KVLDE40X
EN Microwave combi-oven User Manual
CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................5
3. PRODUCT DESCRIPTION................................................................................ 8
4. CONTROL PANEL............................................................................................. 8
5. BEFORE FIRST USE......................................................................................... 9
6. DAILY USE......................................................................................................... 9
7. CLOCK FUNCTIONS....................................................................................... 11
8. USING THE ACCESSORIES........................................................................... 13
9. ADDITIONAL FUNCTIONS.............................................................................. 13
10. HINTS AND TIPS........................................................................................... 14
11. CARE AND CLEANING..................................................................................31
12. TROUBLESHOOTING....................................................................................32
13. ENERGY EFFICIENCY.................................................................................. 33
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away unless continuously supervised.
• Children of less than 3 years of age should be kept
away unless continuously supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
• Only a qualified person must install this appliance and
replace the cable.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
ENGLISH 3
• Always use oven gloves to remove or put in
accessories or ovenware.
• Before carrying out any maintenance, disconnect the
appliance from the power supply.
• Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
scratch the surface, which may result in shattering of
the glass.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Do not activate the appliance when it is empty. Metal
parts inside the cavity can create electric arcing.
• Metallic containers for food and beverages are not
allowed during microwave cooking. This requirement
is not applicable if the manufacturer specifies size and
shape of metallic containers suitable for microwave
cooking.
• If the door or door seals are damaged, the appliance
must not be operated until it has been repaired by a
qualified person.
• Only a qualified person can carry out any service or
repair operation that involves the removal of a cover
which gives protection against exposure to microwave
energy.
• Do not heat liquids and other foods in sealed
containers. They are liable to explode.
• Only use utensils that are suitable for use in
microwave ovens.
• When heating food in plastic or paper containers, keep
an eye on the appliance due to the possibility of
ignition.
www.electrolux.com4
• The appliance is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and
similar may lead to risk of injury, ignition or fire.
• If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
• Microwave heating of beverages can result in delayed
eruptive boiling. Care must be taken when handling
the container.
• The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature
checked before consumption, in order to avoid burns.
• Eggs in their shell and whole hard-boiled eggs should
not be heated in the appliance since they may
explode, even after microwave heating has ended.
• The appliance should be cleaned regularly and any
food deposits removed.
• Failure to maintain the appliance in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly
result in a hazardous situation.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Keep the minimum distance from
other appliances and units.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
ENGLISH 5
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance complies with the
E.E.C. Directives.
2.3 Use
WARNING!
Risk of injury, burns and
electric shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and
air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not use microwave function to
preheat the oven.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make
sure the door is never closed when
the appliance is in operation. Heat
and moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
www.electrolux.com6
close the furniture panel until the
appliance has cooled down
completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Make sure the cavity and the door are
wiped dry after each use. Steam
produced during the operation of the
appliance condensates on cavity walls
and can cause corrosion.
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Fat and food remaining in the
appliance can cause fire and electric
arcing when the microwave function
operates.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, follow the
safety instruction on it's packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.5 Internal lighting
WARNING!
Risk of electric shock.
• The type of light bulb or halogen lamp
used for this appliance is for
household appliances only. Do not
use it for house lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.6 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
ENGLISH 7
3. PRODUCT DESCRIPTION
3.1 General overview
1 3 642 5
12
4
3
1
2
10
11
7
8
9
1
Control panel
2
Power lamp / symbol
3
Knob for the heating functions
4
Display
5
Temperature and microwave power
indicator / symbol
6
Control knob
7
Heating element
8
Microwave generator
9
Lamp
10
Fan
11
Shelf support, removable
12
Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
4. CONTROL PANEL
4.1 Buttons
Sensor field / Button Function Description
MICROWAVE To set the microwave function. Hold it
for more than 3 seconds to turn on or
turn off the oven lamp. You can turn on
the light also when the oven is turned
off.
CLOCK To set a clock function.
TEMPERA‐
TURE
To check the oven temperature or the
temperature of the core temperature
sensor (if applicable). Use only while
the heating function operates.
www.electrolux.com8
4.2 Display
A B C
EH FG D
A. Timer / Temperature / Microwave
power
B. Heat-up and residual heat indicator
C. Microwave mode
D. Core temperature sensor (selected
models only)
E. Door lock (selected models only)
F. Hours / minutes
G. Demo mode (selected models only)
H. Clock functions
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
To set the Time of day refer
to "Clock functions" chapter.
5.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the oven.
Refer to "Care and cleaning" chapter.
Clean the oven and the accessories
before the first use.
Put the accessories and the removable
shelf supports back to their initial
position.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 Retractable knobs
To use the appliance press the knob.
The knob comes out.
6.2 Heating functions
Oven func‐
tion
Application
Off position
The oven is off.
Fast Heat Up
To decrease the heat-
up time.
Oven func‐
tion
Application
Microwave
Creates the heat direct‐
ly in the food. Use it to
heat pre-prepared
meals and drinks, to de‐
frost meat or fruit, and
to cook vegetables and
fish.
True Fan
Cooking
To bake on up to two
shelf positions at the
same time and to dry
food.
Set the temperature 20
- 40 °C lower than for
Conventional Cooking.
Pizza Setting
To bake pizza. To make
intensive browning and
a crispy bottom.
ENGLISH 9
Oven func‐
tion
Application
Conventional
Cooking
(Top / Bottom
Heat)
To bake and roast food
on one shelf position.
Bottom Heat
To bake cakes with
crispy bottom and to
preserve food.
Defrost
To defrost food (vegeta‐
bles and fruit). The de‐
frosting time depends
on the amount and size
of the frozen food.
Grilling
To grill flat food and to
toast bread.
Turbo Grilling
To roast larger meat
joints or poultry with
bones on one shelf po‐
sition. To make gratins
and to brown.
The lamp may turn off
automatically at a
temperature below 60 °C
during some oven functions.
6.3 Setting a heating function
1. Turn the knob for the heating
functions to select a heating function.
2. Turn the control knob to select the
temperature / the microwave power.
The lamp turns on when the oven
operates.
3. To turn off the oven, turn the knob for
the heating functions to the off
position.
6.4 Setting the function:
Microwave
1. Remove all accessories.
2. Turn the knob for the heating
functions to select the function:
Microwave .
Do not let the oven operate when there is
no food in it.
The display shows first a default
microwave power and then a default time
for: Duration.
Press to start with the default values
for microwave power and for: Duration.
You can also wait few seconds for the
oven to start automatically without
pressing the button.
3. Turn the control knob to change the
microwave power. The power setting
changes in 100 Watt steps.
4. Press and then turn the control
knob to change:Duration.Press
again and again to change: Duration
and microwave power. Turn the
control knob to set the value and
press
to confirm.
5. You can change or check microwave
power setting while the function
Microwave is running.Press: .
When the time set for Duration ends, the
signal sounds and the oven stops.
6. Turn the knob for the heating
functions to the off position.
When you open the oven
door, the oven stops. To
start it again, close the door
and press .
The maximum time of microwave
functions depends on microwave power
you set:
MICROWAVE
POWER
MAXIMUM TIME
100 - 600 W -
More than 600 W 7 minutes
6.5 Setting the function:
Microwave Combi
You can combine the microwave function
with any of the heating functions.
1. Turn the knob for the heating
functions to select the function.
The display shows a default temperature.
2. Turn the control knob to change the
temperature.
www.electrolux.com10
3. Press to combine heating function
with the microwave mode.
4. Turn the control knob to change the
microwave power settings. The
power setting changes in 100 Watt
steps.
Around 5 degrees before the set
temperature is reached the signal
sounds. When the set time for Duration
ends the signal sounds again and the
oven stops.
5. Turn the knob for the heating
functions to the off position.
When you use the Microwave
function in Combi mode the
Microwave power cannot be more
than 600 W.
While using Microwave
Combi function the oven
can make various
noises. They are normal
for this function.
6.6 Fast Heat Up
The fast heat up decreases the heat up
time.
Do not put food in the oven
when the Fast heat up
operates.
1. Turn the knob for the oven functions
to set the fast heat up.
2. Turn the knob for the temperature to
set the temperature.
The signal sounds when the oven is at
the set temperature.
3. Set an oven function.
6.7 Heat-up indicator
When the oven function operates, the
bars in the display
appear one by one
when the temperature in the oven
increases, and disappear when it
decreases.
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock func‐
tion
Application
TIME OF
DAY
To show or change the
time of day. You can
change the time of day
only when the oven is
off.
DURATION
To set how long the
oven works. Use only
when a heating function
is set.
END
To set when the oven
turns off. Use only when
a heating function is set.
TIME DELAY
Combination of DURA‐
TION and END function.
Clock func‐
tion
Application
MINUTE
MINDER
Use to set a countdown
time. This function has
no effect on the opera‐
tion of the oven. You
can set the MINUTE
MINDER at any time, al‐
so if the oven is off.
7.2 Setting and changing the
time
After the first connection to the mains,
wait until the display shows and
"12:00". "12" flashes.
1. Turn the knob for the temperature to
set the hours.
2. Press to confirm and set the
minutes.
ENGLISH 11
The display shows and the set
hour. "00" flashes.
3. Turn the knob for the temperature to
set the current minutes.
4. Press to confirm or the set time of
day will be saved automatically after
5 seconds.
The display shows the new time.
To change the time of day press
again and again until the indicator for the
time of day
flashes in the display.
7.3 Setting the DURATION
function
1. Set a heating function.
2. Press
again and again until
starts to flash.
3. Turn the knob for the temperature to
set the minutes and press to
confirm. Turn the knob for the
temperature to set the hours and
press to confirm.
When the set Duration time ends the
signal sounds for 2 minutes. and
time setting flash in the display. The
oven turns off automatically.
4. Press any button or open the oven
door to stop the signal.
5. Turn the knob for the heating
functions to the off position.
7.4 Setting the END function
1. Set a heating function.
2. Press again and again until
starts to flash.
3. Turn the knob for the temperature to
set the hours and press
to
confirm. Turn the knob for the
temperature to set the minutes and
press to confirm.
At the set End time the signal sounds for
2 minutes. and time setting flash in
the display. The oven turns off
automatically.
4. Press any button or open the oven
door to stop the signal.
5. Turn the knob for the heating
functions to the off position.
7.5 Setting the TIME DELAY
function
1. Set a heating function.
2. Press
again and again until
starts to flash.
3. Turn the knob for the temperature to
set the minutes for DURATION time
and press to confirm. Turn the
knob for the temperature to set the
hours for DURATION time and press
to confirm.
The display shows flashing
.
4. Turn the knob for the temperature to
set the hours for END time and press
to confirm. Turn the knob for the
temperature to set the minutes for
END time and press to confirm.
The display shows and the
set temperature.
Oven turns on automatically later on,
works for the set DURATION time and
stops at the set END time.
At the set END time the signal sounds for
2 minutes.
and time setting flash in
the display. The oven turns off.
5. Press any button or open the oven
door to stop the signal.
6. Turn the knob for the heating
functions to the off position.
7.6 Setting the MINUTE
MINDER
Minute minder can be both set when the
oven is turned on and off.
1. Press again and again until
starts to flash.
2. Turn the knob for the temperature to
set the seconds and than the
minutes.
When the time you set is longer than
60 minutes, flash in the display.
3. Set the hours.
4. The MINUTE MINDER starts
automatically after 5 seconds.
After 90% of the set time the signal
sounds.
5. When the set time ends the signal
sounds for 2 minutes. "00:00" and
www.electrolux.com12
flash in the display. Press any button
to stop the signal.
8. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
8.1 Inserting the accessories
Use only suitable cookware and material.
WARNING!
Refer to "Hints and tips"
chapter, Microwave suitable
cookware and materials.
Wire shelf:
Push the shelf between the guide bars of
the shelf support and make sure that the
feet point down.
Baking tray:
Push the baking tray between the guide
bars of the shelf support.
Wire shelf and baking tray together:
Push the baking tray between the guide
bars of the shelf support and the wire
shelf on the guide bars above.
Small indentation at the top
increase safety. The
indentations are also anti-tip
devices. The high rim
around the shelf prevents
cookware from slipping of
the shelf.
9. ADDITIONAL FUNCTIONS
9.1 Using the Child Lock
When the Child Lock is on the oven
cannot be turned on accidentally.
1. Ensure the knob for the oven
functions is in the off position.
2. Press and hold
and at the
same time for 2 seconds.
The signal sounds. SAFE appears on the
display.
To turn off the Child Lock, repeat step 2.
9.2 Using the Function Lock
You can turn on the Function Lock
function only when the oven operates.
When the Function lock is on the
temperature and time settings of a
running oven function cannot be
changed accidentally.
1. Select an oven function and set it
according your preferences.
2. Press and hold
and at the
same time for 2 seconds.
ENGLISH 13
The signal sounds. Loc appears on the
display for 5 seconds.
Loc appears on the display
when you turn the knob for
the temperature or press any
button when the Function
lock is on.
When you turn the knob for the oven
functions, the oven stops.
When you turn off the oven while the
Function Lock is on, the Function Lock
switches automatically to the Child Lock.
Refer to "Using the Child Lock".
To turn off the Function Lock, repeat step
2.
9.3 Residual heat indicator
When you turn off the oven, the display
shows the residual heat indicator
if
the temperature in the oven is more than
40 °C.Turn the knob for the temperature
left or right to check the oven
temperature.
9.4 Automatic Switch-off
For safety reasons the oven turns off
automatically after some time if a heating
function operates and you do not change
the oven temperature.
Temperature (°C) Switch-off time
(h)
30 - 115 12.5
120 - 195 8.5
200 - 230 5.5
After an automatic switch-off, press any
button to operate the oven again.
The Automatic switch-off
does not work with the
functions: Light, Duration,
End.
9.5 Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continues
to operate until the oven cools down.
10. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They
depend on the recipes and
the quality and quantity of
the ingredients used.
10.1 Cooking recommendations
Your oven may bake or roast differently
to the oven you had before. The below
tables provide you with the standard
settings for temperature, cooking time
and shelf position.
If you cannot find the settings for a
special recipe, look for the similar one.
10.2 Microwave
recommendations
Place the food on a plate on the bottom
of the cavity.
Turn or stir the food halfway through the
defrosting and cooking time.
Cover the food for cooking and
reheating.
Put the spoon to the bottle or glass when
heating drinks to ensure better heat
distribution.
Put the food into the oven without any
packaging. The packaged ready meals
can be put into the oven only when the
packaging is microwave safe (check
information on the packaging).
www.electrolux.com14
Microwave cooking
Cook food covered. If you want to keep a
crust cook food without a cover.
Do not overcook the dishes by setting
the power and time too high. The food
can dry out, burn or cause fire.
Do not use the oven to cook eggs or
snails in their shells, because they can
burst. Pierce the yolk of fried egg before
reheating it.
Pierce food with skin or peel with a fork
several times before cooking.
Cut vegetables into similar-sized pieces.
Stir liquid dishes from time to time.
Stir the food before serving.
After you turn off the oven, take the food
out and let it stand for a few minutes.
Microwave defrosting
Put the frozen, unwrapped food on a
small upturned plate with a container
below it, or on a defrosting rack or plastic
sieve so that the defrosting liquid can run
off.
Remove defrosted pieces subsequently.
To cook fruit and vegetables without
defrosting them first, you can use a
higher microwave power.
10.3 Microwave suitable cookware and materials
For the microwave use only suitable cookware and materials. Use below table as
a reference.
Cookware / Material Microwave function Microwave Combi
function
Defrost‐
ing
Heating,
Cooking
Ovenproof glass and porcelain with
no metal components, e.g. heat-
proof glass
Non-ovenproof glass and porcelain
without any silver, gold, platinum or
other metal decorations
X X
Glass and glass ceramic made of
ovenproof / frost-proof material
Ceramic and earthenware without
any quartz or metal components
and glazes which contain metal
X
Ceramic, porcelain and earthen‐
ware with unglazed bottom or with
small holes, e.g. on handles
X X X
Heat-resistant plastic up to 200 °C
(please always check the plastic
container specification before use)
X
Cardboard, paper X X
Clingfilm X X
Roasting film with microwave safe
closure (please always check the
film specification before use)
X
ENGLISH 15
Cookware / Material Microwave function Microwave Combi
function
Defrost‐
ing
Heating,
Cooking
Roasting dishes made of metal,
e.g. enamel, cast iron
X X
Baking tins, black lacquer or sili‐
con-coated (please always check
the baking tins specification before
use)
X X
Baking tray X X X
Wire shelf X X
Cookware for microwave use, e.g.
crisp pan
X X
10.4 Baking
• Use the lower temperature the first
time.
• You can extend baking times by 10 –
15 minutes if you bake cakes on more
than one shelf position.
• Cakes and pastries at different
heights do not always brown equally.
There is no need to change the
temperature setting if an unequal
browning occurs. The differences
equalize during baking.
• Trays in the oven can twist during
baking. When the trays become cold
again, the distortions disappear.
10.5 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake
is not browned suffi‐
ciently.
The shelf position is incor‐
rect.
Put the cake on a lower shelf.
The cake sinks and
becomes soggy, lumpy
or streaky.
The oven temperature is
too high.
The next time you bake, set a
slightly lower oven temperature.
The baking time is too
short.
Set a longer baking time. You
cannot decrease baking times
by setting higher temperatures.
There is too much liquid in
the mixture.
Use less liquid. Be careful with
mixing times, especially if you
use a mixing machine.
The cake is too dry. The oven temperature is
too low.
The next time you bake, set a
higher oven temperature.
The baking time is too
long.
The next time you bake, set a
shorter baking time.
www.electrolux.com16
Baking results Possible cause Remedy
The cake browns un‐
evenly.
The oven temperature is
too high and the baking
time is too short.
Set a lower oven temperature
and a longer baking time.
The mixture is unevenly
distributed.
Spread the mixture evenly on
the baking tray.
The cake is not ready
in the baking time giv‐
en.
The oven temperature is
too low.
The next time you bake, set a
slightly higher oven tempera‐
ture.
10.6 Baking on one oven level
Baking in tins
Food Function Temper‐
ature
(°C)
Time (min) Shelf posi‐
tion
Ring cake or brioche True Fan
Cooking
150 - 160 50 - 70 1
Madeira cake / Fruit
cakes
True Fan
Cooking
140 - 160 70 - 90 1
Sponge cake / Sponge
cake
True Fan
Cooking
140 - 150 35 - 50 1
Sponge cake / Sponge
cake
Top / Bottom
Heat
160 35 - 50 2
Flan base - short pas‐
try
1)
True Fan
Cooking
170 - 180 10 - 25 1
Flan base - sponge
mixture
True Fan
Cooking
150 - 170 20 - 25 1
Apple pie / Apple pie (2
tins Ø 20 cm, diagonal‐
ly off set)
True Fan
Cooking
160 70 - 90 1
Apple pie / Apple pie (2
tins Ø 20 cm, diagonal‐
ly off set)
Top / Bottom
Heat
180 70 - 90 1
Cheesecake, tray
2)
Top / Bottom
Heat
160 - 170 60 - 90 1
1)
Preheat the oven.
2)
Use a deep pan.
ENGLISH 17
Cakes / pastries / breads on baking trays
Food Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Plaited bread / bread
crown
Top / Bottom
Heat
170 - 190 30 - 40 2
Christmas stollen
1)
Top / Bottom
Heat
160 - 180 50 - 70 2
Bread (rye bread)
1)
Top / Bottom
Heat
2
first 230 20
then 160 - 180 30 - 60
Cream puffs / Eclairs
1)
Top / Bottom
Heat
190 - 210 20 - 35 2
Swiss Roll
1)
Top / Bottom
Heat
180 - 200 10 - 20 2
Cake with crumble top‐
ping (dry)
True Fan
Cooking
150 - 160 20 - 40 1
Buttered almond cake /
sugar cakes
1)
Top / Bottom
Heat
190 - 210 20 - 30 2
Fruit flans (made with
yeast dough / sponge
mixture)
2)
True Fan
Cooking
150 - 160 35 - 55 1
Fruit flans (made with
yeast dough / sponge
mixture)
2)
Top / Bottom
Heat
170 35 - 55 1
Fruit flans made with
short pastry
True Fan
Cooking
160 - 170 40 - 80 1
Yeast cakes with deli‐
cate toppings (e.g.
quark, cream, cus‐
tard)
1)
Top / Bottom
Heat
160 - 180 40 - 80 2
1)
Preheat the oven.
2)
Use a deep pan.
Biscuits
Food Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Short pastry biscuits True Fan
Cooking
150 - 160 10 - 20 1
Short bread / Short
bread / Pastry Stripes
True Fan
Cooking
140 20 - 35 1
www.electrolux.com18
Food Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Short bread / Short
bread / Pastry
Stripes
1)
Top / Bottom
Heat
160 20 - 30 2
Biscuits made with
sponge mixture
True Fan
Cooking
150 - 160 15 - 20 1
Pastries made with
egg white, meringues
True Fan
Cooking
80 - 100 120 - 150 1
Macaroons True Fan
Cooking
100 - 120 30 - 50 1
Biscuits made with
yeast dough
True Fan
Cooking
150 - 160 20 - 40 1
Puff pastries
1)
True Fan
Cooking
170 - 180 20 - 30 1
Rolls
1)
Top / Bottom
Heat
190 - 210 10 - 25 2
Small cakes / Small
cakes
1)
True Fan
Cooking
160 20 - 35 3
Small cakes / Small
cakes
1)
Top / Bottom
Heat
170 20 - 35 2
1)
Preheat the oven.
10.7 Bakes and gratins
Food Function Temperature
(°C)
Time (min) Shelf position
Pasta bake Top / Bottom
Heat
180 - 200 45 - 60 1
Lasagne Top / Bottom
Heat
180 - 200 25 - 40 1
Vegetables au
gratin
1)
Turbo Grilling 160 - 170 15 - 30 1
Baguettes top‐
ped with mel‐
ted cheese
True Fan Cook‐
ing
160 - 170 15 - 30 1
Sweet bakes Top / Bottom
Heat
180 - 200 40 - 60 1
Fish bakes Top / Bottom
Heat
180 - 200 30 - 60 1
ENGLISH 19
Food Function Temperature
(°C)
Time (min) Shelf position
Stuffed vegeta‐
bles
True Fan Cook‐
ing
160 - 170 30 - 60 1
1)
Preheat the oven.
10.8 Multilevel baking
Use the function True Fan Cooking.
Cakes / pastries / breads on baking trays
Food Temperature (°C) Time (min) Shelf posi‐
tion
Cream puffs /
Eclairs
1)
160 - 180 25 - 45 1 / 3
Dry streusel cake 150 - 160 30 - 45 1 / 3
1)
Preheat the oven.
Biscuits / small cakes / pastries / rolls
Food Temperature (°C) Time (min) Shelf posi‐
tion
Short pastry biscuits 150 - 160 20 - 40 1 / 3
Short bread / Short
bread / Pastry Stripes
140 25 - 45 1 / 3
Biscuits made with
sponge mixture
160 - 170 25 - 40 1 / 3
Pastries made with
egg white, meringues
80 - 100 130 - 170 1 / 3
Macaroons 100 - 120 40 - 80 1 / 3
Biscuits made with
yeast dough
160 - 170 30 - 60 1 / 3
10.9 Pizza Setting
Food Temperature (°C) Time (min) Shelf position
Pizza (thin crust)
1)
200 - 230 15 - 20 3
Pizza (with a lot of top‐
ping)
2)
180 - 200 20 - 30 3
Tarts 180 - 200 40 - 55 3
Spinach flan 160 - 180 45 - 60 3
www.electrolux.com20
Food Temperature (°C) Time (min) Shelf position
Quiche Lorraine (Sa‐
voury flan)
170 - 190 45 - 55 3
Swiss Flan 170 - 190 45 - 55 3
Cheesecake 140 - 160 60 - 90 3
Apple cake, covered 150 - 170 50 - 60 3
Vegetable pie 160 - 180 50 - 60 3
Unleavened bread
1)
230 10 - 20 3
Puff pastry flan
1)
160 - 180 45 - 55 3
Flammekuchen
1)
230 12 - 20 3
Piroggen (Russian ver‐
sion of calzone)
1)
180 - 200 15 - 25 3
1)
Preheat the oven.
2)
Use a deep pan.
10.10 Roasting
Use heat-resistant ovenware.
Roast large roasting joints directly in the
tray or on the wire shelf placed above the
tray.
Put some water in the tray to prevent the
meat juices or fat from burning.
Meat with crackling can be roasted in the
roasting tin without the lid.
Turn the roast after 1/2 - 2/3 of the
cooking time.
To keep meat more succulent:
• roast lean meat in the roasting tin with
the lid or use roasting bag.
• roast meat and fish in large pieces (1
kg or more).
• baste large roasts and poultry with
their juices several times during
roasting.
10.11 Roasting
Beef
Food Func‐
tion
Quantity
(kg)
Power
(Watts)
Tempera‐
ture (°C)
Time (min) Shelf po‐
sition
Pot roast Top /
Bottom
Heat
1 - 1.5 200 230 60 - 80 1
ENGLISH 21
Pork
Food Func‐
tion
Quantity
(kg)
Power
(Watts)
Tempera‐
ture (°C)
Time (min) Shelf po‐
sition
Shoulder,
neck, ham
joint
Turbo
Grilling
1 - 1.5 200 160 - 180 50 - 70 1
Meat loaf Turbo
Grilling
0.75 - 1 200 160 - 170 35 - 50 1
Pork
knuckle
(pre‐
cooked)
Turbo
Grilling
0.75 - 1 200 150 - 170 60 - 75 1
Veal
Food Func‐
tion
Quantity
(kg)
Power
(Watts)
Tempera‐
ture (°C)
Time (min) Shelf po‐
sition
Roast
veal
Turbo
Grilling
1 200 160 - 180 50 - 70 1
Knuckle
of veal
Turbo
Grilling
1.5 - 2 200 160 - 180 75 - 100 1
Lamb
Food Func‐
tion
Quantity
(kg)
Power
(Watts)
Tempera‐
ture (°C)
Time (min) Shelf
position
Leg of
lamb, roast
lamb
Turbo
Grilling
1 - 1.5 200 150 - 170 50 - 70 1
Poultry
Food Func‐
tion
Quantity
(kg)
Power
(Watts)
Tempera‐
ture (°C)
Time (min) Shelf
position
Poultry
portions
Turbo
Grilling
0.2 - 0.25
each
200 200 - 220 20 - 35 1
Chicken
half
Turbo
Grilling
0.4 - 0.5
each
200 190 - 210 25 - 40 1
Chicken
poulard
Turbo
Grilling
1 - 1.5 200 190 - 210 60 - 80 1
Duck Turbo
Grilling
1.5 - 2 200 180 - 200 80 - 110 1
www.electrolux.com22
Fish (steamed)
Food Func‐
tion
Quantity
(kg)
Power
(Watts)
Tempera‐
ture (°C)
Time (min) Shelf
position
Whole fish Top /
Bottom
Heat
1 - 1.5 200 210 - 220 30 - 45 1
Dishes
Food Func‐
tion
Quantity
(kg)
Power
(Watts)
Tempera‐
ture (°C)
Time (min) Shelf
position
Dishes
sweet
True
Fan
Cook‐
ing
- 200 160 - 180 20 - 35 1
Savoury
dishes
with
cooked in‐
gredients
(noodles,
vegeta‐
bles)
True
Fan
Cook‐
ing
- 400 -
600
160 - 180 20 - 45 1
Savoury
dishes
with raw
ingredients
(potatoes,
vegeta‐
bles)
True
Fan
Cook‐
ing
- 400 -
600
160 - 180 30 - 45 2
10.12 Grilling
Put the pan to collect the fat into the first
shelf position.
Preheat the empty oven for 5 minutes.
Grilling
Food Temperature
(°C)
Grilling time (min) Shelf position
1st side 2nd side
Roast beef,
medium
210 - 230 30 - 40 30 - 40 1
Filet of beef,
medium
230 20 - 30 20 - 30 1
Back of pork 210 - 230 30 - 40 30 - 40 1
Back of veal 210 - 230 30 - 40 30 - 40 1
Back of lamb 210 - 230 25 - 35 20 - 35 1
ENGLISH 23
Food Temperature
(°C)
Grilling time (min) Shelf position
1st side 2nd side
Whole Fish, 0.5
- 1 kg
210 - 230 15 - 30 15 - 30 1
10.13 Frozen foods
• Remove the food packaging. Put the
food on a plate.
• Do not cover it with a bowl or a plate.
This can extend the defrost time.
Use the function True Fan Cooking.
Food Temperature (°C) Time (min) Shelf position
Pizza, frozen 200 - 220 15 - 25 3
Pizza American, fro‐
zen
190 - 210 20 - 25 3
Pizza, chilled 210 - 230 13 - 25 3
Pizza Snacks, frozen 180 - 200 15 - 30 3
French Fries, thin
1)
210 - 230 20 - 30 3
French Fries, thick
1)
210 - 230 25 - 35 3
Wedges / Cro‐
quettes
1)
210 - 230 20 - 35 3
Hash Browns 210 - 230 20 - 30 3
Lasagne / Cannello‐
ni, fresh
170 - 190 35 - 45 2
Lasagne / Cannello‐
ni, frozen
160 - 180 40 - 60 2
Chicken Wings 190 - 210 20 - 30 3
1)
Turn 2 or 3 times during roasting.
Frozen Ready Meals Table
Food Function Tempera‐
ture (°C)
Time (min) Shelf position
Frozen pizza
1)
Top / Bottom
Heat
as per
manufac‐
turer's in‐
structions
as per manufac‐
turer's instruc‐
tions
2
Chips
2)
(300 -
600 g)
Top / Bottom
Heat or Turbo
Grilling
200 - 220 as per manufac‐
turer's instruc‐
tions
2
www.electrolux.com24
Food Function Tempera‐
ture (°C)
Time (min) Shelf position
Baguettes
3)
Top / Bottom
Heat
as per
manufac‐
turer's in‐
structions
as per manufac‐
turer's instruc‐
tions
2
Fruit cake Top / Bottom
Heat
as per
manufac‐
turer's in‐
structions
as per manufac‐
turer's instruc‐
tions
2
1)
Preheat the oven.
2)
Turn 2 or 3 times during cooking.
3)
Preheat the oven.
10.14 Defrost
• Remove the food packaging and put
the food on a plate.
• Use the first shelf position from the
bottom.
• Do not cover the food with a bowl or a
plate, as this can extend the defrost
time.
• For large portions of food place an
upturned empty plate on the bottom of
the oven cavity. Put the food in a
deep plate or dish and set it on top of
the plate inside the oven. Remove
shelf supports if necessary.
Food Quantity
(kg)
Defrosting
time (min)
Further de‐
frosting
time (min)
Comments
Chicken 1 100 - 140 20 - 30 Put the chicken on an upturned
saucer in a big plate. Turn half‐
way through.
Meat 1 100 - 140 20 - 30 Turn halfway through.
Trout 0.15 25 - 35 10 - 15 -
Straw‐
berries
0.3 30 - 40 10 - 20 -
Butter 0.25 30 - 40 10 - 15 -
Cream 2 x 0.2 80 - 100 10 - 15 Whip the cream when still slight‐
ly frozen in places.
Gateau 1.4 60 60 -
10.15 Preserving - Bottom Heat
• Use only preserve jars of the same
dimensions available on the market.
• Do not use jars with twist-off and
bayonet type lids or metal tins.
• Use the first shelf from the bottom for
this function.
• Put no more than six one-litre
preserve jars on the baking tray.
• Fill the jars equally and close with a
clamp.
• The jars cannot touch each other.
ENGLISH 25
• Put approximately 1/2 litre of water
into the baking tray to give sufficient
moisture in the oven.
• When the liquid in the jars starts to
simmer (after approximately 35 - 60
minutes with one-litre jars), stop the
oven or decrease the temperature to
100 °C (see the table).
Soft fruit
Food Temperature (°C) Cooking time until
simmering (min)
Continue to cook
at 100 °C (min)
Strawberries / Blue‐
berries / Raspber‐
ries / Ripe goose‐
berries
160 - 170 35 - 45 -
Stone fruit
Food Temperature (°C) Cooking time until
simmering (min)
Continue to cook
at 100 °C (min)
Pears / Quinces /
Plums
160 - 170 35 - 45 10 - 15
Vegetables
Food Temperature (°C) Cooking time until
simmering (min)
Continue to cook
at 100 °C (min)
Carrots
1)
160 - 170 50 - 60 5 - 10
Cucumbers 160 - 170 50 - 60 -
Mixed pickles 160 - 170 50 - 60 5 - 10
Kohlrabi / Peas /
Asparagus
160 - 170 50 - 60 15 - 20
1)
Leave standing in the oven after it is deactivated.
10.16 Drying - True Fan Cooking
Food Temperature (°C) Time (h) Shelf position
Beans 60 - 70 6 - 8 3
Peppers 60 - 70 5 - 6 3
Vegetables for soup 60 - 70 5 - 6 3
Mushrooms 50 - 60 6 - 8 3
Herbs 40 - 50 2 - 3 3
Plums 60 - 70 8 - 10 3
Apricots 60 - 70 8 - 10 3
Apple slices 60 - 70 6 - 8 3
Pears 60 - 70 6 - 9 3
www.electrolux.com26
10.17 Microwave cooking
Tips for the Microwave
Cooking/Defrost‐
ing results
Possible cause Remedy
The food is too dry. The power was too high.
The time was too long.
Next time select a lower power and
a longer time.
The food is still not
defrosted, hot or
cooked after the
end of cooking time.
The time was too short. Set a longer time. Do not increase
the microwave power.
The food is over‐
heated at the edges
but is still not ready
in the middle.
The power was too high. Next time select a lower power and
a longer time.
Defrosting meat
Food Power
(Watts)
Time (min) Standing time
(min)
Steak (0.2 kg) 100 5 - 7 5 - 10
Minced meat (0.5 kg) 100 10 - 15 5 - 10
Defrosting poultry
Food Power
(Watts)
Time (min) Standing time
(min)
Chicken (1 kg) 100 25 - 30 10 - 20
Chicken breast (0.15 kg) 100 3 - 5 10 - 15
Chicken legs (0.15 kg) 100 3 - 5 10 - 15
Defrosting fish
Food Power
(Watts)
Time (min) Standing time
(min)
Whole Fish (0.5 kg) 100 10 - 15 5 - 10
Fish fillets (0.5 kg) 100 12 - 15 5 - 10
Defrosting dairy products
Food Power
(Watts)
Time (min) Standing time
(min)
Butter (0.25 kg) 100 3 - 4 5 - 10
Grated cheese (0.2 kg) 100 2 - 3 10 - 15
ENGLISH 27
Defrosting cakes / pastries
Food Power
(Watts)
Time (min) Standing time
(min)
Yeast cake (1 piece) 200 2 - 3 15 - 20
Cheesecake (1 piece) 100 2 - 4 15 - 20
Dry cake (e.g. Pound cake)
(1 piece)
200 2 - 4 15 - 20
Bread (1 kg) 200 15 - 20 5 - 10
Sliced bread (0,2 kg) 200 3 - 5 5 - 10
Bread rolls (4 pieces) 200 2 - 4 2 - 5
Defrosting fruit
Food Power
(Watts)
Time (min) Standing time
(min)
Fruit (0.25 kg) 100 5 - 10 10 - 15
Reheating
Food Power
(Watts)
Time (min) Standing time
(min)
Baby food in jars (0.2 kg) 300 1 - 2 -
Baby milk (180 ml); Put
spoon into the bottle
600 0:20 - 0:40 -
Convenience food (0.5 kg) 600 6 - 9 2 - 5
Frozen ready meals (0.5
kg)
400 10 - 15 2 - 5
Milk (200 ml) 1000 1 - 1:30 -
Water (200 ml) 1000 1:30 - 2 -
Sauce (200 ml) 600 1 - 3 -
Soup (300 ml) 600 3 - 5 -
Melting
Food Power
(Watts)
Time (min) Standing time
(min)
Chocolate / Chocolate
coating (0.15 kg)
300 2 - 4 -
Butter (0.1 kg) 400 0:30-1:30 -
www.electrolux.com28
Cooking
Food Power
(Watts)
Time (min) Standing time
(min)
Whole fish (0.5 kg) 500 8 - 10 2 - 5
Fish fillets (0.5 kg) 400 4 - 7 2 - 5
Vegetables, fresh (0.5 kg +
50 ml of water)
600 5 - 15 -
Vegetables, frozen (0.5 kg
+ 50 ml of water)
600 10 - 20 -
Jacked potatoes (0.5 kg) 600 7 - 10 -
Rice (0.2 kg + 400 ml of
water)
600 15 - 18 -
Popcorn 1000 1:30 - 3 -
Microwave Combi function
Use this function to cook food in a
shorter time and to brown it.
Combine functions: Turbo Grilling and
Microwave.
Food Ovenware Pow‐
er
(Watt
s)
Tem‐
pera‐
ture
(°C)
Time
(min)
Shelf
posi‐
tion
Standing
time (min)
2 chicken
halves (2 x
0.55 kg)
Round glass dish, Ø
26 cm
300 220 40 2 5
Au gratin po‐
tatoes (1 kg)
Gratin dish 300 200 40 2 10
Roast pork
neck (1.1 kg)
Glass dish with strain‐
er
300 200 70 1 10
10.18 Examples of cooking
applications for power settings
The data in the table is for guidance only.
Power setting Use
• 1000 Watt
• 900 Watt
• 800 Watt
• 700 Watt
Heating liquids
Searing at the start of the cooking process
Cooking vegetables
ENGLISH 29
Power setting Use
• 600 Watt
• 500 Watt
Defrosting and heating frozen meals
Heating one-plate meals
Simmering stews
Cooking egg dishes
• 400 Watt
• 300 Watt
Continuing to cook meals
Cooking delicate food
Heating baby food
Simmering rice
Heating delicate food
Melting cheese, chocolate, butter
• 200 Watt
• 100 Watt
Defrosting meat, fish
Defrosting cheese, cream, butter
Defrosting fruit and cakes
Defrosting bread
10.19 Information for test
institutes
Microwave function
Tests according to IEC 60705.
Food Power
(Watts)
Quanti‐
ty (kg)
Shelf po‐
sition
1)
Time (min) Comments
Sponge
cake
600 0.475 Bottom 7 - 9 Turn container around
by 1/4, halfway
through the cooking
time.
Meatloaf 400 0.9 2 25 - 32 Turn container around
by 1/4, halfway
through the cooking
time.
Egg custard 500 1 Bottom 18 -
Meat de‐
frosting
200 0.5 Bottom 8 - 12 Turn the meat upside
down halfway through
the cooking time.
1)
Use wire shelf unless otherwise specified.
Microwave Combi function
Tests according to IEC 60705.
www.electrolux.com30
Food Function Power
(Watts
)
Tempera‐
ture (°C)
Shelf
posi‐
tion
1)
Time
(min)
Comments
Cake
(0.7 kg)
True Fan
Cooking +
MW
100 180 2 29 - 31 Turn container
around by 1/4,
halfway through
the cooking time.
Potato
gratin
(1.1 kg)
Grill + MW 400 160 1 40 - 45 Turn container
around by 1/4,
halfway through
the cooking time.
Chicken
(1.1 kg)
Grill + MW 400 230 1 45 - 55 Put the meat in
round glass con‐
tainer and turn it
upside down af‐
ter 20 minutes of
the cooking time.
1)
Use wire shelf unless otherwise specified.
11. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
11.1 Notes on cleaning
Clean the front of the oven with a soft
cloth with warm water and a mild
cleaning agent.
To clean metal surfaces, use a dedicated
cleaning agent.
Clean the oven interior after each use.
Fat accumulation or other food remains
may result in a fire.
Clean the cavity roof carefully from food
residuals and fat.
Clean all accessories after each use and
let them dry. Use a soft cloth with warm
water and a cleaning agent. Do not clean
the accessories in the dishwasher.
Clean stubborn dirt with a special oven
cleaner.
If you have nonstick accessories, do not
clean them using aggressive agents,
sharp-edged objects or a dishwasher. It
can cause damage to the nonstick
coating.
Clean the moisture from the cavity after
each use.
11.2 Removing the shelf
supports
Before maintenance, make sure that the
oven is cool. There is a risk of burns.
To clean the oven, remove the shelf
supports.
1. Pull carefully the supports up and out
of the front catch.
2
3
1
2. Pull the front end of the shelf support
away from the side wall.
3. Pull the supports out of the rear
catch.
Install the shelf supports in the opposite
sequence.
ENGLISH 31
11.3 Replacing the lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
1. Turn off the oven.
Wait until the oven is cooled down.
2. Disconnect the oven from the mains.
3. Put a cloth on the bottom of the
cavity.
CAUTION!
Always hold the halogen
lamp with a cloth to prevent
grease residue from burning
on the lamp.
The top lamp
1. Turn the lamp glass cover to remove
it.
2. Clean the glass cover.
3. Replace the lamp with a suitable 300
°C heat-resistant lamp.
4. Install the glass cover.
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
12.1 What to do if...
Problem Possible cause Remedy
You cannot activate or op‐
erate the oven.
The oven is not connected
to an electrical supply or it
is connected incorrectly.
Check if the oven is cor‐
rectly connected to the
electrical supply (refer to
the connection diagram if
available).
The oven does not heat
up.
The oven is deactivated. Activate the oven.
The oven does not heat
up.
The clock is not set. Set the clock.
The oven does not heat
up.
The necessary settings are
not set.
Make sure that the settings
are correct.
The oven does not heat
up.
The automatic switch-off is
activated.
Refer to "Automatic switch-
off".
The oven does not heat
up.
The Child Lock is on. Refer to "Using the Child
Lock".
The oven does not heat
up.
The fuse is blown. Make sure that the fuse is
the cause of the malfunc‐
tion. If the fuse is blown
again and again, contact a
qualified electrician.
The lamp does not oper‐
ate.
The lamp is defective. Replace the lamp.
www.electrolux.com32
Problem Possible cause Remedy
It takes too long to cook
the dishes or they cook too
quickly.
The temperature is too low
or too high.
Adjust the temperature if
necessary. Follow the ad‐
vice in the user manual.
Steam and condensation
settle on the food and in
the cavity of the oven.
You left the dish in the
oven for too long.
Do not leave the dishes in
the oven for longer than 15
- 20 minutes after the
cooking process ends.
The display shows an error
code that is not in this ta‐
ble.
There is an electrical fault. • Deactivate the oven
with the house fuse or
the safety switch in the
fuse box and activate it
again.
• If the display shows the
error code again, con‐
tact the Customer Care
Department.
12.2 Service data
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre.
The necessary data for the service
centre is on the rating plate. The rating
plate is on the front frame of the oven
cavity. Do not remove the rating plate
from the oven cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
13. ENERGY EFFICIENCY
13.1 Energy saving
The oven contains features
which help you save energy
during everyday cooking.
General hints
Make sure that the oven door is closed
properly when the oven operates. Do not
open the door too often during cooking.
Keep the door gasket clean and make
sure it is well fixed in its position.
Use metal dishes to improve energy
saving, but only when you use a non-
microwave function.
When possible, do not preheat the oven
before you put the food inside.
When the cooking duration is longer than
30 minutes, reduce the oven temperature
to minimum 3 - 10 minutes before the
end of the cooking time, depending on
the duration of the cooking. The residual
heat inside the oven will continue to
cook.
ENGLISH 33
Use the residual heat to warm up other
dishes.
Keep breaks between baking as short as
possible when you prepare few dishes at
one time.
Cooking with fan
When possible, use the cooking
functions with fan to save energy.
Residual heat
If a programme with the Duration or End
Time selection is activated and the
cooking time is longer than 30 minutes,
the heating elements automatically
deactivate earlier in some oven
functions.
The fan and lamp continue to operate.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a
meal warm. The residual heat indicator
or temperature appears on the display.
Cooking with the lamp off
Turn off the lamp during cooking. Turn it
on only when you need it.
14. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
www.electrolux.com34
ENGLISH 35
www.electrolux.com/shop
867352389-A-422018
