must rest firmly
on the floor.
• The front should be slightly elevated to ensure
that doors close and seal properly.
• Doors should align with each other and be level.
Most of these conditions can be met by raising or
lowering the adjustable front rollers.
To level the cabinet using the front rollers:
1. Slightly open freezer drawer if the toe grill is
installed. Lift the toe grille and gently pull
forward.
2. Make initial cabinet adjustments by using the
front roller height adjusting screws. Use a 3/8
inch socket wrench to turn the adjustment
screws (1 per side).
To raise: turn adjustment screw clockwise.
To lower: turn adjustment screw counter
clockwise.
3. Ensure both doors are bind-free with their seals
touching the cabinet on all four sides and that
cabinet is stable.
4. After unit is leveled, lower anti-tip leg using a
3/8 inch socket wrench until it firmly contacts
the floor.
To make final door height adjustments:
1. Open freezer drawer to make lower hinge
visible.
2. Insert 6mm Allen wrench into the shaft of the
lower hinge.
3. Adjust the height by turning clockwise or
counterclockwise. Turning clockwise will
lower the door. Turning counterclockwise will
raise the door. Default setting is to the lowest
height when you receive your appliance.
6
Flipper Mullion
Adjust Flipper Mullion for proper connection
with the mullion guide by ensuring the flipper
mullion is folded and perpendicular to the fresh
food door. If the mullion guide is not in the
correct position, it could prevent the door from
closing completely.
INSTALLING DOOR HANDLES
CAUTION
Wear gloves and safety goggles. Use extreme
CAUTION when installing these handles.
Door Handle Mounting Instructions
1. Remove handles from carton and any other
protective packaging.
2. Position refrigerator handle end caps over
upper and lower pre-installed shoulder bolts
(A) that are fastened into door, ensuring the
holes for the set screws are facing towards
the opposite door.
3. While holding handle firmly against door, fasten
upper and lower Allen set screws (B) with
supplied Allen wrench.
4. Repeat steps 2 and 3 to install opposite handle.
Ensure the holes for the set screws are facing
towards the first door.
5. Position freezer/FlexSpace
TM
Convertible
Drawer handle end caps over left and right pre-
installed shoulder bolts (A) that are fastened to
the door, ensuring the holes for the set screws
are facing down.
6. While holding handle firmly against door,
loosely tighten right Allen set screw (B) with
supplied Allen wrench until there is no gap
between handle and door.
7. Still holding the handle firmly to the door, firmly
tighten left Allen set screw (B) with supplied
Allen wrench.
8. Return to the right Allen set screw (B) and firmly
tighten with supplied Allen wrench.
Note: All set screws should be tightened so
the screw is below the surface of the
handle. The handles should be drawn tight
to doors/drawer with no gaps. Opening
the opposite door while tightening the
Allen screw makes installation easier.
The door handle may loosen over time or if it
was incorrectly installed. If this happens,
tighten the set screws on the handles.
7
Mounting Refrigerator Handles
Mounting Freezer/FlexSpace
TM
Convertible
Drawer Handle
CONNECTING THE WATER SUPPLY
WARNING
To avoid electric shock, which can cause death or
severe personal injury, disconnect the refrigerator
from electrical power before connecting a water
supply line to the refrigerator.
WARNING
To Avoid Property Damage:
• DO NOT install water supply tubing in areas
where temperatures fall below freezing.
• Chemicals from
a malfunctioning water
softener can damage the ice maker. If your
home has a water softening system, ensure the
softener is maintained and working properly.
IMPORTANT
Ensure that your water supply line connections
comply with all local plumbing codes.
Before Installing the Water Supply Line, You
Will Need
:
8
• Basic Tools: adjustable wrench, flat-blade
screwdriver, and Phillips
TM
screwdriver
• The water dispenser and automatic ice maker
require a drinkable water supply with a
pressure range of between 206kPa and
689kPa (30PSI and 100PSI).
• A water supply to suit a ½” tap fitting is
required adjacent to the refrigerator. It is
recommended that a licensed plumber install
a new water supply outlet nearer to the
appliance should the tubing supplied not be
long enough. It is not recommended that the
tubing be extended as this could adversely
affect the flow of water to the ice maker or
water dispenser.
WARNING
Connect to potable water supply only. If using
tank or bore water it is recommended to also use an
external filter (not supplied).
The new hose-sets supplied with
the appliances
must be used and old hose-sets should not be
reused.
WARNING
Never connect the appliance to a hot water
supply.
Do not use with water that is microbiologically
unsafe or
with water of unknown quality without
adequate disinfection.
To Connect Water Supply Line to Ice Maker Inlet
Valve
Installation kit supplied with Refrigerator:
A
- Adapter ½ to ¼ inch to connect the water
supply outlet to the water supply line.
B
- Water supply line ¼ inch with 3 meters in
length.
C
- ¼ inch connector to connect the water
supply line to the refrigerator tube.
1. Disconnect the refrigerator from the power
source.
2. Attach the adapter (item A above) to the water
line, connect the water supply line (item B) to
the adapter (item A) while holding the other
end of the water supply line in a bucket or sink
Turn on the water supply to eliminate air and
clean the water supply line.
Turn off the water supply.
3. Remove the plastic protector from the
refrigerator tube and connect the water supply
line (item B) to the refrigerator tube using the
connector (item C) as shown in fig.
Make sure the tubes are inserted completely
into the connections.
4. Wrap excess water supply line behind
refrigerator so that it does not vibrate with
refrigerator operation.
Do not twist the pipe.
5. Turn on the water supply, check that there are
no leaks in the connections.
6. Reconnect the refrigerator to the power source.
7. The Ice Maker is factory-switched, within 24
hours your refrigerator will have produced ice,
discard the first production.
Note: Expect the first ice harvest within
first 24 hours of unit operation. To prevent
any issues concerning ice production,
please ensure that all water lines are
primed. See “Priming the water supply
system “in the “AUTOMATIC ICE & WATER
DISPENSER” section.
Figure 2
IMPORTANT
9
A
B
C
Remove the cap
from the inlet tube
¼ inch water valve plastic tube
Figure
1
Adapter to connect
the water supply
outlet to the
water
supply line.
connector to connect the water
supply line to the refrigerator tube
Your refrigerator’s water supply system
includes several tubing lines, a water filter, and a
water valve. To ensure that your water
dispenser works properly, this system
must be completely filled with water when
your refrigerator is first connected to the
household water supply line.
Water Filter
The water filter should not be used on water
that is micro biologically unsafe or with water
of unknown quality. The service life of the filter
may be reduced in water supplies that contain
an excess of particles or other impurities.
Reduced flow rate is an indication that a new
filter is required. Failure to replace the filter
when required can affect the function of the
ice maker. Service calls caused by a failure to
replace the filter are not covered by warranty.
Replacement water filters are available from
Electrolux Home Products Spare Parts Centres
and can be posted to you for your convenience
(refer to spare parts contact numbers on the
warranty page).
ABOUT THE USER INTERFACE
Controls –External User interface
BUTTON
/ ICON
DESCRIPTION
PRIMARY FUNCTION
1.
Quick Freeze
(on/off)
Activates a faster rate for freezing food in the freezer. Deactivates
after 12 hours.
2.
Drinks Chill
Quickly chills a drink inside the freezer compartment. Touch the
Drinks Chill Key, a time value will display on the freezer temp display
(in minutes) and can be changed using the +/- buttons. A tone will
sound when the time has been input. Range is from 20-45 minutes in
5 minute intervals.
3.
Ice Maker
When LED is lit, the ice maker is on. When ice maker is in OFF
state, the indicator will blink when dispensing ice. Press and hold
for 3 seconds to turn ice maker on/off.
4.
Lock
Press and hold for 3 seconds to enable/disable. While in the locked
state, you will not be able to change any settings on the display nor
dispense ice and water. The indicator will flash and an audible
warning tone is played.
5.
Error Code
Display show error code
6.
Adjusting Temp
Press either the + or - to adjust to desired temperature setting.
Freezer temp
- Control temperatures range
From -23°C to -15°C.
Refrigerator temp
- Control temperatures range
From +1°C to +7°C.
10
13
14
15
16
1
2
3
4
12
11
10
8
7 5
6
9
6
BUTTON
/ ICON
DESCRIPTION
PRIMARY FUNCTION
7.
Door Open
Illuminates and sounds an alarm when the door is left open for 5
minutes or more. It stays illuminated as long as the door is open.
Pressing any key will mute and reset the alarm.
8.
Replace Water
Filter
Display illuminates every 6 months or when filter needs replacing.
Press and hold ‘Reset Water Filter’ for 3 seconds to reset.
9.
Replace Air
Filter
Display illuminates every 6 months or when filter needs replacing.
Press and hold ‘Reset Air Filter’ for 3 seconds to reset.
10. Water
Press the “water” key to select water. An indicator light will be
illuminated above the active feature.
11. Cubed Ice
Press the “cube” key to select cubed ice. An indicator light will be
illuminated above the active feature.
12. Crushed Ice
Press the “crush” key to select crushed ice. An indicator light will be
illuminated above the active feature.
13. Quick Chill
Quick chill is a faster rate for chilling food in the refrigerator
compartment. Deactivates after 6 hours.
14.
Reset Air Filter
After replacing filter, press and hold for 3 seconds to reset.
15.
Reset Water
Filter
After replacing filter, press and hold for 3 seconds to reset.
16.
Lighting
Toggles dispenser light On and Off.
11
ABOUT THE USER INTERFACE
Controls – Internal User interface
Note: Features may vary according to model.
Double freezer model does not have this
user
interface.
BUTTON
/ ICON
DESCRIPTION PRIMARY FUNCTION
1. Unlock
The interface will automatically lock after 3 seconds without any
interaction. Press and hold 3 seconds to unlock the interface.
A tone will sound to confirm your choice.
2. Freezer
Choosing Freezer will set drawer temperature to the same temperature
as the freezer compartment. A tone will sound to confirm your choice.
3. Ultra Chill
Choosing Ultra Chill will set drawer temperature to -2°C.
A tone will sound to confirm your choice.
4. Cold Drinks
Choosing Cold Drinks will set drawer temperature to 0°C.
A tone will sound to confirm your choice.
5. Deli Snacks
Choosing Deli Snacks will set drawer temperature to 3°C.
A tone will sound to confirm your choice.
6. Chilled Wine
Choosing Chilled Wine will set drawer temperature to 7°C.
A tone will sound to confirm your choice.
12
1
2 3 4 5
6
Setting cooling temperatures
Note: The recommended settings for a
product installed in a kitchen is 3˚C for
the fresh food compartment and -17˚C
for the freezer.
IMPORTANT
If your product has food freezing in the fresh food
compartment, increase the temperature setting 1
or 2 degrees Celsius.
If you place food within 1 inch in front of the air
ports, there may be the chance of freezing food.
Note: Control features and alarms may
vary by
model.
Alerts and Alarms
Water Filter
When illuminated, the water filter needs to be
replaced. Change the water filter every 6 months
or when 120 gallons of water has been dispensed.
To reset, press and hold button for 3 seconds.
Tone will
sound once it has been reset.
Air Filter Installation
First
operation the refrigerator need to installation
the air filter which storage at crisper left side and
follow installation method as below.
Carbon activated air filter
1) Remove plastic wrap.
2) Install filter according to your refrigerator’s
use&care guide.
3) Reset filter reminder light on your refrigerator.
4) Replace filter every 6 months.
When illuminated, air filter needs to be replaced.
Change the air filter every 6 months. To reset,
press and hold button for 3 seconds. Tone will
sounds once it has been reset.
Sabbath Mode
The Sabbath Mode is a feature that disables
portions of the refrigerator and its controls in
accordance with observance of the weekly
Sabbath and religious holidays within the
Orthodox Jewish community.
Sabbath Mode is turned ON and OFF by
simultaneously pressing and holding both the “-”
(freezer side) and “+” (refrigerator side) for five
seconds. Other than the High Temp alarm, no
audible sounds will occur until the user exits the
Sabbath mode. The display shows “Sb” while in
Sabbath mode.
In the Sabbath Mode, the High Temp alarm is
active for health reasons. For example,
If the door is left ajar the High Temp alarm is
activated. The refrigerator will function normally
once the door is closed, without any violation of
the Sabbath/Holidays. The High Temp alarm is
permitted when cabinet temperature is outside
the safe zone for 20 minutes. The alarm silences
itself after 10 minutes while the High Temp icon
stays lit until the Sabbath mode is exited.
Note: While in Sabbath Mode, neither the
lights, dispenser, nor the control panel will
work until Sabbath Mode is deactivated.
Refrigerator stays in Sabbath Mode after
power failure recovery. It must be
deactivated with the buttons on the
control panel.
Although you have entered the Sabbath
Mode, the ice maker will complete the
cycle it had already initiated. The ice cube
compartment will remain cold and new
ice cubes can be made with standard
trays.
13
Door Open
If a door has been left open for 5 minutes or
more, an alarm will sound and the door open
indicator will illuminate on the display. The alarm
can be turned off by closing the door or
pressing any key. Control panel will return to
normal operation after the door is closed.
Error Tone
An al
arm will sound if the user tries to make a
selection that is not available.
AUTOMATIC ICE & WATER
DISPENSER
Using the ice maker after installation
Before making ice for the first time, be sure to
prime the water supply system. Air in new
plumbing lines can result in two or three empty
ice maker cycles. Furthermore, if the system is
not flushed, the first ice cubes may be
discolored or have an odd flavor.
Priming the water supply system
CAUTION
For proper dispenser operation, recommended
water supply pressure should fall between 30
psi and 100 psi. Excessive pressure may cause
the system to malfunction.
1. Begin filling the system by pressing and holding
a drinking glass against the dispenser.
2.Keep the glass in this
position until water comes
out of the dispenser. It may take about 1½
minutes.
3.Continue dispensing water for about four
minutes to flush the system and plumbing
connections of any impurities (stopping to
empty the glass as necessary).
Dispenser
Note: The water dispenser has a built-in
device that shuts off the water flow after
three minutes of continuous use. To reset
this shut-off device, simply release the
dispenser paddle.
Only the first 26 ounces (750 ml) of
dispensed water is chilled.
Ice maker operation & care
After the refrigerator is installed properly and has
cooled for several hours, the ice maker can
produce ice within 24 hours. The ice maker will fill
the ice bin from the rear. You must dispense some
ice to force the ice forward in the bin. This will
allow the bin to fill completely.
Ice Maker and Storage Bin Capacity
This ice maker should produce 2.5 to 3 pounds of
ice per 24 hours. The ice bin will hold about 4
pounds of ice.
Turning the ice maker on and off
IMPORTANT
Your ice maker is turned on at the factory so it can
work as soon as you install your refrigerator. If you
cannot connect a water supply, set the ice maker’s
On/Off feature to Off; otherwise, the ice maker’s
fill valve may make a loud chattering noise when
it attempts to operate without water.
Ice production is controlled by the ice maker’s
On/Off feature on the control panel. Pressing the
On/Off feature turns the ice maker on & off.
Note: The ice maker also has a built-in
plastic signal arm that automatically stops
ice production when the ice bin is full. This
signal arm should not be used to manually
stop the ice maker.
IMPORTANT
Turning off the ice maker simply disables ice
making. You will still be able to dispense existing
ice, and you will still be able to dispense water.
On occasion, unusually small ice cubes may be
noticed in the bucket or in dispensed ice. This
could occur in normal operation of the ice maker.
If you start seeing these more frequently, it may
be an indication of low water pressure, or that
the water filter needs to be replaced. As the
water filter nears the end of its useful life and
becomes clogged with particles, less water is
delivered to the ice maker during each cycle.
Remember, if it has been six months or longer
since you last changed your water filter, replace
the water filter with a new one. Poor quality
household water may require the filter to be
changed more frequently.
14
Ice maker/dispenser tips
• If your refrigerator is not connected to a water
supply or the water supply is turned off, turn off
the ice maker as described in the previous
section.
• The following sounds are normal when the ice
maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• If you need a large quantity of ice at one time, it
is best to get cubes directly from the ice bin.
• Ice cubes stored too long may develop an odd
flavor. Empty the ice bin as explained below.
• When dispensing cubed ice, it is normal to have
a small quantity of little pieces along with the
whole cubes.
• To avoid splashing, dispense ice into your
container before adding liquids.
• It is normal for ice to fill to the top of the ice bin.
CAUTION
If the water supply to your refrigerator is
softened, be sure the softener is properly
maintained. Chemicals from a water softener
can damage the ice maker.
Cleaning the ice maker
Clean the ice maker and ice bin at regular intervals,
especially prior to vacation or moving.
1. Turn off the icemaker.
2. Remove the ice bin by pulling straight out.
3. Empty and carefully clean the ice
bin with mild
detergent.
Do
n
ot
u
se harsh or abrasive
cleaners. Do not place in dishwasher. Rinse with
clear water.
4. Allow the ice bin to dry completely before
placing it back into the freezer.
5. Place ice bin back into position. Turn the ice
maker on.
Remove and empty the ice bin if:
• An extended power failure (one hour or longer)
causes ice cubes in the ice bin to melt and
refreeze together after power is restored,
jamming the dispenser mechanism.
• You do not use the ice dispenser frequently. Ice
cubes will freeze together in the bin, jamming
the dispenser mechanism.
Removing Ice Bin
Remove th
e ice bin and shake to loosen the cubes
or clean as explained above.
CAUTION
NEVER use an ice pick or similar sharp instrument
to break up the ice. This could damage the ice bin
and dispenser mechanism.
To loosen stuck ice, use warm water. Before
replacing the ice bin, make sure it is completely
dry.
15
IMPORTANT
When removing or replacing the ice bin, avoid
rotating the auger in the ice bin. If the auger is
accidentally rotated, you must realign the auger
by turning it in 45 degree turns (see below) until
the ice bin fits into place with the drive
mechanism. If the auger is not properly aligned
when replacing the ice bin, the refrigerator will not
dispense ice. The fresh food door also may not
close properly causing warm air to leak into the
fresh food compartment.
Adjusting the Ice Bin Auger
STORAGE FEATURES
CAUTION
To avoid personal injury or property damage,
handle tempered glass shelves carefully. Shelves
may break suddenly if nicked, scratched, or
exposed to sudden temperature change. Allow the
glass shelves to stabilize to room temperature
before cleaning. Do not wash in dishwasher.
You can easily adjust shelf positions in the fresh
food compartments to suit your needs. The
shelves have mounting brackets that attach to
slotted supports at the rear of each compartment.
To change a shelf position:
1. Remove all food from shelf.
2. Lift the front edge up and pull the shelf out.
3. Replace by inserting the mounting bracket
hooks into the desired support slots.
4. Lower the shelf and lock into position.
To adjust the flip shelf:
1. Remove food from shelf.
2. Lift the right side edge of shelf upwards and
push to the left towards ice maker
Flip Shelf
16
To adjust the slide-under/flip shelf:
1. Pull front half shelf forward until its back drops
down, then gently push front half shelf back and
under back half shelf.
Slide-Under/Flip Shelf
2. With fr
ont half fully below back half, lift front of
shelf to flip it upwards toward the back of the
cabinet.
Slide-Under/Flip Shelf
Drawers
Your refrigerator includes a variety of storage
drawers.
FreshSeal
TM
Crisper (with automatic humidity
control)
Crisper drawers are designed for storing fruits,
vegetables, and other fresh produce. Crispers
have an auto humidity control (with replaceable
membrane) on the side of each crisper under the
humidity control cover.
To remove the auto humidity control
membrane:
1. Reach to back of humidity control cover.
2. Pull up on cover.
3. Pull cover towards back of cabinet and remove.
4. Replace humidity membrane.
5. Replace cover by reversing the steps above.
Repeat for both crispers.
Opening the Crisper Drawer
To remove the FreshSeal
TM
Crisper for
cleaning:
1. Pull the drawer out until it stops.
2. Lift the front slightly and remove the drawer.
Removing the FreshSeal
TM
Crisper
17
Recessed SnackZone
This drawer is ideal for storage of deli meats and
cheese.
Slide back the cover to allow access to the
drawers.
Opening the SnackZone
Doors
Storage bins
The doors to your fresh food compartment use a
system of modular storage bins. All of these bins
are removable for easy cleaning. Bins can be
adjusted to your needs.
Door bins are ideal for storing jars, bottles, cans,
and large drink containers. They also enable quick
selection of frequently used items.
Adjustable door bins
Some models have adjustable door bins that can
be moved to suit individual needs.
To adjust the collapsible door bin:
1. Make sure bin is securely seated on rail in
door.
2. Grab one side of bin and place other hand on
adjustable side.
3. Pull on side of bin until the bin is adjusted to
desired width.
Note: It can be difficult to pull out the
collapsible bin. Some force may be
required.
To move door bin along a rail:
1. Tilt bin up so the back of the bin is off the door
but the hook is still engaged.
2. Slide bin along rail to desired position.
3. Lower bin back into place.
To move door bin from rail to rail:
1. Lift bin up disengaging the hook.
2. Move bin to desired rail location.
3. Push bin hook into rail engaging the hook.
Adjustable Door Bins
Freezer Features (varies by model)
Freezer Basket
18
To remove upper freezer basket:
1. Open freezer compartment completely.
2. Lift up and out to remove upper freezer
basket.
Reverse the steps to reinstall basket.
IMPORTANT
There are wheels on the bottom of the drawer.
Make sure all wheels are aligned on their
respective tracks for proper function. If drawer is
not aligned properly, it will cause problems with
the door operation.
Note: If basket is not resting on stabilizer
bar retainer clips, the drawer will not
close properly.
To remove lower freezer basket:
1. Open freezer compartment completely.
2. Lift the basket up and remove.
Reverse the steps to reinstall drawer.
Dividers
Grab hand hold on lower divider and pull up
slightly to slide to next position. (The divider
cannot be removed.)
Lower Basket Divider
CLEANING YOUR REFRIGERATOR
WARNING
BEFORE CLEANING: Turn the refrigerator off at
the power point and unplug the cord to prevent
any chance of electrocuting yourself.
Doors and exterior (white and silver):
You should only clean the doors with lukewarm
soapy water and a soft cloth.
Stainless Steel:
Your stainless steel refrigerator is manufactured
from mark-resistant stainless steel. This stainless
steel has a special advanced protective coating
that eases the removal of marks such as
fingerprints and water spots. To keep its
appearance, clean it regularly with lukewarm
soapy water and a soft cloth.
CAUTION
Never use stainless steel cleaners, abrasive pads
or other cleaners that will scratch the surface.
Damage to the appliance after delivery is not
covered by your warranty.
Interior
Clean the inside of your refrigerator regularly with
a soft cloth, unscented mild soap and lukewarm
water. Thoroughly dry all surfaces and removable
parts and avoid getting water on the controls.
Replace removable parts, plug power cord in and
switch the power on before returning the food.
Door seals
Always keep door seals clean by washing them
with a mild detergent and warm water, followed
by a thorough drying. Sticky food and drink can
cause seals to stick to the cabinet and tear when
you open the door.
Never use hot water, solvents, commercial kitchen
cleaners, aerosol cleaners, metal polishes, caustic
or abrasive cleaners, or scourers to clean your
refrigerator. Many commercially available cleaning
products and detergents contain solvents that will
damage your refrigerator. Use only a soft cloth
with an unscented mild soap and lukewarm water.
19
CAUTION
To clean a crisper or freezer bin with telescopic
extension slides, simply wipe with a damp cloth
and warm soapy water. Never immerse the cover
in water, as this could affect the operation of the
slide.
Switching off your refrigerator
If you switch off your refrigerator for an
extended period, follow these steps to reduce
the chances of mould.
1. Remove all food.
2. Remove the power plug from the power point.
3. Thoroughly clean and dry the Interior.
4. Ensure that all the doors are wedged open
slightly for air circulation.
CHANGING THE FILTER
Air Filter (select models)
The air filter is located in the top center of the
fresh food compartment.
Replacing your Air Filter
To ensure optimal filtering of refrigerator odors,
you should change the air filter six months (The
filter status light on the Touch Panel prompts you
to replace the filter after six month)
1. Remove the air filter cover by squeezing the
sides of the cover together and removing from
liner
2. Remove the old filter and discard it.
3. Unpack the new filter
and slide it into the
housing. The open face must (carbon media) of
the filter should be installed facing the air port
(hole) in the multiflow.
4. Replace the air filter cover by squeezing the
sides and snapping it back into place.
5. Press and hold the “Reset Air Filter” button on
the control panel for three seconds. When the
LED turns off, the status has been reset.
Water Filter (selected models)
Your refrigerator is equipped with a water filtering
system. The water filtering system filters all
dispensed drinking water, as well as the water
used to produce ice. The water filter is located at
the top right side of the fresh food compartment.
In general, you should change the water filter
every six months to ensure the highest possible
water quality. Water filter status on the user
interface prompts you to replace the filter after a
standard amount of water (125 gallons/473 liters)
has flowed through the system.
If your refrigerator has not been used for a period
of time (during moving for example), change the
filter before reinstalling the refrigerator
Note: When ordering your replacement
filter, please reorder the same filter type
that is currently in your refrigerator.
20
Replacing the Water Filter
To Remove
: Pull cover towards you and cover
will drop down and allow access to filter.
To Reinstall
: Push cover up towards liner and
then push towards rear of cabinet. Filter cover
will snap back into place.
It is not necessary to turn the water supply off to
change the filter. Be ready to wipe up any small
amounts of water released during the filter
replacement.
1. Ensure that the ice maker is turned off
2. Remove the
filter by turning anti-clockwise
180˚
3. Slide the old water filter cartridge straight out
of the housing and discard it.
4. Unwrap the new filter cartridge and using the
alignment guide, slide it gently into filter
housing until it stops against the filter
connection at the back of the housing.
5. Engage the filter by firmly rotating clockwise
until the filter snaps into position (once
engaged the filter cannot be rotated further).
6. Press a drinking glass against the water
dispenser while checking for any leaks at the
filter housing. Any spurts and sputters that
occur as the system purges air out of the
dispenser system are normal.
7. After filling one glass of water, continue
flushing the system for about four minutes.
8. Turn on the ice maker.
9. When the filter has been replaced press and
hold the ‘Reset Water Filter’ button for
three seconds to reset the filter replace
timer.
10.Replace filter cover by pushing up and
snapping into place.
21
FOOD STORAGE GUIDE
22
Note: Double freezer model does not have the UltraChill feature.
IMPORTANT
* Please note, use this information as a guide
only, actual storage times will vary depending
on how you use your refrigerator.
CATEGORY PRODUCT
RECOMMENDED STORAGE TIMES FOR FRESH FOODS *
STORAGE TIPS
REFRIGERATOR
ULTRA CHILL
FREEZER
MEAT
Sausages
and Mince
1-2 Days
3-5 Days 2-3 Months
Keep cold meat at the back of the
refrigerator where it is coldest.
Plastic can cause meat to sweat if
stored in refrigerator for more than a
day.
Roast can take up to 48 hours to
defrost properly, transfer frozen roast
to the refrigerator 2 days before use.
Chops and
Steak
3-4 Days 5-7 Days 4-6 Months
Cold Meats
3-5 Days 5-7 Days 4-6 Months
Roasts
3-5 Days 1 week 12 Months
POULTRY Chicken
1-2 Days 5-7 Days 2 Months
If poultry takes on a smell or colour
you are unsure about it is best to
throw it out.
Whole eggs are not suitable for
freezing, slightly beaten eggs may be
frozen for four months.
Roast Chicken
3-5 Days 1 week 12 Months
Eggs
6 Weeks Not Suitable Not Suitable
SEAFO
OD
Whole fish
and fillets
2-3 Days 5-7 Days 2 Months
Store in an airtight container or foil.
Never freeze prawns in salty water
as this will dehydrate the flesh.
Lobster and
Crab
1-2 Days 3-5 Days 2 Months
Prawns
1-2 Days 3-5 Days 2 Months
DAIRY
Milk
Until Expiry Date Not Suitable Not Suitable
If dairy takes on a smell or colour and
you are unsure about it, it is best to
throw it out.
Depending on the variety hard cheese
can last from 2 weeks to 2 months.
* Texture may change depending
of the type of soft cheese
Yoghurt
7- 10 Days Not Suitable Not Suitable
Hard Cheeses
2 Weeks – 2
Months
1-2 Months
2 Months
(Grated)
Soft Cheeses
1-2 Weeks 2-4 Weeks * Not Suitable
Butter
8 Weeks 3-4 Months 12 Months
FRUIT &
VEGETABLES
Every fruit and vegetable has a
different shelf life. Some stay fresh
for a couple of days e.g. beans,
others can last for a couple of
months e.g. onions.
Not Suitable 8-12 Months
When freezing
chop and
blanch in sm
all
p
ortions.
Keep vegetables in the crisper and away
from the air vents to avoid freezing.
If you wash fruit and vegetables before
storing them make sure they are dry or
wrap in absorbent paper before storing
in the refrigerator as this can make them
susceptible to rotting.
Try to keep fruit and vegetables
separated as fruits that give off high
levels of ethylene (the ripening agent)
can prematurely ripen and spoil
surrounding vegetables
CARE & CLEANING
Care & Cleaning Tips
Part
What To Use
Tips and Precautions
Interior & Door Liners
• Soap and water
• Baking soda and water
Use two tablespoons of baking soda in one quart of warm
water.
Be sure to wring excess water out of sponge or
cloth before cleaning around controls, light bulb or any
electrical part.
Door Gaskets
• Soap and water
Wipe gaskets with a clean soft cloth.
Drawers & Bins
• Soap and water
Use a soft cloth to clean drawer runners and tracks.
Glass Shelves
• Soap and water
• Glass cleaner
• Mild liquid sprays
Allow glass to warm to room temperature before
immersing in warm water.
Exterior & Handles
• Soap and water
• Non Abrasive Glass Cleaner
Do not use commercial household cleaners containing
ammonia, bleach or alcohol to clean handles. Use a soft
cloth to clean smooth handles or exterior.
DO NOT use a
dry cloth to clean smooth doors.
Exterior & Handles
(Stainless Steel Models
Only)
• Soap and water
• Stainless Steel Cleaners
Never use CHLORIDE or cleaners with bleach to clean
stainless steel.
Clean stainless steel front and handles with non-abrasive
soapy water and a dishcloth. Rinse with clean water and a
soft cloth. Use a non-abrasive stainless steel cleaner.
These cleaners can be purchased at most home
improvement or major department stores. Always follow
manufacturer’s instructions. Do not use household
cleaners containing ammonia or bleach.
NOTE: Always clean, wipe and dry with the grain to
prevent scratching.
Wash the rest of the cabinet with
warm water and mild liquid detergent. Rinse well, and
wipe dry with a clean soft cloth.
23
TROUBLESHOOTING
Concern
Potential Cause
Common Solution
Automatic Ice Maker
Ice maker is not
making any ice.
• Ice maker is turned off.
• Refrigerator is not connected to water
line or water valve is not open.
• The water supply line is kinked.
• The water filter is not seated properly.
• The water filter may be clogged with
foreign material.
• Turn on ice maker. For the fresh food ice maker,
press ice maker on-off button once.
• Connect the unit to the household water supply and
ensure the water valve is open.
• Ensure that the supply line does not kink when the
refrigerator is pushed into place against the wall.
• Remove and re-install the water filter. Be sure to
seat it fully into the locked position.
• If water dispenses slowly or not at all, or if the filter
is six months old or older, it should be replaced.
Ice maker is not
making enough ice.
• Ice maker is producing less ice than you
expect.
• The water filter may be clogged with
foreign material.
• The water supply line is kinked.
• Water pressure is extremely low. Cut-
off and cut-on pressures are too low
(well systems only).
• Reverse osmosis system is in
regenerative phase.
• The ice maker will produce approximately 2.3
pounds of ice every 24 hours depending on usage
conditions.
• If water dispenses slower than normal, or if the filter
is six months old or older, it should be replaced.
• Ensure that the supply line does not kink when the
refrigerator is pushed into place against the wall.
• Have someone turn up the cut-off and cut-on
pressure on the water pump system (well systems
only).
• It is normal for a reverse osmosis system to be
below 20 psi during the regenerative phase.
Ice cubes are
freezing together.
• Ice cubes are not being used frequently
enough or interruption of power for
prolonged time.
• Ice cubes are hollow (shells of ice with
water inside). The hollow cubes break
open in the bin and leak their water
onto existing ice, which causes it to
freeze together.
• Remove ice container and discard ice. The ice maker
will produce fresh supply. Ice should be used at least
twice weekly to keep the cubes separated.
• This generally occurs when the ice maker does not
get enough water. This is usually the result of a
clogged water filter or restricted water supply.
Replace the water filter and if the condition still
occurs, check to see if the water valve is not turned
on all the way or if there is a kinked water supply
line.
Dispenser (Ice & Water)
Dispenser (Ice &
water) not
dispensing ice.
• There is no ice in the bin to be
dispensed.
• The refrigerator doors are not
completely closed.
• Dispenser paddle has been pressed too
long and the dispenser motor has
overheated.
• See the “Ice maker is not making any ice” section.
• Be sure the refrigerator doors are completely closed.
• The motor overload protector will reset in about
three minutes and then ice can be dispensed.
Ice dispenser is
jammed.
• Ice has melted and frozen around auger
due to infrequent use, temperature
fluctuations, and/or power outages.
• Ice cubes are jammed between ice
maker and back of ice container.
• Remove ice container, thaw, and empty the
contents. Clean container, wipe dry, and replace in
proper position. When new ice is made, dispenser
should operate.
• Remove ice cubes that are jamming the dispenser.
24
TROUBLESHOOTING
Concern
Potential Cause
Common Solution
Dispenser (Ice & Water)
Dispenser (Ice &
water) not
dispensing water.
• Water filter not seated properly.
• Water filter is clogged.
• Household water line valve is not open.
• Remove and reinstall the water filter. Be sure to
rotate it to the right until it stops and the grip end is
vertical.
• Replace filter cartridge. Be sure to rotate it to the
right until it stops and the grip end is vertical.
• Open household water line valve. See CONCERN
column AUTOMATIC ICE MAKER.
Water not cold
enough.
• As warmer tap water goes through the
filter and enters the water supply
system, the chilled water is pushed
through to the dispenser. Once the
chilled water is used up, it will take
several hours to bring the freshly
replaced water to a cooler temperature.
• Add ice to cup or container before dispensing water.
Water has an odd
taste and/or odor.
• Water has not been dispensed for an
extended period of time.
• Unit not properly connected to cold
water line.
• Draw and discard 10-12 glasses of water to freshen
the supply.
• Connect unit to cold water line that supplies water
to the kitchen faucet.
Opening/Closing Of Doors/Drawer
Door(s) will not
close.
• Door was closed too hard, causing
other door to open slightly.
• Refrigerator is not level. It rocks on the
floor when moved slightly.
• Refrigerator is touching a wall or
cabinet.
• Check gasket and cabinet interface for
any obstructions.
• Close both doors gently.
• Ensure floor is level and solid, and can adequately
support the refrigerator. Contact a carpenter to
correct a sagging or sloping floor.
• Ensure floor is level and solid, and can adequately
support the refrigerator. Contact a carpenter to
correct a sagging or sloping floor.
• Clean the refrigerator door gaskets and interface
with warm, soapy water to remove any grease, dirt
and grime from the surface. Wipe clean with a dry
cloth. Inspect the gasket to make sure it is
thoroughly clean.
Drawers are difficult
to move.
• Food is touching shelf on top of drawer.
• Track that drawers slide on is dirty.
• Remove top layer of items in drawer.
• Ensure drawer is properly installed on track.
• Clean drawer, rollers, and track. See Care & Cleaning.
Running of Refrigerator
Compressor does
not run.
• Refrigerator is in defrost cycle.
• Plug at electrical outlet is disconnected.
• House fuse blown or tripped circuit
breaker.
• Power outage.
• This is normal for a fully automatic defrost
refrigerator. The defrost cycle occurs periodically,
lasting about 30 minutes.
• Ensure plug is tightly pushed into outlet.
• Check/replace fuse with a 15 amp time-delay fuse.
Reset circuit breaker.
• Check house lights. Call local electric company.
25
TROUBLESHOOTING
Concern
Potential Cause
Common Solution
Running of Refrigerator
Refrigerator seems to
run too much or too
long.
• Your variable speed compressor is
designed to run 100% of the time
except during the defrost cycle. At
times it will run faster, such as after a
defrost cycle.
• It is normal for the compressor to run continuously
except during defrost mode.
Digital Temperature Setting Display
Digital temperature
displays an error.
• Electronic control system has detected
a performance problem.
• Call your Electrolux service representative, who can
interpret any messages or number codes flashing
on the digital displays.
Water/Moisture/Frost Inside Refrigerator
Moisture collects on
inside of refrigerator
walls.
• Weather is hot and humid.
• Flipper mullion
• The rate of frost buildup and internal sweating
increases.
• Adjust flipper mullion. (See “To adjust the flipper
mullion” in the Installation section.)
Water collects on
bottom side of drawer
cover.
• Vegetables contain and give off
moisture.
• It is not unusual to have moisture on the bottom
side of the cover.
Water collects in
bottom of drawer.
• Washed vegetables and fruit drain
while in the drawer
• Dry items before putting them in the drawer. Water
collecting in bottom of drawer is normal
Water/Moisture/Frost Outside Refrigerator
Moisture collects on
outside of refrigerator
or between doors.
• Weather is humid.
• This is normal in humid weather. When humidity is
lower, the moisture should disappear.
Food in Fresh Food Compartment
Food is freezing.
• Temperature setting is too low.
• Temperature sensor is covered by food
(right side of fresh food area).
• Food is covering the air ports.
• Move the setting to a higher degree.
• Allow space for air flow to the sensor.
• Allow space between the air ports and the food.
26
27
This document sets out the terms and conditions of the product
warranties for Westinghouse Appliances. It is an important
document. Please keep it with your proof of purchase documents
in a safe place for future reference should there be a manufacturing
defect in your Appliance. This warranty is in addition to other rights
you may have under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the
Competition and Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products
Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004
762 341 in respect of Appliances purchased in Australia and Electrolux
(NZ) Limited (collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount
Wellington, in respect of Appliances purchased in New Zealand;
(e) ‘WarrantyPeriod’meanstheperiodspeciedinclause3ofthis
warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased
and used in Australia or New Zealand and is in addition to (and does not
exclude, restrict, or modify in any way) other rights and remedies under
a law to which the Appliances or services relate, including any non-
excludable statutory guarantees in Australia and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty
continues for in Australia for a period of 24 months and in New Zealand
for a period of 24 months, following the date of original purchase of the
Appliance.Speciccomponentsarewarrantedagainstmanufacturing
defects in Australia and New Zealand for the periods listed below;
• Comp essor – Further 3 years parts only,
• Exte nal Condenser – Further 3 years parts only
• Evaporator – Further 3 years parts onl
• Drier – Further 3 years parts onl
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge if your Appliance is readily accessible
for service, without special equipment and subject to these terms and
conditions, repair or replace any parts which it considers to be defective.
Electrolux may, in its absolute discretion, choose whether the remedy
oeredforavalidwarrantyclaimisrepairorreplacement.Electroluxorits
ASC may use refurbished parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the
Appliance to and from Electrolux or its ASC. Travel and transportation will
be arranged by Electrolux as part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this
warranty.
7. Exclusions: You may not make a claim under this warranty unless the
defect claimed is due to faulty or defective parts or workmanship. This
warranty does not cover:
(a) lightglobes,batteries,ltersorsimilarperishableparts;
(b) parts and Appliances not supplied by Electrolux;
(c) cosmeticdamagewhichdoesnotaecttheoperationofthe
Appliance;
(d) damage to the Appliance caused by:
(i)i) negligence or accide
(ii)ii) misuse or abuse, including fa e to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv)iv) normal wear and t
(v)v) power surges, electrical storm damage or inc ect power supply;
(vi)vi) incomplete or oper installation;
(vii)vii) i ect, improper or inappropriate operation;
(viii)viii) insect or vermin infest
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which
the Appliance was intended, including where the Appliance has
been used for any non-domestic purpose;
(b) theApplianceismodiedwithoutauthorityfromElectroluxinwriting;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced.
8. How to claim under this warranty: To enquire about claiming under
this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the
terms of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure.
‘Acceptable quality’ and ‘major failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux
pursuant to the provisions of the Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading Act. Where the Appliance was
purchased in New Zealand for commercial purposes the Consumer
Guarantee Act does not apply.
11.Condentiality: You accept that if you make a warranty claim, Electrolux
and its agents including ASC may exchange information in relation to you
to enable Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: WESTINGHOUSE REFRIGERATORS AND FREEZERS
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
AUSTRALIA
ELECTROLUX HOME PRODUCTS
163 O’Riordan Street, Mascot NSW 2020
electrolux.com.au
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
(New Zealand only)
NEW ZEALAND
ELECTROLUX (NZ) Limited
3-5 Niall Burgess Road, Mount Wellington
electrolux.co.nz
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
(New Zealand only)
WFridgeFreezer_Warr_Jun17
AUSTRALIA
phone: 1300 363 640
fax: 1800 350 067
email: customercare@electrolux.com.au
web: westinghouse.com.au
NEW ZEALAND
phone: 0800 436 245
fax: 0800 225 088
email: customercare@electrolux.co.nz
web: westinghouse.co.nz
For more information on all Westinghouse
appliances, or for dimension and installation
information, call into your retailer, phone or email
our customer care team or visit our website:
TOP SERVICE
Top Service encompasses the after sales service
provided by The Electrolux Group to consumers
including delivery, home service and spare parts.
and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation.
Used under license. All Rights Reserved.
P/No. . A10883102/D
© 2017 Electrolux Home Products Pty Ltd.
ABN 51 004 762 341
MDR4_JUN'18
