OWNER’S MANUAL
Mini Hi-Fi
System
OM5540
Please read this manual carefully before operating
your set and retain it for future reference.
www.lg.com
ةيبرعلا
ENGLISH
FOR THE GUARANTEE TERMS & CONDITIONS,
PLEASE REFER TO INNER PAGE OF BACK COVER.
OM5540-DB_DGBRLLK_ENG_3709.indd 1 2014-04-10 �� 5:07:23
1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with
arrowhead symbol within an
equilateral triangle is intended to
alert the user to the presence of
uninsulated dangerous voltage
within the product’s enclosure
that may be of sucient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: The apparatus should not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, should be placed on the
apparatus.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing the
product on a bed, sofa, rug or other similar surface.
This product should not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.
OM5540-DB_DGBRLLK_ENG_3709.indd 2 2014-04-10 �� 5:07:23
Getting Started 3
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
Disposal of your old appliance
1. When this crossed-out wheeled bin
symbol is attached to a product it
means the product is covered by
the European Directive 2002/96/EC.
2. All electrical and electronic products
should be disposed of separately
from the municipal waste stream
via designated collection facilities
appointed by the government or
the local authorities.
3. The correct disposal of your
old appliance will help prevent
potential negative consequences
for the environment and human
health.
4. For more detailed information about
disposal of your old appliance,
please contact your city office,
waste disposal service or the shop
where you purchased the product.
Disposal of waste batteries/accumulators
1. When this crossed-out wheeled
bin symbol is attached to batteries/
accumulators of Your product
it means they are covered by
European Directive 2006/66/EC.
2. This symbol may be combined with
chemical symbols for mercury(Hg),
cadmium(Cd) or lead(Pb) if the
battery Contains more that 0.0005%
of mercury,0.002% of cadmium or
0.004% of lead.
3. All batteries/accumulators should
be disposed separately from
the municipal waste stream via
designated collection facilities
appointed by the government or
the local authorities.
4. The correct disposal of Your old
batteries/accumulators will help
to prevent potential negative
consequences for the environment,
animal and human health.
5. For more detailed information
about disposal of Your old batteries/
accumulators, please contact Your
city office, waste disposal service or
the shop where You purchased the
product.
OM5540-DB_DGBRLLK_ENG_3709.indd 3 2014-04-10 �� 5:07:24
Getting Started4
Getting Started
1
LG Electronics hereby declares that this/these
product(s) is/are in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC, 2004/108/EC, 2006/95/EC,
2009/125/EC and 2011/65/EU.
Please contact to the following address for
obtaining a copy of the DoC (Declaration of
Conformity).
Contact oce for compliance of this product:
LG Electronics Inc.
EU Representative, Krijgsman 1,
1186 DM Amstelveen, The Netherlands
y
Please note that this is NOT a Customer Service
contact point. For Customer Service Information,
see Warranty Card or contact the dealer that you
purchased this product.
Indoor use only.
RF Radiation Exposure Statement
This equipment should be installed and operated
with minimum distance 20 cm between the
radiator and your body.
POWER: This unit operates on a mains supply
of 200-240V, 50/60Hz.
WIRING: This unit is supplied with a BS 1363
approved main plug. When replacing the
fuse, always use of the same rating approved
to BS 1362. Never use this plug with the fuse
cover omitted. To obtain a replacement fuse
cover contact your dealer. If the type of plug
supplied is not suitable for the mains sockets in
your home, then the plug should be removed
and a suitable type tted. Please refer to the
wiring instructions below:
WARNING: A mains plug removed from the
mains lead of this unit must be destroyed. A
mains plug with bared wires is hazardous if
inserted in a mains socket. Do not connect
either wire to the earth pin, marked with the
letter E or with the earth symbol
or coloured
green or green and yellow. If any other plug is
tted, use same rating of fuse in the plug.
IMPORTANT: The wires in this mains lead are
coloured in accordance with the following
codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the
colours of the wires in the mains lead of this
unit may not correspond with the coloured
marking identifying the terminals in your plug,
proceed as follows: The wire which is coloured
blue must be connected to the terminal which
is marked with the letter N or coloured black.
The wire which is coloured brown must be
connected to the terminal which is marked
with the letter L or coloured red.
OM5540-DB_DGBRLLK_ENG_3709.indd 4 2014-04-10 �� 5:07:24
Table of Contents 5
1
2
3
4
5
6
Table of Contents
1 Getting Started
2 Safety Information
6 Unique Features
6 Accessories
7 Playable file Requirement
7 – Music file requirement
7 – Compatible USB Devices
7 – USB device requirement
8 Remote control
10 Front panel
12 Rear panel
13 Use of Tripod
2 Connecting
15 Optional Equipment Connection
15 – AUX IN Connection
15 – PORT. IN Connection
16 – USB Connection
16 – Antenna Connection
3 Operating
17 Basic Operations
17 – Searching for a folder
18 – Deleting an MP3/WMA file
18 – AUTO DJ playback
19 – Programmed Playback
19 – Deleting Programmed list
20 Using a Bluetooth wireless technology
20 – Listening to music stored on the
Bluetooth devices
21 – Using Bluetooth App
24 Radio Operations
24 – Listening to the radio
24 – Improving poor FM reception
24 – Presetting the Radio Stations
24 – Deleting all the saved stations
24 – Seeing information about a Radio
station
25 Other Operations
25 – Turn off the sound temporarily
25 – Displaying file information
(ID3 TAG)
25 – DEMO
25 – Using Microphone
26 – Switching on and off the speaker light
26 Sound adjustment
26 – Setting the surround mode
27 – Setting the USER EQ
27 Setting the Clock
27 – Setting the Clock through “LG
Bluetooth Remote” App
28 – Using your player as an alarm clock
28 – Sleep Timer Setting
28 – Dimmer
28 – Auto power down
29 Advanced Operations
29 – Recording to USB
4 Troubleshooting
31 Troubleshooting
5 Appendix
32 General specifications
33 Maintenance
33 – Handling the Unit
33 Trademarks and Licenses
6 Warranty
35 Warranty
OM5540-DB_DGBRLLK_ENG_3709.indd 5 2014-04-10 �� 5:07:24
Getting Started6
Getting Started
1
Unique Features
Bluetooth
Listens to music stored on your bluetooth device.
Portable In
Listens to music from your portable device. (MP3,
Notebook, etc.)
USB Direct Recording
Records music to your USB device.
LG Bluetooth Remote
You can control this unit with your Android device
via Bluetooth. This unit and your device must be
paired for Bluetooth. Visit “Google Android Market
(Google Play Store)” or use the QR code shown
below to search for “LG Bluetooth Remote” app. For
detailed information, refer to page 21-23.
(Android OS)
Accessories
Please check and identify the supplied accessories.
Remote Control (1) Batteries (2)
FM Antenna (1)
OM5540-DB_DGBRLLK_ENG_3709.indd 6 2014-04-10 �� 5:07:24
Getting Started 7
Getting Started
1
Playable file
Requirement
Music file requirement
MP3/WMA le compatibility with this unit is limited
as follows.
y
File extensions : “.mp3”/ “.wma”
y
Sampling frequency : within 32 to 48 kHz (MP3),
within 32 to 48 kHz (WMA)
y
Bit rate : within 32 to 320 kbps (MP3),
40 to 192 kbps (WMA)
y
Maximum les : Under 999
y
Maximum folders : Under 99
Compatible USB Devices
y
MP3 Player : Flash type MP3 player.
y
USB Flash Drive :
Devices that support USB2.0 or USB1.1.
y
The USB function of this unit does not support
all USB devices.
USB device requirement
y
Devices which require additional program
installation when you have connected it to a
computer, are not supported.
y
Do not extract the USB device while in operation.
y
For a large capacity USB, it may take longer than
a few minute to be searched.
y
To prevent data loss, back up all data.
y
If you use a USB extension cable or USB hub, the
USB device is not recognized.
y
Using NTFS le system is not supported. (Only
FAT(16/ 32) le system is supported.)
y
This unit is not supported when the total
number of les is 1,000 or more.
y
External HDD, Card readers, Locked devices or
hard type USB devices are not supported.
y
USB port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
y
Some USB may not work with this unit.
OM5540-DB_DGBRLLK_ENG_3709.indd 7 2014-04-10 �� 5:07:25
Getting Started8
Getting Started
1
Remote control
Battery Installation
Remove the battery cover on the rear of the
Remote Control, and insert two (size AAA) batteries
with
4
and
5
matched correctly.
• • • • • • • • • •
a
• • • • • • • • •
1
(Power) : Switches the unit ON or OFF.
FUNCTION : Selects the function and input source.
PRESET·FOLDER
W
/
S
:
-
Searches for a folder of MP3/WMA les. When a
USB containing MP3/WMA les in several folders
is being played, press PRESET·FOLDER
W
/
S
to
select the folder you want to play.
-
Chooses a preset number for a radio station.
SOUND EFFECT : Chooses sound impressions.
MUTE
@
: Mutes the sound.
VOL +/- : Adjusts speaker volume.
PROGRAM/MEMORY :
-
Stores radio stations.
-
Creates a playlist you want to listen to.
USB REC : USB direct recording.
SLEEP : Sets the system to turn off automatically at
a specified time.
(Dimmer : The display window will be darkened by
half.)
OM5540-DB_DGBRLLK_ENG_3709.indd 8 2014-04-10 �� 5:07:25
Getting Started 9
Getting Started
1
• • • • • • • • • •
b
• • • • • • • • •
REPEAT (MENU) : Listens to your les repeatedly or
randomly.
TUNING-/+ : Selects the radio stations.
C
/
V
:
-
Skips Fast backward or Forward.
-
Searches for a section within a le.
Z
ENTER :
-
Stops playback or recording.
-
Cancels DELETE function.
d
/
M
:
-
Starts or pauses playback.
INFO : Sees informations about your music. An MP3
le often come with ID3 tag. The tag gives the Title,
Artist, Album or Time information.
AUTO DJ : Selects the AUTO DJ mode. (For more
information refer to the page 18)
DELETE :
-
Deletes MP3/WMA les.
-
Deletes a song on Programmed playback list.
• • • • • • • • • •
c
• • • • • • • • •
0 to 9 numerical buttons : Selects numbered les
or preset number.
CLOCK : For setting the clock and checking the
time.
ALARM : With the ALARM function you can turn
USB play and TUNER reception on at a desired time.
• • • • • • • • • •
d
• • • • • • • • •
RDS/SET :
-
RDS (Radio Data System).
-
Conrms the clock and the alarm setting.
PTY : Searches radio stations by radio type.
OM5540-DB_DGBRLLK_ENG_3709.indd 9 2014-04-10 �� 5:07:25
Getting Started10
Getting Started
1
Front panel
a
b
c
d
e
f
m
n
o
k
g
i
j
l
h
OM5540-DB_DGBRLLK_ENG_3709.indd 10 2014-04-10 �� 5:07:25
Getting Started 11
Getting Started
1
a
Display window
b
MIC 1/2 jack
MIC VOL.
PORT. IN jack
c
1
/
!
(Power)
d
MASTER VOLUME
Adjusts speaker volume.
e
AUTO DJ/RDS
- Selects the AUTO DJ mode. (For more
informaion refer to the page 18)
- RDS (Radio Data System).
f
X-FLASH LED
g
NFC allows you to install and open “LG
Bluetooth Remote” app to NFC-enabled phone.
h
Remote control receiver
i
T
Starts or pauses playback.
I
Stops playback or cancels DELETE function.
Y/U
- Skips Fast backward or Forward.
- Searches for a section within a le.
j
USB 1/2 Port
You can play or record sound files by
connecting the USB device.
k
USB REC
Records to USB.
l
FILE SEARCH
Selects a file on USB function.
m
BASS/MIDDLE/TREBLE
Adjusts the sound level when setting USER EQ.
n
BASS BLAST
Selects the BASS BLAST or BYPASS sound
directly.
o
FUNCTION
Selects the function and input source.
USER EQ/DEMO
- Controls sound register.
- Shows demo.
X-FLASH/SET
- Selects a X-FLASH mode.
- Conrms the setting.
OM5540-DB_DGBRLLK_ENG_3709.indd 11 2014-04-10 �� 5:07:25
Getting Started12
Getting Started
1
Rear panel
c
b
d
a
a
Power cord
b
Vent Hole
c
AUX IN connectors (L/R)
d
ANTENNA (FM)
OM5540-DB_DGBRLLK_ENG_3709.indd 12 2014-04-10 �� 5:07:25
Getting Started 13
Getting Started
1
Use of Tripod
You can mount the unit on a tripod.
The tripod is optional purchase.
y
Extend the tripod legs as much as possible
and tighten up the screw securely.
y
Before connecting with the unit, you must
x a tripod hard for not shaking.
>
Caution
1. Put down the unit to connect with the tripod.
2. After setting the tripod, insert a top of a
recommended tripod to a hole underneath the
unit.
Safety pin
Use the safety pin for xing center column all
the time.
>
Caution
3. Fix the unit to the tripod with the screw.
Tighten up the screw underneath the unit.
4. Make the tripod stand upright carefully.
When you make the tripod stand upright,
you hold a body of the unit for avoiding unit’s
toppling.
OM5540-DB_DGBRLLK_ENG_3709.indd 13 2014-04-10 �� 5:07:26
Getting Started14
Getting Started
1
y
If you use a tripod, use the tripod only for
speaker.
y
Before buying a tripod, check the
specications for maximum bearing load
of the center column.
(Unit’s net weight : about 16.5 kg)
(B)
(A)
35 mm
y
Use tripod as below :
(A) From tripod’s center to tripod’s leg :
above 530 mm
(B) From top of tripod to bottom of tripod :
below 780 mm
(C) Tripod net weight : over 2.5 kg
y
Use a tripod as low as possible for safety
use.
y
You should pull the center column to the
maximum only in case of need.
y
Mount only one unit on each tripod.
y
Do not try to extent the tripod legs
outside over its allowed range.
y
Make sure the tripod is correctly
assembled and all its components are
tightly connected.
y
Do not try to assemble the tripod if parts
are missing or defective.
y
After installation, check whether the unit is
xed rmly on the tripod or not.
y
Do not place the unit on an unstable
position where it might accidentally fall
over.
y
Add weight such as sand bags around the
tripod legs to prevent them from falling
over.
,
Note
y
You should limit people around the
unit while using this unit with tripod.
Otherwise it may result in malfunction
and causing personal injury or property
damage.
y
Standing on the stool to reach unit control
panel is risky and might lead to injuries.
y
Do not put or attach other objects on the
tripod.
y
Do not shake or push the unit when the
tripod is installed.
y
Refrain from moving around the tripod
after unit is installed.
y
Remove the units from all connected
cables of the tripods before moving the
tripods or adjusting their height.
y
When transporting or moving the unit,
always use two or more people.
y
When you use the tripod, use an extension
cord. Always be careful the movement of
cable.
y
It is prohibited to use this unit outside.
(Indoor use only)
y
Do not expose the unit to excessive
dust or vibrations, or extreme cold or
heat (such as in direct sunlight, near a
heater) to prevent the possibility of panel
disguration or damage to the internal
components.
y
When using the external input cable (Mic,
etc.) after installing the unit on the tripod,
external input cable can cause the unit to
fall down.
y
Watch out the people can trip over the
input cable (Mic, etc.) connected the unit.
y
Always be careful of the unit being
tripped.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 14 2014-04-10 �� 5:07:26
2 Connecting
Connecting 15
Connecting
2
Optional Equipment
Connection
AUX IN Connection
Connect an output of auxiliary device(Camcoder,
TV, Player, etc.) to the AUX IN (L/R) connector.
If your device has only one output for audio(mono),
connect it to the left (white) audio jack on the unit.
Audio cable
DVD, Blu-ray player, etc.
Rear panel
PORT. IN Connection
Connect an output (earphone or line out) of
portable device (MP3 or PMP, etc.) to the
PORT. IN connector.
Portable cable
MP3 player, etc.
Listening to music from your
portable player or external device
The unit can be used to play the music from many
types of portable player or external device.
1. Connect the portable player to the PORT. IN
connector of the unit.
Or
Connect the external device to the AUX IN
connector of the unit.
2. Turn the power on by pressing
1
on the
remote control or
1
/
!
on the unit.
3. Select the PORTABLE or AUX function by
pressing FUNCTION.
4. Turn on the portable player or external device
and start it playing.
If it is get over input than the input spec
(Refer to page 32), the unit might be o
automatically to protect itself.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 15 2014-04-10 �� 5:07:27
Connecting16
Connecting
2
USB Connection
Connect a USB device (or MP3 player, etc.) to the
USB ports on the unit.
USB device
Removing the USB device from the unit :
1. Choose a different function/mode or
press
Z
ENTER on the remote control
or
I
on the unit twice in a row.
2. Remove the USB device from the unit.
,
Note
Antenna Connection
Connect the supplied FM antenna for listening to
the radio.
Connect the FM wire antenna to the FM antenna
connector.
FM antenna
Rear panel
Be sure to fully extend the FM wire antenna.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 16 2014-04-10 �� 5:07:27
3 Operating
Operating 17
Operating
3
Basic Operations
1. Connect the USB device to the USB port.
2. Select the USB function by pressing FUNCTION
on the remote control or on the unit.
To Do this
Stop
Press
Z
ENTER on the remote
control or
I
on the unit.
Playback
Press
d
/
M
on the remote control
or
T
on the unit.
Pause
Press
d
/
M
on the remote control
or
T
on the unit during playback.
Searching
for a section
within a le
Press
C
/
V
on the remote
control or
Y
/
U
on the unit
during playback and release it at
the point you want to listen to.
Selecting a
le directly
Press 0 to 9 numerical buttons on
the remote control to go to the
desired le directly.
Skipping to
the next/
previous le
During playback,
(1) By using
C
/
V
buttons :
Press
C
/
V
to go to the next
le or to return to the beginning of
the current le.
Press
C
twice briey to step
back to the previous le.
(2) By using FILE SEARCH knob :
Rotate FILE SEARCH and press
d
/
M
to play the le.
Playing
repeatedly or
randomly
Press REPEAT(MENU) on the
remote control repeatedly, the
display will be changed in the
following order.
RPT1 -> RPT DIR -> RPT ALL ->
RANDOM -> OFF
*DIR : Directory
y
When you play Program list, only RPT 1 and
RPT ALL are available.
y
Even after restarting the unit or switching
one function to another, you can listen to
music from the point where it’s last been
played.
,
Note
Searching for a folder
1. Press PRESET·FOLDER
W
/
S
on the remote
control repeatedly until a desired folder appears
in the display window.
2. Press
d
/
M
to play it. The first file of the folder
will be played.
y
USB Folders/Files are recognized as below.
FOLDER1
ROOT
FOLDER3
FOLDER4
FOLDER2
FOLDER7
FOLDER8
FOLDER5
FOLDER6
FILE 5
FILE 6
FILE 7
FILE 8
FILE 9
FILE 10
FILE 3
FILE 4
FILE 11
FILE 12
FILE 13
FILE 14
FILE 1
FILE 2
FOLDER
FILE
y
If there is no le in a folder, the folder will
not appear.
y
Folders will be presented as the following
order;
ROOT
FOLDER 1 FOLDER 3 FOLDER
7 FOLDER 8 FOLDER 5 FOLDER 6
y
File will be played from
$
le No.1 to
$
le
No.14 one by one.
y
Files and folders will be presented in order
recorded and may be presented dierently
according to the record circumstances.
y
*ROOT : The rst screen you can see when a
computer recognize the USB is “ROOT”.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 17 2014-04-10 �� 5:07:27
Operating18
Operating
3
Deleting an MP3/WMA file
You can delete file, folder or format by pressing
DELETE. This function is supported only in stop
status. (USB only)
1. Select the file you want to delete and press
DELETE on the remote control.
Press and hold DELETE to format the USB
device.
Or
Press DELETE repeatedly during selecting the
MP3/WMA file.
The display changes in the following order.
- DEL FILE : Deletes file
- DEL DIR : Deletes folder
- FORMAT : Formats USB
2. To delete file/folder or format, press
d
/
M
on the
remote control or press
T
on the unit.
3. If you want to exit the current mode, press
Z
ENTER on the remote control or press
I
on
the unit.
y
Do not extract the USB device during
operation. (play, delete, etc.)
y
Regular back up is recommended to
prevent data loss.
y
The delete function may not be supported
according to the USB status. (lock etc.)
>
Caution
AUTO DJ playback
Auto DJ blends the end of one song into the
beginning of another for seamless playback. It
equalizes volume across les for uninterrupted
playback.
Press AUTO DJ on the remote control or AUTO DJ/
RDS on the unit repeatedly, the display changes
as followings. RANDOM (AUTO DJ RANDOM) ->
REPEAT ALL (AUTO DJ SEQUENTIAL) -> (AUTO DJ
OFF)
Mode
Display
Window
Description
OFF
-
(AUTO DJ OFF)
-
RANDOM
RANDOM
(AUTO DJ
RANDOM)
The music is
played randomly
on this mode.
REPEAT
RPT
(AUTO DJ
SEQUENTIAL)
The music is
played repeatedly
on this mode.
y
It is not supported on the AUTO DJ mode
to search for a section within a le or to play
repeatedly or randomly.
y
If you move to other functions or stop the
music using
I
on the unit (or
Z
ENTER on
the remote control) on AUTO DJ mode,
AUTO DJ function will be disable.
y
AUTO DJ function is not supported in the
music le whose length is less than 60
seconds.
y
During recording, AUTO DJ function is not
available.
y
Only AUTO DJ SEQUENTIAL is selected
when played Program list.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 18 2014-04-10 �� 5:07:28
Operating 19
Operating
3
Programmed Playback
The Program function enables you to make a
playlist of your favourite les from the USB device.
A playlist of up to 20 les can be entered for each
media. (USB1,USB2) Possible to save a total of 40
les.
1. Press PROGRAM/MEMORY on the remote
control in stop status.
2. Press
C
/
V
on the remote control to select
a file.
3. Press PROGRAM/MEMORY to save and select a
next file.
4. Repeat steps 2-3 to store other files.
(You can modify the list by pressing
PRESET·FOLDER
W
/
S
to select the program
number.)
5. Press PROGRAM/MEMORY once again.
To play the programmed list, press
d/M
after you
make the list.
When making or modifying the programmed
list, REPEAT mode is o.
,
Note
Deleting Programmed list
Deleting function is worked only on the edit mode.
1. Press PROGRAM/MEMORY on the remote
control in stop status.
2. Select a song by pressing PROGRAM/MEMORY
or PRESET·FOLDER
W
/
S
repeatedly.
3. Press DELETE while a song is selected.
y
Programmed list is cleared in the case
below.
-
Removing the USB device.
-
Deleting or recording music les in the
USB device.
y
Program is switched o in the case below.
-
Changing the function to the others.
-
Turning o and on the unit.
-
Operating the numeric buttons on the
remote control.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 19 2014-04-10 �� 5:07:28
Operating20
Operating
3
Using a Bluetooth
wireless technology
About Bluetooth
Bluetooth® is wireless communication technology
for short range connection.
The sound may be interrupted when the
connection interfered by the other electronic wave
or you connect the bluetooth in the other rooms.
Connecting individual devices under Bluetooth®
wireless technology does not incur any charges. A
mobile phone with Bluetooth® wireless technology
can be operated via the Cascade if the connection
was made via Bluetooth® wireless technology.
Available Devices : Mobile phone, MP3, Laptop,
PDA.
Bluetooth Profiles
In order to use Bluetooth® wireless technology,
devices must be able to interpret certain proles.
This unit is compatible with following prole.
A2DP (Advanced Audio Distribution Prole)
Listening to music stored on
the Bluetooth devices
Before you start the pairing procedure, make
sure the Bluetooth feature is turned on in to your
Bluetooth device. Refer to your Bluetooth device’s
user guide. Once a pairing operation is performed,
it does not need to be performed again.
1. Select the Bluetooth function by using the
FUNCTION.
“BT READY” appears on the display window.
2. Operate the Bluetooth device and perform the
pairing operation. When searching for this unit
with the Bluetooth device, a list of the devices
found may appear in the Bluetooth device
display depending on the type of Bluetooth
device. Your unit appears as “LG MINI(XX:XX)” .
XX:XX means the last four digits of BT address.
For example, if your unit has a BT address
such as 9C:02:98:4A:
F7:08
, you will see “LG
MINI(
F7:08
)” on your Bluetooth device.
,
Note
3. Enter the PIN code.
PIN code : 0000
4. When this unit is successfully connected with
your Bluetooth device, “BT PAIR” will appear on
the display window and bluetooth indicator will
be lit up.
Depending on the Bluetooth device type,
some device have a dierent pairing way.
,
Note
5. Listen to music.
To play a music stored on your Bluetooth device,
refer to your Bluetooth device’s user guide.
According to your mobile phone’s volume level,
the volume level of Bluetooth will be adjusted.
y
Sound from the main set can be distorted
if you raise the volume of Bluetooth device
up to two-thirds or more.
y
When you use the bluetooth function,
adjust the volume of a bluetooth device to
a proper level to listen to.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 20 2014-04-10 �� 5:07:28
Operating 21
Operating
3
y
When using Bluetooth® technology, you
have to make a connection between the
unit and the bluetooth device as close as
possible and keep the distance.
However it may not work well in the case
below :
-
There is a obstacle between the unit and
the bluetooth device.
-
There is a device using same frequency
with Bluetooth® technology such as a
medical equipment, a microwave or a
wireless LAN device.
y
You should connect your Bluetooth device
to this unit again when you restart it.
y
The sound may be interrupted when
the connection interfered by the other
electronic wave.
y
You cannot control the Bluetooth device
with this unit.
y
Pairing is limited one Bluetooth device per
one unit and multi-pairing is not supported.
y
Depending on the type of the device,
you may not be able to use the Bluetooth
function.
y
You can enjoy wireless system using phone,
MP3, Notebook, etc.
y
When not connected the Bluetooth, “BT” and
“BT READY” appears on the control panel.
y
When someone stands and interrupts
communication between Bluetooth device
and the player, the connection will be
disconnected.
y
The more distant between the unit and
the bluetooth device, the lower the sound
quality becomes.
y
When Bluetooth connection is
disconnected, connect the bluetooth device
to the unit again.
,
Note
Using Bluetooth App
Only Android OS is available to use
“LG Bluetooth remote” app with this unit.
,
Note
About “LG Bluetooth Remote” App
“LG Bluetooth Remote” app brings a suite of new
features to this unit.
To enjoy more features, you are recommended to
download and install free “LG Bluetooth Remote”
app.
Install “LG Bluetooth Remote” App
onto Your Bluetooth Device
1. Install “LG Bluetooth Remote” app through QR
code. Use the scanning software to scan the QR
code.
(Android OS)
2. Tap an icon for installation.
3. Tap an icon for downloading.
y
Make sure that your Bluetooth device is
connected to the Internet.
y
Make sure that your Bluetooth device has a
scanning software application. If you don’t
have one, download one from “Google
Android Market. (Google Play Store)”
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 21 2014-04-10 �� 5:07:28
Operating22
Operating
3
Install “LG Bluetooth Remote” App
through “Google Android Market
(Google Play Store)”
1. Tap the “Google Android Market (Google Play
Store)” icon.
2. In the search bar, type in the “LG Bluetooth
Remote” and search it.
3. In the search result list, find and tap “LG
Bluetooth Remote” to start downloading
Bluetooth app.
4. Tap an icon for installation.
5. Tap an icon for downloading.
y
Make sure that your Bluetooth device is
connected to the Internet.
y
Make sure that your Bluetooth device is
equipped with “Google Android Market
(Google Play Store)”.
,
Note
Install “LG Bluetooth Remote” App
through NFC
NFC allows you to install and open “LG Bluetooth
Remote” app to NFC-enabled phone.
1. Activates the NFC feature of your NFC-enabled
phone.
2. Turn on the unit.
3. Tag the back of your NFC-enabled phone over
the unit.
-
If “LG Bluetooth Remote” app is not installed on
your NFC-enabled phone, the linked screen with
“LG Bluetooth Remote“ app is displayed.
y
You must activate the NFC feature of your
NFC-enabled phone.
y
If your NFC-enabled phone’s screen is
locked, it will not read the NFC.
y
If your smart phone case is plated with
chrome, NFC is unavailable. Depending on
your case’s material or thickness, NFC may
not be read well.
y
If “LG Bluetooth Remote” app is already
installed in your NFC-enabled phone, it will
display the screen for choosing to activate
“LG Bluetooth Remote” app.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 22 2014-04-10 �� 5:07:28
Operating 23
Operating
3
Activate Bluetooth with “LG
Bluetooth Remote” App
“LG Bluetooth Remote” app helps to connect your
bluetooth device to this unit.
1. Tap “LG Bluetooth Remote” app icon on the
home screen to open “LG Bluetooth Remote”
app and go to the main menu.
2. Tap [Setting] and select the unit you want.
3. If you want to get more information to operate,
tap [Setting] and [Help].
y
BT app will be available in the software
version as follow;
- Android O/S : Ver 2.3.3 (or later)
y
This unit does not support the multi-pairing.
If this unit is already connected with other
Bluetooth device, disconnect that device
and then try again.
y
If you use “LG Bluetooth Remote” app for
operation, there would be some dierences
between “LG Bluetooth Remote” app and
the supplied remote control. Use the
supplied remote control as necessary.
y
Depending on the Bluetooth device, “LG
Bluetooth Remote” app may not work.
y
The connection you’ve made may be
disconnected if you select other application
or change the setting of the connected
device via “LG Bluetooth Remote” app. In
such a case, please check the connection
status.
y
After connection of Bluetooth app, music
may be output from your device. In this
case, try connecting procedure again.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 23 2014-04-10 �� 5:07:28
Operating24
Operating
3
Radio Operations
Be sure that FM antenna is connected.
(Refer to the page 16)
Listening to the radio
1. Press FUNCTION until FM appears in the display
window.
The last received station is tuned in.
2. Auto tuning :
Press and hold TUNING-/+ on the remote
control or
Y/U
on the unit for about two
seconds until the frequency indication starts to
change, then release. Scanning stops when the
unit tunes in a station.
Or
Manual tuning :
Press TUNING-/+ on the remote control or
Y/U
on the unit repeatedly.
3. Adjust the volume by rotating volume knob on
the unit or by pressing VOL +/- on the remote
control repeatedly.
Improving poor FM reception
Adjust the antenna to improve the reception when
the radio has poor reception.
Presetting the Radio Stations
You can preset 50 stations for FM.
Before tuning, make sure to turn down the volume.
1. Press FUNCTION until FM appears in the display
window.
2. Press TUNING-/+ on the remote control or
Y
/
U
on the unit to select a desired
frequency.
3. Press PROGRAM/MEMORY. A preset number
will blink in the display window.
4. Press PRESET·FOLDER
W
/
S
to select the
preset number you want.
5. Press PROGRAM/MEMORY. The station is
stored.
6. Repeat steps 2 to 5 to store other stations.
7. To listen a preset station, press PRESET·FOLDER
W
/
S
or 0 to 9 numerical buttons.
Deleting all the saved stations
1. Press and hold PROGRAM/MEMORY for two
seconds.
“ERASEALL” will flash up on the unit display.
2. Press PROGRAM/MEMORY to erase all the
saved radio stations.
Seeing information about a
Radio station
The FM tuner is supplied with the RDS (Radio Data
System) facility. This shows information about the
radio station being listened to. Press RDS/SET
repeatedly to cycle through the various data
types:
PS (Programme Service Name)
The name of the channel will appear in
the display.
PTY (Programme Type Recognition)
The programme type (e.g. Jazz or News)
will appear in the display.
RT (Radio Text)
A text message contains special
information from the broadcast station.
This text may scroll across the display.
CT (Time controlled by the channel)
This shows the time as broadcast by the
station.
You can search the radio stations by programme
type by pressing RDS/SET. The display will show
the last PTY in use. Press PTY one or more times to
select your preferred programme type. Press and
hold
C
/
V
. The tuner will search automatically.
When a station is found the search will stop.
OM5540-DB_DGBRLLK_ENG_3709.indd 24 2014-04-10 �� 5:07:28
Operating 25
Operating
3
Other Operations
Turn off the sound temporarily
Press MUTE
@
on the remote control to mute
your sound.
You can mute your unit, for example, to answer the
telephone, the “MUTE” will appear in the display
window.
To cancel it, press MUTE
@
again or change the
volume level.
Displaying file information
(ID3 TAG)
While playing an MP3 le containing le
information, you can display the information by
pressing INFO.
DEMO
In the power o state, it demonstrates the function
on display window and a display by pressing
USER EQ/DEMO.
To cancel the DEMO, press it again.
y
While DEMO, this unit will keep DEMO
status even if you unplug the power cord
connection.
y
You can enjoy other functions during
the DEMO. Then the DEMO will pause to
temporary.
-
Without input key in 10 sec, the DEMO will
play back automatically.
,
Note
Using Microphone
It is available on the function as follows :
USB, Bluetooth, AUX, Portable-In, FM.
1. Connect your microphone to the MIC jack.
2. Play the music you want.
3. Sing along with the accompaniment. Adjust
the microphone volume by rotating MIC VOL.
clockwise or unclockwise on the unit.
y
When not using the microphone, set the
MIC VOL. to minimum or turn o the MIC
and remove the microphone from the
MIC jack.
y
If the microphone is set too near the
speaker, a howling sound may be produced.
In this case, move the microphone away
from the speaker or decrease the sound
level by using the MIC VOL.
y
If sound through the microphone is
extremely loud, it may be distorted. In this
case, rotate MIC VOL. to minimum.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 25 2014-04-10 �� 5:07:28
Operating26
Operating
3
Switching on and off the
speaker light
You can select various types of the speaker light by
pressing X-FLASH/SET on the unit.
Press X-FLASH/SET on the unit repeatedly, the
speaker lightening changes as followings. Red LED
Lighting -> Red LED Off, White LED Blinking -> Red
LED Lighting, White LED Blinking -> OFF
Step Lighting Description
OFF - -
Step1
Red LED Lighting,
White LED O
Depending on the
beat, the Red LED
is blinking.
Step2
Red LED Off,
White LED
Blinking
Regardless of the
beat, the White
LED is blinking.
Step3
Red LED Lighting,
White LED
Blinking
Depending on the
beat, the Red LED
is blinking.
Regardless of the
beat, the White
LED is blinking.
y
The RED LED may not work properly
according to Low Input level or connected
external device. (Low Volume, Device Type,
Play sound source, connection mode, etc.)
y
The RED LED is the LED lights up only
during operation. (playback, USB playback,
Radio Listening and other external input)
,
Note
Sound adjustment
Setting the surround mode
This system has a number of pre-set surround
sound elds. You can select a sound mode you
want by using SOUND EFFECT on the remote
control.
The displayed items for the Equalizer may be
dierent depending on sound sources and eects.
On Display Description
NATURAL
You can enjoy comfortable and
natural sound.
Local
Specialization
equalizer
(Optional)
Regionally optimized sound
eect. (FORRO/FUNK/
SERTANEJO/DANGDUT/ARABIC/
PERSIAN/INDIA/REGUETON/
MERENGUE/SALSA/SAMBA/
CUMBIA/AFRO)
AUTO EQ
Realizes the sound equalizer that
is the most similar to the genre
of which is included in the MP3
ID3 tag of song les.
POP
CLASSIC
JAZZ
ROCK
This program lends an
enthusiastic atmosphere to the
sound, giving you the feeling
you are at an actual pop, classic,
jazz or rock concert.
MP3 - OPT
This function is optimized
for compressible MP3 le. It
improves the treble sound.
BASS BLAST
Reinforces the treble, bass and
surround sound eect.
LOUDNESS
Improves the bass and treble
sound.
FOOT BALL
This program lends an
atmosphere to the sound,
giving you the feeling you are in
football stadium.
BYPASS
You can enjoy the sound
without equalizer eect.
OM5540-DB_DGBRLLK_ENG_3709.indd 26 2014-04-10 �� 5:07:28
Operating 27
Operating
3
y
On some speakers, sound may not be heard
or heard in low sound depending on the
sound mode.
y
By pressing BASS BLAST on the unit you
can directly select the BYPASS or
BASS BLAST sound.
,
Note
Setting the USER EQ
You can listen to music with equalizer by adjusting
the sound level yourself.
1. Press USER EQ/DEMO. “USER EQ” is displayed.
2. Turn the BASS, MIDDLE and TREBLE knobs to
adjust the sound level.
3. To finish the setting, press X-FLASH/SET on the
unit.
Turning the knobs clockwise increases the
level, counterclockwise decreases the level.
,
Note
Setting the Clock
1. Turn the unit on.
2. Press and hold CLOCK.
3. Select time mode by pressing
C/V
on
the remote control.
- AM 12:00 (for an AM and PM display) or 0:00
(for a 24 hour display)
4. Press RDS/SET to confirm your selection.
5. Select the hours by pressing
C/V
on the
remote control.
6. Press RDS/SET.
7. Select the minutes by pressing
C/V
on
the remote control.
8. Press RDS/SET.
Setting the Clock through “LG
Bluetooth Remote” App
Install “LG Bluetooth Remote” app on your Android
device. (see page 21 - 23)
Your unit’s clock will be automatically synchronized
with your device by activating Bluetooth
connection through “LG Bluetooth Remote” app.
OM5540-DB_DGBRLLK_ENG_3709.indd 27 2014-04-10 �� 5:07:29
Operating28
Operating
3
Using your player as an alarm
clock
1. Turn the unit on.
2. Press and hold ALARM.
3. Press
C/V
on the remote control to
change the hours and minutes and press RDS/
SET to save.
4. Press
C/V
on the remote control to
select function and press RDS/SET to save.
5. Press
C/V
on the remote control to
change the volume and press RDS/SET to save.
The clock icon “
(
“ shows that the alarm.
y
If you set the clock time, you can check the
time by pressing CLOCK even when the
player is turned o.
y
If you set the clock time and alarm, you
can check the alarm icon “
(
“ by pressing
CLOCK even when the player is turned o.
y
If you set the clock time and alarm, you
can check the alarm icon “
(
“ and setting
information by pressing ALARM even when
the unit is turned o.
y
Press ALARM, you can selects a ALARM
on mode.
,
Note
Sleep Timer Setting
Press SLEEP repeatedly to select delay time
between 10 and 180 minutes. After the delay time,
the unit will be turned o.
To cancel the sleep function, press SLEEP
repeatedly until “SLEEP 10” appears, and then press
SLEEP once again while “SLEEP 10” is displayed.
y
You can check the remaining time before
the unit is turned o.
y
Press SLEEP. The remaining time appears in
the display window.
,
Note
Dimmer
Press SLEEP once. The display window will
be darkened by half. To cancel it, press SLEEP
repeatedly until dim o.
Auto power down
This unit will turn o itself to save electric
consumption in the case were main unit is not
connected to external device and is not used for 20
minutes.
So does this unit after six hours since Main unit has
been connected to other device using analogue
input.
OM5540-DB_DGBRLLK_ENG_3709.indd 28 2014-04-10 �� 5:07:29
Operating 29
Operating
3
Advanced Operations
Recording to USB
You can record a various sound source to USB.
(USB, AUX, PORTABLE, FM)
1. Connect the USB device to the unit.
2. Select a function in which you want to record
by pressing FUNCTION.
One file recording - You can record to USB after
playing a file you want.
All files recording - You can record to USB after
stop.
Programmed Playback list recording - After
showing Programmed Playback list, you can
record it to USB.
(Refer to the page 19)
3. Start the recording by pressing USB REC on the
remote control or USB REC on the unit.
- If you connect both USB1 and USB2, press
USB REC on the remote control or
USB REC on the unit when USB1 or USB2
which you want to record blinks in the display
window.
4. To stop recording, press
I
on the unit or
Z
ENTER on the remote control.
You can record various sound using Mic.
Output may dier depending on the Mic
volume.
(Only TUNER, AUX, PORTABLE)
,
Note
Pausing recording
During recording, press
d
/
M
on the remote
control or
T
on the unit to pause recording. Press
it again to restart recording.
(Only TUNER, AUX, PORTABLE)
To select recording bit rate
1. Press USB REC on the unit or USB REC on
the remote control for longer than 3 seconds.
2. Press
C
/
V
on the remote control or
Y
/
U
on the unit to select a bit rate.
3. Press USB REC on the unit or USB REC on
the remote control to finish the setting.
Dubbing USB to USB
You can do dubbing a various sound source in
USB1 to USB2 on USB function.
1. Connect a USB device including desired sound
files to USB1.
2. Connect another USB device to USB2.
3. Press USB REC on the unit or USB REC on
the remote control.
4. To stop recording, press
I
on the unit or
Z
ENTER on the remote control.
The making of unauthorized copies of copy-
protected material, including computer
programs, les, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal oense.
This equipment should not be used for such
purposes.
Be responsible
Respect copyrights
OM5540-DB_DGBRLLK_ENG_3709.indd 29 2014-04-10 �� 5:07:29
Operating30
Operating
3
y
It is not supported to record music stored
on bluetooth device.
y
During recording MP3/WMA, there is no
sound.
y
You cannot record in AUTO DJ mode.
y
When you stop recording during playback,
the le that has been recorded at that time
will be stored. (Except MP3/WMA les)
y
Do not remove the USB device or turn o
the unit during USB recording. If does not,
an incomplete le may be made and not
deleted on PC.
y
If USB recording does not work, the
message like “NO USB”, “ERROR”, “USB FULL”
or “NO REC” is displayed on the display
window.
y
Multi card reader device or External HDD
can not be used for USB recording.
y
A le is recorded by about 512 Mbyte when
you record for a long term.
y
You may not store more than 999 les.
y
It’ll be stored as follows.
MP3/WMA
The other source* TUNER
TUNER : The current recording frequency is
shown.
* : AUX, PORTABLE and the like.
,
Note
OM5540-DB_DGBRLLK_ENG_3709.indd 30 2014-04-10 �� 5:07:29
4 Troubleshooting
Troubleshooting 31
Troubleshooting
4
Troubleshooting
Problem Cause & Solution
No Power.
y
The power cord is not plugged in. Plug in the power cord.
y
Check whether electricity failed.
Check the condition by operating other electronic devices.
No sound.
y
Check whether you select right function.
Press FUNCTION and check the selected function.
The unit does not work
properly.
y
Turn o the power of this unit and the connected external device (TV, Woofer,
DVD-player, Amplier, etc.) and turn it on again.
y
Disconnect the power cord of this unit and the connected external device (TV,
Woofer, DVD-player, Amplier, etc.) and then try connecting again.
Radio stations cannot
be tuned in properly.
y
The antenna is positioned or connected poorly.
Connect the antenna securely.
y
The signal strength of the radio station is too weak.
Tune to the station manually.
y
No stations have been preset or preset stations have been cleared. (When
tuning by scanning preset channels)
Preset some radio stations, see page 24 for details.
The remote control
does not work
properly.
y
The remote control is too far from the unit.
Operate the remote control within about 23 ft (7 m).
y
There is an obstacle in the path of the remote control and the unit.
Remove the obstacle.
y
The batteries in the remote control are exhausted.
Replace the batteries with new ones.
No speaker light
y
Check the speaker light eects by pressing X-FLASH/SET.
OM5540-DB_DGBRLLK_ENG_3709.indd 31 2014-04-10 �� 5:07:29
5 Appendix
Appendix32
Appendix
5
General specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) 395.5 mm x 548 mm x 446 mm
Net Weight (Approx.) 16.5 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) 5 V
0
500 mA
Inputs
AUX IN 1.2 Vrms (1 kHz, 0 dB, 600 Ω, RCA jack, L/R)
PORT. IN 0.8 Vrms (3.5 Ø jack)
Mic 25 mV
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier
Total 330 W
Front Mono 330 W (at 1 kHz, 4 Ω)
THD 20 %
y
Design and specications are subject to change without notice.
OM5540-DB_DGBRLLK_ENG_3709.indd 32 2014-04-10 �� 5:07:29
Appendix 33
Appendix
5
Maintenance
Handling the Unit
When shipping the unit
Please save the original shipping carton and
packing materials. If you need to ship the unit, for
maximum protection, re-pack the unit as it was
originally packed at the factory.
Keeping the exterior surfaces clean
Do not use volatile liquids such as insecticide spray
near the unit. Wiping with strong pressure may
damage the surface. Do not leave rubber or plastic
products in contact with the unit for a long period
of time.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not
use strong solvents such as alcohol, benzine, or
thinner, as these might damage the surface of the
unit.
Trademarks and
Licenses
Bluetooth® wireless technology is a system which
allows radio contact between electronic devices.
Connecting individual devices under Bluetooth®
wireless technology does not incur any charges.
A mobile phone with Bluetooth® wireless
technology can be operated via the Cascade if
the connection was made via Bluetooth® wireless
technology.
The Bluetooth® word mark and logos are owned
by the Bluetooth® SIG, Inc. and any use of such
marks by LG Electronics is under license.
Other trademarks and trade names are those of
their respective owners.
OM5540-DB_DGBRLLK_ENG_3709.indd 33 2014-04-10 �� 5:07:29
6 Warranty
Warranty
OM5540-DB_DGBRLLK_ENG_3709.indd 34 2014-04-10 �� 5:07:29
Warranty 35
Warranty
6
6 Warranty
Warranty
Technology with the human touch
GUARANTEE
• LG Electronics U.K. Ltd. will provide the following services in order to expedite this Guarantee.
1. All faulty components which fail due to defective manufacture will be replaced free of charge for a
period of 12 months from the original date of purchase.
2. The dealer (or his service agent) who sold the product will be
reimbursed for any labour provided in the repair of this LG equipment, for a period of 12 months from
the original date of purchase. These claims must be made in accordance with the published scale of
service charges and relevant claims procedure.
PLEASE NOTE:
A. The dealer may restrict the guarantee to the original purchaser.
B. The dealer is not obliged to carry out service under guarantee if unauthorized modifications are made
to the apparatus, or if non standard components are used or if the serial number of the apparatus is
removed, defaced, misused, or altered.
C. Any claims made under guarantee must be directed to the dealer from whom the equipment was
originally purchased. The dealer may, before carrying out service under guarantee, require a receipted
account as evidence of the date of purchase.
D.
We respectfully point out that your dealer is not obligated to replace batteries if they become
exhausted or worn in use.
E. Aerial alignment and consumer control adjustments are not covered by this guarantee.
This guarantee does not affect your statutory rights.
• REQUIREMENTS TO MAINTAIN WARRANTY COVERAGE:
RETAIN YOUR RECEIPT TO PROVE DATE OF PURCHASE. A COPY OF YOUR RECEIPT MUST BE
SURRENDERED AT THE TIME GUARANTEE SERVICE IS PROVED.
• Product Registration Card :
It is helpful to complete at least your name, address, phone, model & serial numbers and return it. This
will enable LG to assist you in the future should you lose your receipt, your units be stolen, or should
modifications be necessary.
• To obtain information or assistance: Call 0870 873 5454
MODEL NO.* SERIAL NO.* DATE OF PURCHASE.*
In all cases of diculty - consult your LG dealer from whom the product was purchased
LGEUK Website : www.lg.com/uk
( service website : www.lg.com/uk/support )
OM5540-DB_DGBRLLK_ENG_3709.indd 35 2014-04-10 �� 5:07:30
OM5540-DB_DGBRLLK_ENG_3709.indd 36 2014-04-10 �� 5:07:30
