OWNER’S MANUAL
Smart TV Upgrader
Please read this manual carefully before operating
your set and retain it for future reference.
ST600
P/NO : SAC35193509
www.lg.com
ENGLISH
1 Getting Started
Getting Started 3
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
Getting Started4
Getting Started
1
FCC Compliance Statement
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
y
Reorient or relocate the receiving antenna.
y
Increase the separation between the equipment
and receiver.
y
Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
y
Consult the dealer or an experienced radio/TV
technician for help.
CAUTION: Any changes or modications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
FCC RF Radiation Exposure Statement : This
equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with minimum distance 20 cm between the
radiator and your body. End users must follow the
specic operating instructions for satisfying RF
exposure compliance. This transmitter must not be
co-located or operating in conjunction with any
other antenna or transmitter.
FCC Radio Frequency Interference
Requirements : This device is restricted to indoor
use due to its operation in the 5.15 to 5.25 GHz
frequency range. FCC requires this product to
be used indoors for the frequency range 5.15
to 5.25 GHz to reduce the potential for harmful
interference to co-channel Mobile Satellite systems.
CAUTION: Regulations of the FCC and FAA prohibit
airborne operation of radio-frequency wireless
devices because their signals could interfere with
critical aircraft instruments.
Responsible Party :
LG Electronics USA, Inc.1000 Sylvan Avenue
Englewood Clis, NJ 07632
TEL. : +1-800-243-0000
Getting Started 5
Getting Started
1
Notes on Copyrights
y
Recording equipment should be used only for
lawful copying and you are advised to check
carefully what is lawful copying in the area
in which you are making a copy. Copying of
copyright material such as lms or music is
unlawful unless permitted by a legal exception
or consented to by the rights owner.
y
CONSUMERS SHOULD NOTE THAT NOT ALL
HIGH DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY
CAUSE ARTIFACTS TO BE DISPLAYED IN THE
PICTURE. IN CASE OF 480 PROGRESSIVE SCAN
PICTURE PROBLEMS, IT IS RECOMMENDED
THAT THE USER SWITCH THE CONNECTION
TO THE ‘STANDARD DEFINITION’ OUTPUT. IF
THERE ARE QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 480p UNIT
PLEASE CONTACT OUR CUSTOMER SERVICE
CENTRE.
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not t into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specied by
the manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table
specied by the manufacturer,
or sold with the apparatus.
When a cart is used, use
caution when moving the cart/
apparatus combination to avoid injury from tip-
over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Table of Contents6
Table of Contents
1 Getting Started
3 Safety Information
8 Introduction
8 – About the “7” Symbol Display
8 – File requirement
10 – About DLNA
10 – Certain System Requirements
10 – LG Remote
10 – WOL (Wake On LAN)
10 – Compatibility Notes
11 Main Unit
11 Remote control
2 Connecting
12 Connecting the AC Adapter
12 HDMI Connecting to Your TV
13 – Resolution Setting
14 Connecting to an Amplifier
14 – Connecting to an Amplifier via HDMI
Output
15 – Connecting to an Amplifier via Digital
Audio Output
16 Connecting to your Home Network
16 – Wired network connection
17 – Wired Network Setup
18 – Wireless Network Connection
18 – Wireless Network Setup
21 USB device connection
21 – Playback content in the USB device
3 System Setting
22 Settings
22 – Adjust the Setup Settings
22 – [DISPLAY] Menu
23 – [LANGUAGE] Menu
24 – [AUDIO] Menu
25 – [NETWORK] Menu
26 – [OTHERS] Menu
4 Operating
27 General Playback
27 – Using [HOME] menu
27 – Playing a file media from a USB
device
28 – Playing a file media from a network
server
29 – Wi-Fi Direct™ Connection
31 – Basic operations for video and audio
content
31 – Basic operations for photo content
32 Advanced Playback
32 – Zoom in & out during slide show
32 – Repeat Playback
32 – Viewing content information
32 – Changing content list view
33 – Selecting a subtitle file
33 – Setting your photo as a wallpaper
33 – Options while viewing a photo
34 – Listening to music while slide show
34 On-Screen display
34 – Displaying content information on-
screen
35 – Playing from selected time
35 – Listening to a different audio track
35 – Selecting a subtitle language
35 – Changing TV Aspect Ratio
35 – Changing subtitle code page
36 – Changing Picture Mode
36 Using the Premium
37 Using the LG Apps
37 – Signing in
37 – Managing my Apps
38 Using the Browser Home
38 – About the Browser Home menu
39 – Editing your favorite web pages
39 – Additional browser options
40 Playing content via Media Link
40 – Mide Link connection
41 – Using the Media Link
41 – Using Movie section
42 – Using Music section
42 – Using TV Program section
43 – Plug-in installation
Table of Contents 7
1
2
3
4
5
6
5 Troubleshooting
44 Troubleshooting
44 – General
44 – Picture
45 – Resetting
45 – Network
45 – Customer Support
45 – Open source software notice
6 Appendix
46 Network Software Update
46 – Network update notification
46 – Software Update
47 About Nero MediaHome 4 Essentials
47 – Installing Nero MediaHome 4
Essentials
48 – Sharing files and folders
49 Trademarks and Licenses
50 Audio Output Specifications
51 Specifications
52 Maintenance
52 – Handling the Unit
52 Important Information Relating to
Network Services
Getting Started8
Getting Started
1
Introduction
About the “
7
” Symbol Display
“
7
” may appear on your TV display during operation and indicates that the function explained in this
owner’s manual is not available on that specic media.
File requirement
Video files
File
Location
File
Extension
Codec Format Audio Format Subtitle
USB
“.avi”, “.divx”,
“.mpg”,
“.mpeg”,
“.mkv”, “.mp4”,
“.asf”, “.wmv”,
“.m4v” (DRM
free)
DIVX3.xx, DIVX4.xx,
DIVX5.xx, DIVX6.xx
(standard playback
only), XVID, H.264/
MPEG-4 AVC, VC-1
SM (WMV3), MPEG1,
MPEG2
Dolby Digital,
DTS, MP3,
WMA, AAC,
Dolby Digital
Plus
SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt),
MicroDVD (.sub/.txt), VobSub
(.sub), SubViewer 1.0 (.sub),
SubViewer 2.0 (.sub/.txt), TMUnit
(.txt), DVD Subtitle System (.txt)
DLNA, PC
“.avi”, “.divx”,
“.mpg”,
“.mpeg”,
“.mkv”, “.mp4”,
“.asf”, “.wmv”
DIVX3.xx, DIVX4.xx,
DIVX5.xx, DIVX6.xx
(standard playback
only), XVID, H.264/
MPEG-4 AVC, VC-1
SM (WMV3), MPEG1,
MPEG2
Dolby Digital,
DTS, MP3,
WMA, AAC,
Dolby Digital
Plus
SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt),
MicroDVD (.sub/.txt), SubViewer
1.0 (.sub), SubViewer 2.0 (.sub/.
txt), TMUnit (.txt), DVD Subtitle
System (.txt)
Media Link
“.mp4”, “.asf”,
“.wmv”
Audio files
File
Location
File
Extension
Sampling Frequency Bitrate Note
USB,
DLNA, PC
“.mp3”, “.wma”,
“.m4a” (DRM
free)
within 32 - 48 kHz
(WMA), within 16 - 48
kHz (MP3)
within 20 - 320 kbps
(WMA), within 32 - 320
kbps (MP3)
Some audio les are
not supported on
this unit.
Media Link “.mp3”, “.wma”
Photo files
File
Location
File
Extension
Recommanded
Size
Note
USB,
DLNA, PC,
“.jpg”, “.jpeg”,
“.png”,
Less than 4,000 x 3,000 x 24 bit/pixel
Less than 3,000 x 3,000 x 32 bit/pixel
Progressive and lossless
compression photo image les
are not supported.
Getting Started 9
Getting Started
1
y
The le name is limited to 180 characters.
y
Maximum les/Folder: Less than 2000 (total number of les and folders)
y
Depending on the size and number of the les, it may take several minutes to read the contents on
the media.
y
File compatibility may dier depending on the server.
y
Because the compatibility on DLNA server are tested on the bundle DLNA server (Nero MediaHome
4 Essentials) environment, le requirements and playback functions may dier depending on media
servers.
y
The le requirements on page 8 are not always compatible. There may have some restrictions by le
features and media server’s ability.
y
Playing a video subtitle les are only available on share folder of a PC or DLNA media server created
by supplied Nero MediaHome 4 Essentials software on this unit package.
y
The les from removable media such as USB drive etc. on your media server may not be shared
properly.
y
This unit cannot support the ID3 Tag embedded MP3 le.
y
The total playback time of audio le indicated on the screen may not correct for VBR les.
y
HD video les contained on the USB 1.0/1.1 may not played properly. USB 2.0 are recommended to
play back HD video les.
y
This unit supports H.264/MPEG-4 AVC prole Main, High at Level 4.1. For a le with higher level, the
warning message will appear on the screen.
y
This unit does not support les that are recorded with GMC or Qpel.
y
GMC – Global Motion Compensation
y
Qpel – Quarter pixel
,
Note
Getting Started10
Getting Started
1
About DLNA
This Unit is a DLNA Certied digital media unit
that can display and play movie, photo and music
content from your DLNA-compatible digital media
server (PC and Consumer Electronics).
The Digital Living Network Alliance (DLNA) is a
cross-industry organization of consumer electronics,
computing industry and mobile device companies.
Digital Living provides consumers with easy sharing
of digital media through your home network.
The DLNA certication logo makes it easy
to nd products that comply with the DLNA
Interoperability Guidelines. This unit complies with
DLNA Interoperability Guidelines v1.5.
When a PC running DLNA server software or other
DLNA compatible device is connected to this unit,
some setting changes of software or other devices
may be required. Please refer to the operating
instructions for the software or device for more
information.
Certain System Requirements
For high denition video playback:
y
High denition display that has HDMI input jacks.
For Dolby® Digital Plus and DTS multi-channel
audio playback:
y
An amplier/receiver with a built-in (Dolby
Digital, Dolby Digital Plus or DTS) decoder.
y
Main, center, surround speakers and subwoofer
as necessary for chosen format.
For playing les on your PC’s share folder via your
home network, the PC requires below.
y
Windows® XP (Service Pack 2 or higher),
Windows Vista® (no Service Pack required)
Windows 7® (no Service Pack required)
y
1.2 GHz Intel® Pentium® III or AMD
Sempron™ 2200+ processors
y
Network environment: 100 Mb Ethernet, WLAN
y
More than 1 folder on your PC has to be shared.
Visit suppot link of your operating system for
more information on le share settings.
LG Remote
You can control this unit with your iPhone or
Android phone via your home network. This unit
and your phone must be connected to your
wireless network device such as access point.
Visit “Apple iTunes” or “Google Apps Marketplace” for
detailed information of “LG Remote”.
WOL (Wake On LAN)
Users can turn on this unit using WOL embeded
utility on your personal computer or smartphone
via your home network. To use this feature, this unit
must be connected to the WOL available access
point or router with wired network connection.
Refer to the relevant manual of the utility or
network devices for more detailed information.
Compatibility Notes
y
If you experience compatibility problems, please
contact an authorized Customer Service Center.
y
Dolby Digital Plus are supported with maximum
7.1 channels if you use HDMI connection for the
audio output of the unit.
Getting Started 11
Getting Started
1
Main Unit
a b c d
e
f g h
a
LAN port
b
HDMI OUT (1080p)
c
OPTICAL AUDIO OUT
d
DC IN 12V (AC adapter input)
e
Power indicator
f
Remote sensor
g
USB port
h
RESET
a
1
(POWER): Switches the
unit ON or OFF.
b
m
(MENU): Displays or exits
On-Screen Display.
c
Direction buttons: Selects
an option in the menu.
d
Center buttons (Touch
Sensors): Enters the selected
item.
In web browser menu, You
can control this button
displayed cursor in all
directions.
Note: If you leave the unit
without touching, the touch
function will be disable for
energy saving. To activate
the touch function, press
direction button and touch
the sensors.
e
HOME (
n
): Displays or exits
the Home Menu.
f
BACK (
x
): Exits the menu
or resumes playback.
g
Colored (R, G, Y, B) buttons:
They are also used for [Smart
Share], [Premium], [LG Apps]
and [Web Browser] menu.
h
d
(Play): Starts playback.
M
(Pause): Pauses playback.
i
c/v
: Searches
backward or forward.
C/V
: Press and hold for
two seconds to skip previous/
next chapter or le.
Z
(Stop): Stops playback.
Battery Installation
Remove the battery cover on the
rear of the Remote Control, and
insert two R6 (size AA, alkaline)
batteries with
4
and
5
matched
correctly.
Remote control
2 Connecting
Connecting12
Connecting
2
Connecting the AC
Adapter
Connect the unit to the power supply with the
supplied AC adapter.
Connect the power cord to the adapter, and then
plug the other end into an AC outlet.
Rear of the unit
Plug into a
power source
AC power cord
AC adapter
y
Contact an electrical parts distributor for
assistance in selecting a suitable AC plug adapter
or AC cord set.
y
This AC adapter is manufacture by Asian Power
Devices Inc.
Only use the AC adapter supplied with this
device. Do not use a power supply from
another device or another manufacturer. Using
any other power cable or power supply may
cause damage to the device and void your
warranty.
>
Caution
HDMI Connecting to
Your TV
If you have a HDMI TV or monitor, you can connect
it to this unit using a HDMI cable (Type A, High
Speed HDMI™ Cable). Connect the HDMI jack on
the unit to the HDMI jack on a HDMI compatible TV
or monitor.
Rear of the unit
TV
HDMI cable
(not supplied)
Set the TV’s source to HDMI (refer to TV’s Owner’s
manual).
y
If you select a resolution manually and then
connect the HDMI jack to TV and your TV
does not accept it, the resolution setting is
set to [Auto].
y
If you select a resolution that your TV
does not accept, the warning message
will appear. After resolution change,
if you cannot see the screen, please
wait 20 seconds and the resolution will
automatically revert back to the previous
resolution.
y
The 1080p video output frame rate may
be automatically set to either 24 Hz or 60
Hz depending both on the capability and
preference of the connected TV.
,
Note
Connecting 13
Connecting
2
Additional Information for HDMI
y
When you connect a HDMI or DVI compatible
device make sure of the following:
-
Try switching o the HDMI/DVI device and
this unit. Next, switch on the HDMI/DVI
device and leave it for around 30 seconds,
then switch on this unit.
-
The connected device’s video input is set
correctly for this unit.
-
The connected device is compatible with
720x480p, 1280x720p, 1920x1080i or
1920x1080p video input.
y
Not all HDCP-compatible HDMI or DVI devices
will work with this unit.
-
The picture will not be displayed properly
with non-HDCP device.
y
If a connected HDMI device does not accept
the audio output of the unit, the HDMI
device’s audio sound may be distorted or
may not output.
y
When you use HDMI connection, you can
change the resolution for the HDMI output.
(Refer to “Resolution Setting” on page 13)
y
Select the type of video output from the
HDMI OUT jack using [HDMI Color Setting]
option on the [Setup] menu (see page 23).
y
Changing the resolution when the
connection has already been established
may result in malfunctions. To solve the
problem, turn o the unit and then turn it
on again.
y
When the HDMI connection with HDCP
is not veried, TV screen is changed to
black screen. In this case, check the HDMI
connection, or disconnect the HDMI cable.
y
If there are noises or lines on the screen,
please check the HDMI cable (length is
generally limited to 4.5 m(15 ft.)).
,
Note
Resolution Setting
The unit provides several output resolutions for
HDMI OUT. You can change the resolution using
[Setup] menu.
1. Press HOME (
n
).
2. Press green (G) colored button. The [Setup]
menu appears.
3. Use
W/S
to select [DISPLAY] option then
press
D
to move to the second level.
4. Use
W/S
to select the [Resolution] option
then press Center button to move to the third
level.
5. Use
W/S
to select the desired resolution then
press Center button to conrm your selection.
14
Connecting
2
Connecting
Connecting to an
Amplifier
Make one of the following connections, depending
on the capabilities of your existing equipment.
y
HDMI Audio connection (page 14)
y
Digital Audio connection (page 15)
Since many factors aect the type of audio output,
see “Audio Output Specications” on page 50 for
details.
About Digital Multi-channel sound
A digital multi-channel connection provides the
best sound quality. For this, you need a multi-
channel Audio/Video Receiver that supports one or
more of the audio formats supported by your unit.
Check the logos on the front of the Audio/Video
receiver and the manual. (PCM Stereo, Dolby Digital,
Dolby Digital Plus or DTS)
Connecting to an Amplifier via
HDMI Output
Connect the unit’s HDMI OUT jack to the
corresponding in jack on your amplier using a
HDMI cable.
HDMI cable
HDMI
cable
TV
Receiver/Amplier
Rear of the unit
Connect the amplier’s HDMI output jack to HDMI
input jack on your TV using a HDMI cable if your
amplier has HDMI output jack.
You will need to activate the unit’s digital output.
(See “[AUDIO] Menu” on page 24)
Connecting 15
Connecting
2
Connecting to an Amplifier via
Digital Audio Output
Connect the unit’s OPTICAL AUDIO OUT jack to the
corresponding in jack (OPTICAL) on your amplier
using an optional digital audio cable.
DIGITAL INPUT
OPTICAL
Optical cable
Receiver/Amplier
Rear of the unit
You will need to activate the unit’s digital output.
(See “[AUDIO] Menu” on page 24.)
Connecting16
Connecting
2
Connecting to your
Home Network
This unit can be connected to a local area network
(LAN) via the LAN port on the rear panel or the
internal wireless module.
By connecting the unit to a broadband home
network, you have access to services such as
software updates, Web Browser and on-line content
services.
Wired network connection
Using a wired network provides the best
performance, because the attached devices
connect directly to the network and are not subject
to radio frequency interference.
Please refer to the documentation for your network
device for further instructions.
Connect the unit’s LAN port to the corresponding
port on your Modem or Router using a
commercially available LAN or Ethernet cable.
y
When plugging or unplugging the LAN
cable, hold the plug portion of the cable.
When unplugging, do not pull on the LAN
cable but unplug while pressing down on
the lock.
y
Do not connect a modular phone cable to
the LAN port.
y
Since there are various connection
congurations, please follow the
specications of your telecommunication
carrier or internet service provider.
y
If you want to access content from PCs or
DLNA servers, this unit must be connected
to the same local area network with them
via a router.
,
Note
WAN
LAN 1
LAN 2
LAN 3
Rear of the unit
Router
Broadband
service
PC and/or DLNA
certied server
Connecting 17
Connecting
2
Wired Network Setup
If there is a DHCP server on the local area
network (LAN) via wired connection, this unit will
automatically be allocated an IP address. After
making the physical connection, a small number
of home networks may require the unit’s network
setting to be adjusted. Adjust the [NETWORK]
setting as follow.
Preparation
Before setting the wired network, you need to
connect the broadband internet to your home
network.
1. Select [Connection Setting] option in the
[Setup] menu then press Center button.
2. The [Connection Setting] menu appear on the
screen. Use
W/S
to select the [Wired] and
press Center button.
3. Use
W/S/A/D
to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
If there is no DHCP server on the network and
you want to set the IP address manually, select
[Static] then set [IP Address], [Subnet Mask],
[Gateway] and [DNS Server] using
W/S/A/
D
.
,
Note
4. Select [OK] and press Center button to apply
network settings.
5. The unit will ask you to test the network
connection. Select [OK] and press Center
button to complete the network connection.
6. If you select [Test] and press Center button at
step 5 above, the network connection status is
displayed on the screen.
You can also test it on the [Connection Status]
in the [Setup] menu.
Connecting18
Connecting
2
Wireless Network Connection
Another connection option is to use an Access Point
or a wireless router. The network conguration and
connection method may vary depending on the
equipment in use and the network environment.
This unit is equipped with an IEEE 802.11n (Dual-
band, 5 GHz and 2.4 GHz band) wireless module,
which also supports the 802.11a/b/g standards.
For the best wireless performance, we recommend
using a IEEE 802.11n certied Wi-Fi network (access
point or wireless router).
Wireless
Communication
PC and/or
DLNA certied server
Access Point or
Wireless Router
Broadband
service
Refer to the setup instructions supplied with
your access point or wireless router for detailed
connection steps and network settings.
For best performance, a direct wired connection
from this unit to your home network’s router or
cable/DSL modem is always the best option.
If you do chose to use the wireless option, note that
performance can sometimes be aected by other
electronic devices in the home.
Available frequency range and channels for
5 GHz band are listed as below. But, there
may have the dierences and restrictions
depending on the country. Try setting your
access point with other channel if you have
diculties in wireless network connection.
Area Frequency Range
North
America
5.15-5.25 GHz (ch. 36-48),
5.725-5.825 GHz (ch. 149-161),
5.825-5.850 GHz (ch.165)
Europe 5.15-5.25 GHz (ch. 36-48)
Others 5.15-5.25 GHz (ch. 36-48),
5.725-5.825 GHz (ch. 149-161),
5.825- 5.850 GHz (ch.165)
,
Note
Wireless Network Setup
For the wireless network connection, the unit needs
to be set up for network communication. This
adjustment can be done from the [Setup] menu.
Adjust the [NETWORK] setting as follow. Setting up
the access point or the wireless router is required
before connecting the unit to the network.
Preparation
Before setting the wireless network, you need to:
-
Connect the broadband internet to the wireless
home network.
-
Set the access point or wireless router.
-
Note the SSID and security code of the network.
1. Select [Connection Setting] option in the
[Setup] menu then press Center button.
Connecting 19
Connecting
2
2. The [Connection Setting] menu appear on the
screen. Use
W/S
to select [Wireless] and press
Center button.
3. Select [Yes] and press Center button to
continue. The new connection settings reset
the current network settings.
4. The unit scans the all available access points or
wireless routers within range and display them
as a list. Use
W/S
to select an access point
or wireless router on the list, and then press
Center button.
If you have security on your access point or
wireless router, verify that the WEP or WPA key
that was entered into the unit matches the
router’s information exactly. You need to input
the security code as necessary.
y
WEP security mode generally have 4 keys
available on an access point or wireless
router’s setting. If your access point or
wireless router use WEP security, enter the
security code of the key “No.1” to connect
on your home network.
y
An Access Point is a device that allows you
to connect to your home network wirelessly.
y
If your access point or wireless router
supports the PIN Code conguration
method based on WPS(Wi-Fi Protected
Setup), press yellow (Y) colored button and
note the code number on the screen. And
then, enter the PIN number on a setting
menu of your access point or wireless router
to connect. Refer to the documentation for
your network device.
,
Note
[Manual] – Your access point may not be
broadcasting its access point name (SSID).
Check your router settings through your
computer and either set your router to
broadcast SSID, or manually enter the access
point name (SSID) in [Manual].
[Push Button] – If your access point or
wireless router that supports the Push Button
Conguration method, select this option and
press the Push Button on your access point or
wireless router within 120 counts. You do not
need to know the access point name (SSID) and
security code of your access point or wireless
router.
5. Use
W/S/A/D
to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
If there is no DHCP server on the network and
you want to set the IP address manually, select
[Static] then set [IP Address], [Subnet Mask],
[Gateway] and [DNS Server] using
W/S/A/
D
and numerical buttons.
,
Note
6. Select [OK] and press Center button to apply
network settings.
7. The unit will ask you to test the network
connection. Select [OK] and press Center
button to complete the network connection.
8. If you select [Test] and press Center button at
step 7 above, the network connection status is
displayed on the screen. You can also test it on
the [Connection Status] in the [Setup] menu.
Connecting20
Connecting
2
Notes on Network Connection:
y
Many network connection problems during set
up can often be xed by re-setting the router or
modem. After connecting the unit to the home
network, quickly power o and/or onnect the
power cable of the home network router or
cable modem. Then power on and/or connect
the power cable again.
y
Depending on the internet service provider (ISP),
the number of devices that can receive internet
service may be limited by the applicable terms
of service. For details, contact your ISP.
y
Our company is not responsible for any
malfunction of the unit and/or the internet
connection feature due to communication
errors/malfunctions associated with your
broadband internet connection, or other
connected equipment.
y
Some internet contents may require a higher
bandwidth connection.
y
Even if the unit is properly connected and
congured, some internet contents may not
operate properly because of internet congestion,
the quality or bandwidth of your internet service,
or problems at the provider of the content.
y
Some internet connection operations may not
be possible due to certain restrictions set by the
Internet service provider (ISP) supplying your
broadband Internet connection.
y
Any fees charged by an ISP including, without
limitation, connection charges are your
responsibility.
y
A 10 Base-T or 100 Base-TX LAN port is required
for wired connection to this unit. If your internet
service does not allow for such a connection,
you will not be able to connect the unit.
y
You must use a Router to use xDSL service.
y
A DSL modem is required to use DSL service and
a cable modem is required to use cable modem
service. Depending on the access method of and
subscriber agreement with your ISP, you may not
be able to use the internet connection feature
contained in this unit or you may be limited to
the number of devices you can connect at the
same time. (If your ISP limits subscription to one
device, this unit may not be allowed to connect
when a PC is already connected.)
y
The use of a “Router” may not be allowed or its
usage may be limited depending on the policies
and restrictions of your ISP. For details, contact
your ISP directly.
y
The wireless network operate at 2.4 GHz
radio frequencies that are also used by other
household devices such as cordless telephone,
Bluetooth® devices, microwave oven, and can be
aected by interference from them.
y
Turn o all unused network equipment in
your local home network. Some devices may
generate network trac.
y
For the purpose of the better transmission,
placing the unit from the access point as close as
possible.
y
In some instances, placing the access point or
wireless router at least 0.45 m (1.5 ft.) above the
oor may improve the reception.
y
Move closer to the access point if possible or re-
orient the unit so there is nothing between it
and the access point.
y
The reception quality over wireless depends on
many factors such as type of the access point,
distance between the unit and access point, and
the location of the unit.
y
Set your access point or wireless router to
Infrastructure mode. Ad-hoc mode is not
supported.
Connecting 21
Connecting
2
USB device connection
This unit can play video, audio and photo les
contained in the USB device.
Playback content in the USB
device
1. Insert a USB device to the USB port until it ts
into place.
When you connect the USB device on the HOME
menu, the unit plays an audio le contained in the
USB storage device automatically. If the USB storage
device is containing various types of les, a menu
for the le type selection will appear.
File loading may takes few minutes depending on
the number of content stored in the USB storage
device. Press Center button while [Cancel] is
selected to stop loading.
2. Press HOME (
n
).
3. Select [Smart Share] using
A/D
, and press
Center button.
4. Select [Movie], [Photo] or [Music] using
W/S
,
and press Center button.
5. Select [USB] option using
W/S
, and press
Center button.
6. Select a le using
W/S/A/D
, and press
d
or Center button to play the le.
7. Withdraw the USB device carefully.
y
This unit supports USB ash drive/external
HDD formatted in FAT16, FAT32 and NTFS
when accessing les (audio, photo, video).
y
This unit can support up to 8 partitions of
the USB device.
y
Do not extract the USB device during
operation (play, etc.).
y
A USB device which requires additional
program installation when you have
connected it to a computer, is not
supported.
y
USB device: USB device that supports
USB1.1 and USB2.0.
y
Movie, music and photo les can be played.
For details of operations on each le, refer
to relevant pages.
y
Regular back up is recommended to
prevent data loss.
y
If you use a USB extension cable, USB HUB
or USB Multi-reader, the USB device may not
be recognized.
y
Some USB device may not work with this
unit.
y
Digital camera and mobile phone are not
supported.
y
USB Port of the unit cannot be connected
to PC. The unit cannot be used as a storage
device.
,
Note
3 System Setting
System Setting22
System Setting
3
Settings
Adjust the Setup Settings
You can change the settings of the unit in the
[Setup] menu.
1. Press HOME (
n
).
2. Press green (G) colored button. The [Setup]
menu appears.
3. Use
W/S
to select the rst setup option, and
press
D
to move to the second level.
4. Use
W/S
to select a second setup option, and
press Center button or
D
to move to the third
level.
5. Use
W/S
to select a sdesired setting, and
press Center button or
D
to conrm your
selection.
[DISPLAY] Menu
TV Aspect Ratio
Select a TV aspect ratio option according to your TV
type.
[4:3 Letter Box]
Select when a standard 4:3 TV is connected.
Displays theatrical images with masking bars
above and below the picture.
[4:3 Pan Scan]
Select when a standard 4:3 TV is connected.
Displays pictures cropped to ll your TV screen.
Both sides of the picture are cut o.
[16:9 Original]
Select when a 16:9 wide TV is connected. The
4:3 picture is displayed with an original 4:3
aspect ratio, with black bars appearing at the
left and right sides.
[16:9 Full]
Select when a 16:9 wide TV is connected. The
4:3 picture is adjusted horizontally (in a linear
proportion) to ll the entire screen.
You cannot select [4:3 Letter Box] and
[4:3 Pan Scan] option when the resolution is
set to higher than 720p.
,
Note
23
System Setting
3
Resolution
Sets the output resolution of the Component and
HDMI video signal. Refer to page 13 for details about
the resolution setting.
[Auto]
If the HDMI OUT jack is connected to
TVs providing display information (EDID),
automatically selects the resolution best suited
to the connected TV.
[1080p]
Outputs 1080 lines of progressive video.
[1080i]
Outputs 1080 lines of interlaced video.
[720p]
Outputs 720 lines of progressive video.
[480p]
Outputs 480 lines of progressive video.
1080p Display Mode
When the resolution is set to 1080p, select
[24 Hz] for smooth presentation of lm material
(1080p/24 Hz) with a HDMI-equipped display
compatible with 1080p/24 Hz input.
y
When you select [24 Hz], you may
experience some picture disturbance when
the video switches video and lm material.
In this case, select [60 Hz].
y
Even when [1080p Display Mode] is set to
[24 Hz], if your TV is not compatible with
1080p/24 Hz, the actual frame frequency of
the video output will be 60 Hz to match the
video source format.
,
Note
HDMI Color Setting
Select the type of output from the HDMI OUT jack.
For this setting, please refer to the manuals of your
display device.
[YCbCr]
Select when connecting to a HDMI display
device.
[RGB]
Select when connecting to a DVI display
device.
Wallpaper
Changes the background of the initial screen.
[LANGUAGE] Menu
Display Menu
Select a language for the [Setup] menu and on-
screen display.
System Setting
System Setting24
System Setting
3
[AUDIO] Menu
Set the unit’s Audio options according to the type
of audio system you use.
Since many factors aect the type of audio
output, see “Audio Output Specications” on
page 50 for details.
,
Note
HDMI / Digital Output
[PCM Stereo]
Select if you connect this unit’s HDMI OUT or
DIGITAL AUDIO OUT jack to a device with two-
channel digital stereo decoder.
[DTS Re-Encode]
Select if you connect this unit’s HDMI OUT or
DIGITAL AUDIO OUT jack to a device with DTS
decoder.
[Primary Pass-Thru]
Select if you connect this unit’s OPTICAL AUDIO
OUT and HDMI OUT jack to a device with
LPCM, Dolby Digital, Dolby Digital Plus and DTS
decoder.
Sampling Freq.
(Digital Audio Output)
[192 kHz]
Select this if your A/V Receiver or Amplier is
capable of handling 192 kHz signals.
[96 kHz]
Select this if your A/V Receiver or Amplier is
not capable of handling 192 kHz signals. When
this choice is made, this unit
automatically converts any 192 kHz signals to
96 kHz so your system can decode them.
[48 kHz]
Select this if your A/V Receiver or Amplier is
not capable of handling 192 kHz and 96 kHz
signal. When this choice is made, this unit
automatically converts any 192 kHz and 96 kHz
signals to 48 kHz so your system can decode
them.
Check the documentation for your A/V Receiver or
Amplier to verify its capabilities.
DRC (Dynamic Range Control)
This function allows you to listen to a movie at a
lower volume without losing clarity of sound.
[O]
Turns o this function.
[On]
Compress the dynamic range of the Dolby
Digital or Dolby Digital Plus audio output.
[Auto]
The dynamic range of the Dolby Digital and
Dolby Digital Plus are operated as same as the
[On] mode.
The DRC setting can be changed only the unit
is in complete stop mode.
,
Note
System Setting 25
System Setting
3
[NETWORK] Menu
The [NETWORK] settings are needed to use the
software update, Web Browser and on-line content
services.
Connection Setting
If your home network environment is ready to
connect the unit, the unit needs to be set the
wired or wireless network connection for network
communication. (See “Connecting to your Home
Network” on pages 16.)
Connection Status
If you want to check the network status on this unit,
select the [Connection Status] options and press
Center button to check whether a connection
to the network and the internet have been
established.
Wi-Fi Direct
This player is a Wi-Fi Direct™ certied device. Wi-Fi
Direct™ is the technology that devices to connect
each other without connecting to an Access point
or a router. Set this option to [On] for activating the
Wi-Fi Direct™ mode. Refer to page 29 for the device
connection.
Netflix
[Netix ESN]
Display its unique Netix ESN (Electronic Serial
Number) that allows you to use the Netix
streaming.
[Deactivate Netix]
Deactivates your unit. To activate the Netix
again, contact to the service provider.
Deactivate Vudu
You can deactivate your unit from your Vudu
account. It is recommended that you do this if you
give your unit to someone else who should not
share your Vudu account.
Premium/LG Apps
[Country Setting]
Select your area for displaying proper services
and contents on the [Premium] and [LG Apps]
feature.
[ID Management]
Displays the [ID Management] menu. You can
manage IDs that ever logged-in on this unit.
[Registration Code]
Display the unique code of this unit for
servicing [Premium] and [LG Apps] feature.
System Setting26
System Setting
3
[OTHERS] Menu
DivX® VOD
ABOUT DIVX VIDEO: DivX® is a digital video format
created by DivX, Inc. This is an ocial DivX Certied®
device that plays DivX video. Visit divx.com for more
information and software tools to convert your les
into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certied® device must be registered in order to play
purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX
VOD section in your device setup menu. Go to vod.
divx.com for more information on how to complete
your registration.
[Register]
Displays the registration code of your unit.
[Deregister]
Deactivate your unit and display the
deactivation code.
All the downloaded videos from DivX VOD
with this unit’s registration code can only be
played back on this unit.
,
Note
Quick Start
This player can stay in standby mode with low
power consumption, so that the player can
instantly boot without delay when you turn on this
unit. Set this option to [On] for activating [Quick
Start] function.
If [Quick Start] option is set to [On] and an
AC power is acceidently re-connected to
the player by power failure etc., the player
automatically boots itself to be the standby
status. Before operating the player, wait for a
while until the player is in standby status.
,
Note
Auto Power Off
The screen saver appears when you leave the unit
in Stop mode for about ve minutes. If you set
this option to [On], the unit automatically turns
o within 25 minutes since the Screen Saver is
displayed. Set this option to [O] to leave the
screen saver until the unit is operated by the user.
Factory Set
You can reset the unit to its original factory settings.
If you reset the unit to its original factory
settings using [Factory Set] option, you have
to set all the activation for the on-line services
and network settings again.
,
Note
Software
[Information]
Displays the current software version.
[Update]
You can update the software by connecting
the unit directly to the software update server
(see page 46).
Disclaimer Notice
Press Center button to view the notice of Network
Service Disclaimer.
Pointer
You can adjust the pointer speed.
Network Play
This function allows you to control the playback
of media streamed from DLNA media server by a
DLNA certied smartphone. Most DLNA certied
smartphone has a function to control the playback
media on your home network. Set this option to
[On] for allowing your smartphone to control this
unit. Refer to instructions of your DLNA certied
smartphone or the application for more detailed
information.
4 Operating
Operating 27
Operating
4
General Playback
Using [HOME] menu
The home menu appears when you press HOME
(
n
). Use
W/S/A/D
to select a category and
press Center button.
a [Premium] - Displays the Premium Home or
[Edit Premium Card] screen.
b [LG Apps] - Displays the [LG Apps] screen.
c [Web Browser] - Displays the Browser Home
screen.
d [Sign In] - Displays the [Premium] or [LG
Apps] Login menu screen.
e [Setup] - Adjusts the system settings.
f [Smart Share] - Plays [Movie], [Photo],
[Music] or [Media Link] contents.
g [Search] - This function will be updated later.
h [LG Apps] - Displays the [LG Apps] screen.
i [Favorite Apps] - Shortcut for user’s favorite
Apps.
j [My Apps] - Display the [My Apps] screen.
Playing a file media from a
USB device
This unit can play video, audio and photo les
contained in the USB device.
1. Insert a USB device into the USB port until it ts
into place.
2. Press HOME (
n
).
3. Select [Smart Share] using
A/D
, and press
Center button.
4. Select [Movie], [Photo] or [Music] using
W/S/
A/D
, and press Center button.
5. Select [USB] option using
W/S
, and press
Center button.
6. Select a le using
W/S/A/D
, and press
d
or Center button to play the le.
Operating28
Operating
4
Playing a file media from a
network server
This unit can play video, audio and photo les
located in a PC or a DLNA server through your
home network.
1. Check the network connection and settings
(page 16).
2. Press HOME (
n
).
3. Select [Movie], [Photo] or [Music] using
W/S
,
and press Center button.
4. Select a DLNA media server or a share folder
on your PC on the list using
W/S
, and press
Center button.
If you want to rescan available media server,
press the green (G) colored button.
5. Select a le using
W/S/A/D
, and press
Center button to play the le.
y
The le requirements are described on page
8.
y
The thumbnail of the unplayable les can
be displayed, but those cannot be played
on this unit.
y
The subtitle le name and video le name
have to be the same and located at the
same folder.
y
The playback and operating quality may be
aected by your home network condition.
y
You may experience connection problems
depending on your server’s environment.
,
Note
Entering a network user ID and the
password
Depending on your PC’s environment, you may
need to enter a network user ID and the password
for accessing a shared folder.
1. The keyboard menu appears automatically if the
network user ID and the password are required.
2. Use
W/S/A/D
to select a character then
press Center button to conrm your selection
on the virtual keyboard.
To enter a letter with an accent mark, press
m
(MENU) to display the extended character set.
[Cancel] – Clear all entered characters.
[Space] – Inserts a space at the cursor position.
[<–] – Deletes the previous character at the
cursor position.
[ABC / abc / #+-=&] – Change the keyboard
menu settings to capital letters, small letters or
symbols.
3. When you nish entering the network user ID
and password, select [OK] using
W/S/A/D
and press Center button to access the folder.
The network user ID and password will be
remembered after accessing the folder for your
convenience. If you do not want the network user
ID and password to be remembered, press red (R)
colored button to un-tick the [Remember] check
box before accessing the folder.
Operating 29
Operating
4
Wi-Fi Direct™ Connection
Connecting to a Wi-Fi Direct™
certified device
This player can play movie, music and photo les
located in a Wi-Fi Direct™ certied device. The Wi-Fi
Direct™ technology make the player to be directely
connected to a Wi-Fi Direct™ certied device
without connecting to a network device such as an
access point.
1. Set the [Wi-Fi Direct] option on the [Setup]
menu to [On] (page 25).
2. Press HOME (
n
).
3. Select [Movie], [Photo] or [Music] using
W/S/
A/D
, and press Center button.
4. Select [Wi-Fi Direct] option using
W/S
, and
press Center button.
5. Select a Wi-Fi Direct™ device on the list using
W/S
, and press Center button.
Wi-Fi Direct™ connection will be automatically
proceeded.
If the Wi-Fi Direct™ device supports the PIN
Code conguration method based on WPS(Wi-
Fi Protected Setup), select a device on the list
and press yellow (Y) coloured button. Note the
PIN number on the screen. And then, enter the
PIN number on a setting menu of the device to
connect.
If you want to rescan available Wi-Fi Direct™
device, press the green (G) coloured button.
6. Select a server that shared from the connected
Wi-Fi Direct™ device using
W/S
, and press
Center button to navigate the server.
To select a server from the device list, les or
folders must be shared by DLNA server from the
connected Wi-Fi Direct™ device.
7. Select a le using
W/S/A/D
, and press
Center button to play the le.
y
For the purpose of the better transmission,
placing the player from the Wi-Fi Direct™
certied server as close as possible.
y
This unit can connect only 1 device at a
time. Multiple connection is not available.
y
If you try to connect wireless network while
a device is connected by Wi-Fi Direct™
function , Wi-Fi Direct™ connection will be
force disconnected.
y
If this player and a Wi-Fi Direct™ device
are connected to the dierent local area
network, Wi-Fi Direct™ connection may not
available.
,
Note
Operating30
Operating
4
Connecting to a Wi-Fi available
devices
This player can connect to a general Wi-Fi device
using Wi-Fi Direct™ function.
1. Set the [Wi-Fi Direct] option on the [Setup]
menu to [On] (page 25)
2. Press HOME (
n
).
3. Select [Movie], [Photo] or [Music] using
A/D
,
and press Center button.
4. Select [Wi-Fi Direct] option using
W/S
, and
press Center button.
5. Press red (R) coloured button to display the
[Network name (SSID)], [Security Option] and
[Encription] of the player.
6. On your Wi-Fi device, make a network
connection to this player, using [Network name
(SSID)], [Security Option] and [Encription] at
step 5 above.
7. Press BACK (
x
) twice to display the device list.
8. Select a server that shared from the connected
Wi-Fi device using
W/S
, and press Center
button to navigate the server.
To select a server from the device list, les or
folders must be shared by DLNA server from the
connected device.
9. Select a le using
W/S/A/D
, and press
Center button to play the le.
Operating 31
Operating
4
Basic operations for video and
audio content
To stop playback
Press
Z
(STOP) while playback.
To pause playback
Press
M
(PAUSE) while playback.
Press
d
(PLAY) to resume playback.
To play frame-by-frame (Video)
Press
M
(PAUSE) while movie playback.
Press
M
(PAUSE) repeatedly to play Frame-by-Frame
playback.
To scan forward or backward
Press
c
or
v
to play fast forward or fast reverse
during playback.
You can change the various playback speeds by
pressing
c
or
v
repeatedly.
To slow down the playing speed
While the playback is paused, press
v
repeatedly
to play various speeds of slow motion.
To skip to the next/previous file
During playback, press
C
or
V
and hold for
two seconds to go to the next le or to return to
the beginning of the current track/le.
Press
C
twice briey to step back to the previous
le.
In the le list menu of a server, there may have
many types of contents in a folder together. In this
case, press
C
or
V
and hold for two seconds
to go to the previous or next content with same
type.
Basic operations for photo
content
To play a slide show
Press
d
(PLAY) to start slide show.
To stop a slide show
Press
Z
(STOP) while slide show.
To pause a slide show
Press
M
(PAUSE) while slide show.
Press
d
(PLAY) to re-start the slide show.
To skip to the next/previous photo
While viewing a photo in full screen, press
A
or
D
to go to the previous or next photo.
Operating32
Operating
4
Advanced Playback
Zoom in & out during slide
show
1. During playback, press
m
(MENU) to display the
option menu.
2. Select the [Zoom] option using
W/S
, and
press Center button to display the [Zoom]
menu.
3. Use red (R) or green (G) colored button to zoom
out or in the picture. You can move through the
zoomed picture using
W/S/A/D
buttons.
4. To return to the normal picture size, press yellow
(Y) colored button.
5. Press BACK (
x
) to exit the [Zoom] menu.
Repeat Playback
During playback, press red (R) colored button
repeatedly to select a desired repeat mode.
Music les
;
Track– The current track or le will be played
back repeatedly.
:
All – All the tracks or les will be played back
repeatedly.
l
– The tracks or les will be played back in
random order.
l:
All – All the tracks or les will be played
back repeatedly in random order.
To return to normal playback, press red (R) colored
button repeatedly to select [O ].
Viewing content information
The unit can display the content information.
1. Select a le using
W/S/A/D
.
2. Press
m
(MENU) to display the option menu.
3. Select the [Information] option using
W/S
,
and press Center button.
The le information appears on the screen.
The information displayed on the screen
may not correct comparing actual content
information.
,
Note
Changing content list view
On the [Movie], [Music] or [Photo] menu, you can
change the content list view.
Method 1
Press red (R) colored button repeatedly.
Method 2
1. On the content list, press
m
(MENU) to display
the option menu.
2. Use
W/S
to select the [View Change] option.
3. Press Center button to change the content list
view.
Operating 33
Operating
4
Selecting a subtitle file
If the subtitle le name is dierent from the video
le name, you need to select the subtitle le on the
[Movie] menu before playing the movie.
1. Use
W/S/A/D
to select the subtitle le you
wish to play in the [Movie] menu.
2. Press Center button.
Press Center button again to deselect the
subtitle le. Selected subtitle le will be
displayed when you play the video le.
y
If you press
Z
(STOP) while playback, the
subtitle selection is cancelled.
y
This function is not available for playing le
on a server via home network.
,
Note
Setting your photo as a
wallpaper
You can apply your photo to the wallpaper.
1. Press HOME (
n
).
2. Select [Smart Share] using
A/D
, and press
Center button.
3. Select [Photo] using
W/S
, and press ENTER
(
b
).
4. Select [USB] option using
W/S
, and press
Center button.
5. Select a photo le, and press
m
(MENU) to
display the option menu.
6. Use
W/S
to select [Wallpaper], and press
Center button.
7. Use
A/D
to select [Yes], and press Center
button to be applied.
The photo will be set as [Wallpaper 5] on the
[Setup] menu.
Options while viewing a photo
You can use various options during viewing a
photo in full screen.
1. While viewing a photo in full screen, press
m
(MENU) to display the option menu.
2. Select an option using
W/S
.
a Current photo/Total number of photos
– Use
A/D
to view previous/next photo.
b Slide Show – Press Center button to start
or pause slide show.
c Music Select – Select the background
music for the slide show (page 34).
d Music –Press Center button to start or
pause background music.
e Rotate – Press Center button to rotate
the photo clockwise.
f Zoom – Press Center button to display
the [Zoom] menu.
g Eect – Use
A/D
to select a transition
eect between photos in a slide show.
h Speed – Use
A/D
to select a delaying
speed between photos in a slide show.
3. Press BACK(
x
) to exit the option menu.
Operating34
Operating
4
Listening to music while slide
show
You can display photo les while listening to audio
les.
1. While viewing a photo in full screen, press
m
(MENU) to display the option menu.
2. Use
W/S
to select [Music Select] option, and
press Center button to display the [Music
Select] menu.
3. Use
W/S
to select a device, and press Center
button.
Device that you can select are dier depending
on the location of the photo le you are
displaying in full screen.
Photo location Available Device
USB USB
Share Folder (PC) Share Folder (PC)
DLNA server DLNA server
4. Use
W/S
to select a le or a folder you wish to
play.
Select
g
and press Center button to display
the upper directory.
When selecting the audio le from a server,
folder selection is not available. Only le
selection is available.
,
Note
5. Use
D
to select [OK], and press Center button
to complete music selection.
On-Screen display
You can display and adjust various information and
settings about the content.
Displaying content information
on-screen
1. While playback, press
m
(MENU) to show
various playback information.
a Title – current title number/total number of
titles
b Time – elapsed playing time/total playback
time
c Audio – selected audio language or channel
d Subtitle – selected subtitle.
e Code Page – selected subtitle code page
(page 33).
f TV Aspect Ratio – selected TV aspect Ratio.
g Picture Mode – selected picture mode.
2. Select an option using
W/S
.
3. Use
A/D
to adjust the selected option value.
4. Press BACK(
x
) to exit the On-Screen display.
y
If no button is pressed for a few seconds,
the on-screen display disappears.
y
Available items may dier depending on
titles.
,
Note
Operating 35
Operating
4
Playing from selected time
1. Press
m
(MENU) during playback. The time
search box shows the elapsed playing time.
2. Select the [Time] option and then input the
required start time in hours, minutes, and
seconds from left to right.
For example, to nd a scene at 2 hours, 10
minutes, and 20 seconds, enter “21020”.
Press
A/D
to skip the playback 60 seconds
forward or backward.
3. Press Center button to start playback from
selected time.
y
This function may not work on some titles.
y
This function may not work depending on
the le type and ability of the DLNA server.
,
Note
Listening to a different audio
track
1. During playback, press
m
(MENU) to display the
On-Screen display.
2. Use
W/S
to select the [Audio] option.
3. Use
A/D
to select desired audio language,
audio track or audio channel.
Immediately after you have switched sound,
there may be a temporary discrepancy
between the display and actual sound.
,
Note
Selecting a subtitle language
1. During playback, press
m
(MENU) to display the
On-Screen display.
2. Use
W/S
to select the [Subtitle] option.
3. Use
A/D
to select desired subtitle language.
4. Press BACK(
x
) to exit the On-Screen display.
Changing TV Aspect Ratio
You can change the TV aspect ratio setting while
playback.
1. During playback, press
m
(MENU) to display the
On-Screen display.
2. Use
W/S
to select the [TV Aspect Ratio]
option.
3. Use
A/D
to select desired option.
4. Press BACK(
x
) to exit the On-Screen display.
Even if you change the value of the [TV Aspect
Ratio] option in On-Screen display, the [TV
Aspect Ratio] option in the [Setup] menu is
not changed.
,
Note
Changing subtitle code page
If the subtitle is displayed in broken letter, you can
change the subtitle code page to view the subtitle
le properly.
1. During playback, press
m
(MENU) to display the
playback menu.
2. Use
W/S
to select the [Code Page] option.
3. Use
A/D
to select desired code option.
4. Press BACK(
x
) to exit the On-Screen display.
Operating36
Operating
4
Changing Picture Mode
You can change the [Picture mode] option while
playback.
1. During playback, press
m
(MENU) to display the
On-Screen display.
2. Use
W/S
to select the [Picture Mode] option.
3. Use
A/D
to select desired option.
4. Press BACK(
x
) to exit the On-Screen display.
Setting the [User setting] option
1. During playback, press
m
(MENU) to display the
On-Screen display.
2. Use
W/S
to select the [Picture Mode] option.
3. Use
A/D
to select the [User setting] option,
and press Center button.
4. Use
W/S/A/D
to adjust the [Picture Mode]
options.
Select [Default] option then press Center
button to reset the all video adjustments.
5. Use
W/S/A/D
to select the [Close] option,
and press Center button to nish setting.
Using the Premium
You can use various content services via Internet
with the Premium feature.
1. Check the network connection and settings
(page 16).
2. Press HOME (
n
).
3. Select the [Premium] using
A/D
, and press
Center button.
4. Select an on-line service using
W/S/A/D
,
and press Center button.
y
Detailed information of each service,
contact to the content provider or visit
support link of the service.
y
The content of Premium services and
service related information, including user
interface, is subject to changes. Please refer
to the web site of each service for most up-
to-date information.
y
Using Premium features with wireless
network connection may result in improper
streaming speed by interference from
household devices that are using radio
frequencies.
y
When you are rst time to access [Premium]
or [LG Apps] feature, current country setting
appears. If you want to change the country
setting, select [Edit] and press Center
button.
,
Note
Operating 37
Operating
4
Using the LG Apps
You can use the LG application services on this
unit via Internet. You can easily nd and download
various applications from LG Apps store.
1. Check the network connection and settings
(page 16).
Depending on the region, LG Apps service
may not available at the moment. LG Apps
service will be opened for such regions by
software updates later.
2. Press HOME (
n
).
3. Select the [LG Apps] using
A/D
, and press
Center button.
4. Select a category using
A/D
, and press
Center button.
5. Use
W/S/A/D
to select an application, and
press Center button to display the information.
6. Press Center button while [Install] icon is
highlighted. The application will be installed to
the unit.
To install an application to the unit, user needs
to sign in. Refer to page 37 for more information
of signning in.
7. Press yellow (Y) colored button to display the
[My Apps] screen.
8. Select the installed application and press
Center button to excute it.
To install a paid application, you need to be
a paid member. Visit www.lgappstv.com for
more information.
,
Note
Signing in
To use the [LG Apps] feature, you need to sign in
with your account.
1. On the [LG Apps] or [My Apps] screen, press red
(R) colored button.
2. Fill the [ID] and [Password] eld using the virtual
keyboard.
If you do not have an account, press red (R)
colored button to register.
3. Use
W/S/A/D
to select [OK], and press
Center button to sign in with your account.
If you select the [Auto Sign In] check box,
your ID and password are remembered and
automatically signed in without entering them.
y
If you want to sign in with other account,
press red (R) colored button on [LG Apps] or
[My Apps] screen, and select [Change User]
option.
y
To view the information of your account and
applications, press red (R) colored button on
[LG Apps] or [My Apps] screen, and select
[Account Setting] option.
,
Note
Managing my Apps
You can move or delete an installed application in
the [My Apps] menu.
Move an application
1. Select an application, and press green (G)
colored button to display the options.
2. Use
W/S
to select [Move], and press Center
button.
3. Use
W/S/A/D
to select a position you want
to move to, and press Center button.
Delete an application
1. Select an application, and press green (G)
colored button to display the options.
2. Use
W/S
to select [Delete], and press Center
button.
3. Use
A/D
to select [Yes], and press Center
button to conrm.
Operating38
Operating
4
Using the Browser
Home
You can browser, search web pages using the web
browser feature over the Internet.
y
Web browser on this unit is dierent
with a web browser on your PC. The web
browser on this unit does not support
additional plug-ins and platform-dependant
technology such as ActiveX.
y
Compatible Flash version on this unit is up
to Flash 8.
y
Playing a movie on the web browser can be
restricted depending on a movie source.
y
The web browser will force quit when the
unit runs out of memory.
,
Note
1. Check the network connection and settings
(page 16).
2. Press HOME (
n
).
3. Select the [Web Browser] using
A/D
, and
press Center button.
4. Select an web page using
W/S/A/D
, and
press Center button.
Press
S
and
W/S/A/D
to select the
desired web page in the web browser menu.
Press Center button to enter the web page.
,
Note
About the Browser Home
menu
There are various options on the Browser Home
menu. Use
W/S/A/D
to select an option
and press Center button to select the options as
described below.
Options available within the browser menu include.
a URL – You can nd a web page entering a
web site address. The virtual keyboard will be
displayed and enter a web address.
b Favorites – You can directly open your
favorites web pages without entering web
address.
c History – Displays web address list of
previously opened web pages. Use
W/S
to
select a website address, and press Center
button to open the web page.
Press the red (R) colored button to clear
history.
Operating 39
Operating
4
Editing your favorite web
pages
In the Favorites menu , you can edit your favorites.
1. Press red (R) colored button to change the
highlighter to edit mode.
2. The highlighter color will be changed to green
color.
3. Select a web page and press Center button to
display the [Edit] menu.
4. Use
W/S
to select an option and press Center
button.
[Move] - Moves the web page to desired
position in the favorites menu.
[Rename] - Edits the selected web page name.
The virtual keyboard will be displayed.
[Delete] - Deletes the web page from favorites
menu.
[Close] - Exits the edit menu
Additional browser options
There are various options on the browser menu.
Press the corresponding remote buttons to use the
options. You can also move the pointer and click
the buttons to use the options.
a Returns to previous page.
b Returns to Browser Home menu.
c You can zoom in and out the currently
viewing page.
d Saves current page to your favorites web
page. The virtual keyboard will be displayed.
e Searches web pages from Google by
entering a keyword.
f Display the browser menu.
[
,//
] - Moves to the previous or next web
page.
[Refresh] - Reloads the current web page.
[Settings] - To clear the saved data such as
cookies and history, select this and select an
option from the menu.
Operating40
Operating
4
Playing content via
Media Link
You can enjoy music, photo, or video by installing
the PLEX application on your PC via home network.
y
To enjoy Media Link, install PLEX Midea
server version on the MAC or PC higher
than 0.9.1.14. (You can download it from
http://www.plexapp.com/medialink )
y
For the Thai, Arabic, Persian, Hebrew,
Kurdish, GUI language is shown in English,
carried data is not displayed it.
y
When plays the Video Plug-in, initial
buering may take a long time for the
unsupported media. Depending on the
ability of PC or network speed, the ability of
conversion operations on the PC may dier.
y
The le requirements are described on page
8.
y
Using Media Link with wireless network
connection may result in improper playback
quality by interference from household
devices that are using radio frequencies.
y
Your PC may not be recognized on this
unit depending on the router settings.
(Ex.: On some router, when setting “Multi
Cast forward“ function, your PC may not
be recognised on the unit with wireless
network connection.)
y
Since encoding format of character string is
supported only for UTF les, Text les that
are not UTF types may not be supported.
y
When you play the Saved les (Movie, TV
show, Music) on the PC, the supported
formats are MP4, ASF, WMV, MP3, WMA.
y
When playing the music le, fast forward
and backward playback is not supported.
,
Note
Mide Link connection
Check the network connection and settings (page
16).
1. Install PLEX application on your PC.
You can download it from http://www.plexapp.
com/medialink.
2. Run PLEX on your PC.
If it is rst run, you can set it easily through
WIZARD.
y
Local contents can always be revised
through Media Manager.
y
Web contents can be installed or deleted in
the online menu of the PLEX.
,
Note
Operating 41
Operating
4
Using the Media Link
1. Press HOME (
n
).
2. Select the [Media Link] using
W/S/A/D
,
and press Center button.
List of Media Link available PCs on your home
network are displayed.
3. Use
W/S/A/D
to select a PC and press
Center button to display the options as
described below.
a It is section list set on the connected PC. You
can enjoy media to section.
b Those are (plug- in) options. You can use on-
line content by operating the set plug-in.
c Selects other devices.
You can also use green (G) button on the
remote control.
d You can install, delete or update the desired
applications on your PC.
You can also use yellow (Y) button on the
remote control.
e Moves to the previous screen.
Using Movie section
You can watch movie or view movie information on
the movie section.
1. Press HOME (
n
).
2. Select the [Media Link] using
W/S/A/D
,
and press Center button.
3. Select an movie section using
A/D
, and press
Center button.
a Shows movie information you select.
b Shows the thumbnail of movies.
c Searches for a movie within the section.
You can also use red (R) button on the
remote control.
d Shows a reorganized list that matches your
property of selection. You can also use green
(G) button on the remote controller.
e Plays a movie in full screen. If you were
watching movie, it resumes playback.
f Moves to the previous screen.
You can also use BACK(
x
) on the remote
control.
Subtitle language is work depending on the
menu language.
,
Note
Operating42
Operating
4
Using Music section
You can listen to music or view the le information
on the music section.
1. Press HOME (
n
).
2. Select the [Media Link] using
W/S/A/D
,
and press Center button.
3. Select a music section using
A/D
, and press
Center button.
a Shows the list of music le in the music
section.
b Shows selected music information.
c Searches for music within the section. You
can also use red (R) button on the remote
control.
d Shows selected music.
e Shows a reorganized list that matches your
property of selection. You can also use green
(G) button on the remote control.
f Moves to the previous screen.
You can also use BACK(
x
) on the remote
control.
Using TV Program section
You can enjoy the TV program or view program
information on the TV program section.
1. Press HOME (
n
).
2. Select the [Media Link] using
W/S/A/D
,
and press Center button.
3. Select an TV program section using
A/D
, and
press Center button.
a Shows the list of TV programs in the TV
program section.
b Shows selected program information.
c Searches for TV program within the section.
You can also use red (R) button on the
remote control.
d Shows selected TV program.
e Shows a reorganized list that matches your
property of selection. You can also use green
(G) button on the remote controller.
f Moves to the previous screen.
You can also use BACK(
x
) on the remote
control.
Operating 43
Operating
4
Plug-in installation
You can enjoy a various media on the web by
installing the plug-in.
1. Press HOME (
n
).
2. Select the [Media Link] using
W/S/A/D
,
and press Center button.
3. Select a Plug-in section using
A/D
, and press
Center button.
a Shows available plug-in list.
b If you move the pointer to plug-in you want,
the information of plug-in will be displayed.
In case of installed plug-in: it can be run,
update, reinstalled or deleted.
In case of uninstalled plug-in: it can be
installed
The installed plug-ins can be run from the
video, music or picture plug-in.
c Moves to the previous screen.
You can also use BACK(
x
) on the remote
control.
Some plug-in may not work properly.
,
Note
5 Troubleshooting
Troubleshooting44
Troubleshooting
5
Troubleshooting
General
Symptom Cause & Solution
No Power.
y
Plug the power cord into the wall outlet securely.
Cannot play movie, photo or
audio les.
y
The les are not recorded in a format that the unit can play.
y
The unit does not support the codec of the video le.
The remote control does not
work properly.
y
The remote control is not pointed at the remote sensor of the unit.
y
The remote control is too far from the unit.
y
There is an obstacle in the path of the remote control and the unit.
y
The batteries in the remote control are exhausted.
y
We recommend using alkaline batteries.
The connected USB storage
device is not recognized.
y
Try another dierent USB cable, some of USB cable may not support
enough current for normal USB operation.
y
If you use a USB extension cable or USB HUB, the USB devices may not
be recognized.
y
An USB device which requires additional program installation when
you have connected it to a computer is not supported.
y
This unit supports only USB Flash Drive and USB External HDD with
FAT16, FAT32 or NTFS format.
Symptom Cause & Solution
There is no picture.
y
Select the appropriate video input mode on the TV so the picture
from the unit appears on the TV screen.
y
Check the [HDMI Color Setting] in the [Setup] menu is set to the
appropriate item that conforms to your video connection.
y
Your TV may not suppot the resolution you have set on the unit.
Change the resolution that your TV accepts.
y
The player’s HDMI OUT jack is connected to a DVI device that does
not support copyright protection.
Picture noise appears
y
Set the resolution which your TV accepts.
45
Troubleshooting
5
Troubleshooting
Resetting
Symptom Cause & Solution
You can reset the unit as
follows.
y
Press RESET button on the unit. This will force the unit to power o.
y
Unplug the power cord, wait at least ve seconds, and then plug it in
again.
Network
Symptom Cause & Solution
Streaming video services (such as
YouTube™, etc.) are often stopped
or “buer” during playback.
y
Your broadband service speed may not be fast enough to stream
video services. Contact your Internet Service Provider (ISP) and
increase the broadband speed is recommended.
Shared folder or les from your
PC or a media server are not
displayed on the device list.
y
The re wall or anti-virus software on your media server is running.
Turn o the re wall or anti-virus software running on your PC or
media server.
y
The unit is not connected to the local area network that your PC or
the media server are connected.
Cannot connect the unit to the
access point or wireless LAN
router.
y
The wireless communication may be interrupted from household
devices that are using radio frequencies. Move the unit away from
them.
Access point is not displayed on
the “Access point name” list.
y
The access point or wireless LAN router may not broadcast its SSID.
Set your access point to broadcast its SSID through your computer.
y
Your network device such as access point may not set with
available frequency range and channel that this unit can support.
Try setting the frequency range and channel on the network
device setting.
Customer Support
You can update the Unit using the latest software to enhance the products operation and/or add new
features. To obtain the latest software for this unit (if updates have been made), please visit
http://us.lgservice.com or contact LG Electronics customer care center.
Open source software notice
To obtain the corresponding source code under GPL, LGPL and other open source licenses, please visit
http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are
available to download with the source code.
6 Appendix
Appendix46
Appendix
6
Network Software
Update
Network update notification
From time to time, performance improvements
and/or additional features or services may be
made available to units that are connected to a
broadband home network. If there is new software
available and the unit is connected to a broadband
home network, the unit will inform you about the
update as follows.
Option 1:
1. The update menu will appear on the screen
when you turn on the unit.
2. Use
A/D
to select a desired option and then
press Center button.
[OK] Starts the software update.
[Cancel] Exits the update menu and
displays it next booting.
[Hide] Exits the update menu and
it does not appear until next
software is uploaded in the
update server.
Option 2:
If the software update is available from the update
server, the “Update” icon appears in the Home
menu. Press blue (B) colored button to start the
update procedure.
Software Update
You can update the unit using the latest software
to enhance the products operation and/or add
new features. You can update the software by
connecting the unit directly to the software update
server.
y
Before updating the software in your unit,
remove USB Device from the unit.
y
Before updating the software in your unit,
turn the unit o and then turn it back on.
y
During the software update procedure,
do not turn o the unit or disconnect AC
power, or do not press any button.
y
If you cancel the update, turn o the power
and turn it on for stable performance.
y
This unit cannot be updated to previous
software version.
,
Note
1. Check the network connection and settings
(page 16).
2. Select [Software] option in the [Setup] menu
then press Center button.
3. Select [Update] option, and press Center
button.
The unit will check for the newest update.
y
Pressing Center button while checking for
the update will end the process.
y
If there is no update available, the Message,
“No update is found.” appears. Press Center
button to return to the [Home Menu].
,
Note
4. If a newer version exists, the message “Do you
want to update?” appears.
5. Select [OK] to start update. (Selecting [Cancel]
will end the update.)
Do not turn o the power during the software
update.
>
Caution
Appendix 47
Appendix
6
6. When update is completed, the message,
“Update is complete.” will appear, and then
power will turn o automatically after 5
seconds.
7. Turn the power back on. The system now
operates with the new version.
The Software Update function may not
work properly depending on your internet
environment. In this case, you can obtain
the latest software from the authorized LG
Electronics Service Center then update your
unit. Refer to “Customer Support” on page 45.
,
Note
About Nero
MediaHome 4
Essentials
Nero MediaHome 4 Essentials is a software for
sharing video, audio and photo les stored on
your computer to this unit as a DLNA-compatiable
digital media server.
y
The Nero MediaHome 4 Essentials CD-
ROM is designed for PCs and should not be
inserted in this unit or in any product other
than a PC.
y
The supplied Nero MediaHome 4 Essentials
CD-ROM is a customized software edition
only for sharing les and folders to this unit.
y
The supplied Nero MediaHome 4 Essentials
software does not support following
functions: Transcoding, Remote UI, TV
control, Internet services and Apple iTunes
y
This manual explains operations with
the English version of Nero MediaHome
4 Essentials as examples. Follow the
explanation referring to the actual
operations of your language version.
,
Note
Installing Nero MediaHome 4
Essentials
Before you install Nero MediaHome 4 Essentials,
check the system requirement shown below.
y
Windows® XP (Service Pack 2 or higher), Windows
Vista® (no Service Pack required), Windows® XP
Media Center Edition 2005 (Service Pack 2 or
higher), Windows Server® 2003
y
Windows Vista® 64-bit edition (application runs
in 32-bit mode)
y
Windows® 7 64-bit edition (application runs in
32-bit mode)
y
Hard drive space: 200 MB hard drive space for a
typical installation of Nero MediaHome stand-
alone
y
1.2 GHz Intel® Pentium® III or AMD
Sempron™ 2200+ processors
y
Memory: 256 MB RAM
Appendix48
Appendix
6
y
Graphics card with at least 32 MB video memory,
minimum resolution of 800 x 600 pixels, and 16-
bit color settings
y
Windows® Internet Explorer® 6.0 or higher
y
DirectX® 9.0c revision 30 (August 2006) or higher
y
Network environment: 100 Mb Ethernet, WLAN
Start up your computer, and insert the supplied CD-
ROM disc into your computer’s CD-ROM drive. An
installation wizard will walk you through the quick
and uncomplicated installation process. To install
Nero MediaHome 4 Essentials, proceed as follows:
1. Close all Microsoft Windows programs and exit
any anti-virus software that may be running.
2. Insert the supplied CD-ROM disc into your
computer’s CD-ROM drive.
3. Click [Nero MediaHome 4 Essentials].
4. Click [Run] to start installation.
5. Click [Nero MediaHome 4 Essentials]. The
installation is prepared and the installation
wizard appears.
6. Click the [Next] button to display the serial
number input screen. Click [Next] to go to the
next step.
7. If you accept all conditions, click [I accept
the License Conditions] check box and click
[Next]. Installation is not possible without this
agreement.
8. Click [Typical] and click [Next]. The installation
process is started.
9. If you want to take part in the anonymous
collection of data, select the check box and click
the [Next] button.
10. Click the [Exit] button to complete the
installation.
Sharing files and folders
On your computer, you must share the folder
contained video, audio and/or photo content to
play them on this unit.
This parts explains the procedure for selecting the
shared folders on your computer.
1. Double-click the “Nero MediaHome 4 Essentials”
icon on the desktop.
2. Click [Network] icon on the left and dene your
network name in the [Network name] eld. The
Network name you enter will be recognized by
your unit.
3. Click [Shares] icon on the left.
4. Click [Local Folders] tab on the [Shares] screen.
5. Click [Add] icon to open the [Browse Folder]
window.
6. Select the folder containing the les you want
to share. The selected folder is added to the list
of shared folders.
7. Click [Start Server] icon to start the server.
y
If the shared folders or les are not displayed
on the unit, click the folder on the [Local
Folders] tab and click [Rescan Folder] at the
[More] button.
y
Visit www.nero.com for more information
and software tools
,
Note
Appendix 49
Appendix
6
Trademarks and
Licenses
HDMI, the HDMI logo and High-Denition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S.
and worldwide patents issued & pending. DTS,
the Symbol, & DTS and the Symbol together are
registered trademarks & DTS 2.0+Digital Out is a
trademark of DTS, Inc. Product includes software.
© DTS, Inc. All Rights Reserved.
DLNA®, the DLNA Logo and DLNA CERTIFIED® are
trademarks, service marks, or certication marks
of the Digital Living Network Alliance.
The Wi-Fi CERTIFIED Logo is a certication mark
of the Wi-Fi Alliance.
DivX®, DivX Certied® and associated logos
are trademark of DivX, Inc., and are used under
license
Appendix50
Appendix
6
Audio Output Specifications
Jack/Setting
Source
Digital Output (DIGITAL AUDIO OUT)
*
4
PCM Stereo
DTS Re-Encode
*
3
*
5
Primary Pass-Thru
Dolby Digital PCM 2ch DTS Dolby Digital
Dolby Digital Plus PCM 2ch DTS Dolby Digital
DTS PCM 2ch DTS DTS
Linear PCM 2ch PCM 2ch DTS PCM 2ch
Linear PCM 5.1ch PCM 2ch DTS PCM 2ch
Linear PCM 7.1ch PCM 2ch DTS PCM 2ch
Jack/Setting
Source
HDMI OUT
PCM Stereo
DTS Re-Encode
*
3
*
5
Primary Pass-Thru
*
1
*
2
*
3
Dolby Digital PCM 2ch DTS Dolby Digital
Dolby Digital Plus PCM 2ch DTS Dolby Digital Plus
DTS PCM 2ch DTS DTS
Linear PCM 2ch PCM 2ch DTS Linear PCM 2ch
Linear PCM 5.1ch PCM 2ch DTS Linear PCM 5.1ch
Linear PCM 7.1ch PCM 2ch DTS Linear PCM 7.1ch
*1 The secondary and interactive audio may not
be included in the output bitstream if [Digital
Output] or [HDMI] option is set to [Primary Pass-
Thru]. (Except LPCM Codec: the output always
include interactive and secondary audio.)
*2 This unit automatically selects the HDMI audio
according to the decoding capability of the
connected HDMI device even though [HDMI]
option is set to [Primary Pass-Thru].
*3 The [Primary Pass-Thru] setting of the [HDMI]
option and [DTS Re-Encode] setting of the
[Digital Output] option cannot be set together.
If you set them together, the [HDMI] or
[Digital Output] option is set to [PCM Stereo]
automatically.
*4 On the [Digital Output] audio output, the
sampling frequency of DIGITAL AUDIO OUT is
limited to 96 kHz.
*5 If the [HDMI] or [Digital Output] option is set to
[DTS re-encode], the audio output is limited to
48 kHz and 5.1Ch.
y
If [HDMI] option is set to [Digital Output] option
is set to [Primary Pass-Thru] while playback Dolby
Digital Plus or DIGITAL AUDIO OUT is limited to
“PCM 2ch”.
y
If the HDMI OUT jack is connected to your
TV with High Speed HDMI™ Cable and Dolby
Digital Plus is outputted from HDMI OUT jack,
DIGITAL AUDIO OUT jack is limited to “PCM 2ch”
(When the HDMI and DIGITAL AUDIO OUT are
connected simultaneously).
y
The audio is outputted as PCM 48 kHz/16 bit for
MP3/WMA le.
y
You must select a digital audio output and
a maximum sampling frequency that your
Amplier (or AV receiver) accepts using [Digital
Output], [HDMI] and [Sampling Freq.] options on
the [Setup] menu (see page 24).
y
If the audio format of the digital output does
not match the capabilities of your receiver, the
receiver will produce a strong, distorted sound
or no sound at all.
y
Multi-channel Digital Surround Sound via digital
connection can only be obtained if your receiver
is equipped with a Digital Multi-channel decoder.
Appendix 51
Appendix
6
Specifications
General
Power Supply
Refer to the main label or refer to the main label on the bottom
Power consumption
AC adapter DA-18B12
Dimensions (W x H x D) Approx. 110 x 110 x 29 mm (4.3 x 4.3 x 1.1 inches)
Net Weight (Approx.) 0.28kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL AUDIO OUT (OPTICAL) 3 V (p-p), Optical jack x 1
System
Signal system Standard NTSC color TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna)
Integrated IEEE 802.11n (5 GHz and 2.4 GHz bands) wireless
networking access, compatible with 802.11a/b/g Wi-Fi networks.
Bus Power Supply (USB) DC 5 V
0
500 mA
y
Design and specications are subject to change without notice.
Appendix52
Appendix
6
Maintenance
Handling the Unit
When shipping the unit
Please save the original shipping carton and
packing materials. If you need to ship the unit, for
maximum protection, re-pack the unit as it was
originally packed at the factory.
Keeping the exterior surfaces clean
y
Do not use volatile liquids such as insecticide
spray near the unit.
y
Wiping with strong pressure may damage the
surface.
y
Do not leave rubber or plastic products in
contact with the unit for a long period of time.
Cleaning the unit
To clean the unit, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not
use strong solvents such as alcohol, benzine, or
thinner, as these might damage the surface of the
unit.
Important Information
Relating to Network
Services
All information, data, documents, communications,
downloads, les, text, images, photographs,
graphics, videos, webcasts, publications, tools,
resources, software, code, programs, applets,
widgets, applications, products and other content
(“Content”) and all services and oerings (“Services”)
provided or made available by or through any
third party (each a “Service Provider”) is the sole
responsibility of the Service Provider from whom it
originated.
The availability of and access to Content and
Services furnished by the Service Provider through
the LGE Device are subject to change at any time,
without prior notice, including, but not limited to
the suspension, removal or cessation of all or any
part of the Content or Services.
Should you have any inquiry or problem related
to the Content or Services, you may refer to the
Service Provider’s website for the most up-to-
date information. LGE is neither responsible nor
liable for customer service related to the Content
and Services. Any question or request for service
relating to the Content or Services should be made
directly to the respective Content and Service
Providers.
Please note that LGE is not responsible for any
Content or Services provided by the Service
Provider or any changes to, removal of, or cessation
of such Content or Services and does not warrant
or guaranty the availability of or access to such
Content or Services.
