SHB3075
BASS+
User manual
Register your product and get support at
www.philips.com/support
1EN
Contents
Contents
1 Important safety instructions 2
Hearing Safety 2
General information 2
2 Your Bluetooth wireless
headphones 3
What's in the box 3
Other devices 3
Overview of your Bluetooth
wireless headphones 3
3 Get started 5
Charge your headphones 5
Pair the headphones with your
mobile phone 5
4 Use your headphones 6
Connect the headphones to a
Bluetooth device 6
Manage your calls and music 6
Wear your headset 7
5 Technical data 8
6 Notice 9
Notice of compliance 9
Disposal of your old product
and battery 10
Trademarks 10
7 Frequently asked questions 11
2
EN
1 Important
safety
instructions
Hearing Safety
Danger
• To avoid hearing damage, limit the time you
use headphones at high volume and set the
volume to a safe level. The louder the volume,
the shorter the safe listening time is.
Be sure to observe the following
guidelines when using your headset.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high
that you can’t hear what’s around
you.
• You should use caution or
temporarily discontinue use in
potentially hazardous situations.
• Excessive sound pressure from
earphones and headphones can
cause hearing loss.
• Using headphones with both
ears covered while driving is not
recommended and may be illegal in
some areas while driving.
• For your safety, avoid distractions
from music or phone calls while in
trac or other potentially dangerous
environments.
General information
To avoid damage or malfunction:
Caution
• Do not expose headphones to excessive heat.
• Do not drop your headphones.
• Headphones shall not be exposed to dripping
or splashing.
• Do not allow your headphones to be
submerged in water.
• Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
• If cleaning is required use a soft cloth, if
necessary dampened with a minimum amount
of water or diluted mild soap, to clean the
product.
• The integrated battery shall not be exposed
to excessive heat such as sunshine, re or the
like.
• Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
About operating and storage
temperatures and humidity
• Operate or store in a place where
temperature is between -15ºC (5ºF)
and 55ºC (131ºF) (up to 90% relative
humidity.
• Battery life may be shorter in high or
low temperature conditions.
3EN
2 Your
Bluetooth
wireless
headphones
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers,
register your product at www.philips.
com/welcome.
With this Philips wireless headphones,
you can:
• enjoy convenient wireless
handsfree calls;
• enjoy and control wireless music;
• switch between calls and music.
What's in the box
Philips Bluetooth wireless headphones
BASS+ On-Ear (SHB3075)
USB charging cable (for charging only)
Quick start guide
Other devices
A mobile phone or device (e.g.
notebook, PDA, Bluetooth adapters,
MP3 players etc) which supports
Bluetooth and is compatible to the
headphones (see ‘Technical data” on
page 8).
Overview of your
Bluetooth wireless
headphones
a
Music/call/track control button
b LED indicator
c
On/o button
d Microphone
7
3
1
2
4
5
6
4
EN
e
Pairing/Mute button
f Micro USB charging slot
g +/-
Volume control button
5EN
3 Get started
Charge your headphones
Note
• Before you use your headphones for the
rst time, charge the battery for 5 hours for
optimum battery capacity and lifetime.
• Use only the original USB charging cable to
avoid any damage.
• Finish your call before charging the
headphones, as connecting the headphones
for charging will power the headphones o.
• You can operate the headphones normally
during charging.
Connect the supplied USB charging
cable to:
• the micro USB charging slot on
the headphones and;
• the charger/USB port of a
computer.
» LED turns white during
charging and turns o when the
headphones is fully charged.
Tip
• Normally, a full charge takes 3 hours.
Pair the headphones with
your mobile phone
Before you use the headphones with
your mobile phone for the rst time,
pair it with a mobile phone. A successful
pairing establishes a unique encrypted
link between the headphones and
mobile phone. The headphones store
the last 8 devices in the memory. If
you try to pair more than 8 devices, the
earliest paired device is replaced by the
new one.
1
Make sure that the headphones are
fully charged.
2
Press and hold for 2 seconds to
turn the headphones on.
3
Press and hold until the blue and
white LED ashes alternately.
» The headphones remain in
pairing mode for 5 minutes.
4
Make sure that the mobile phone is
turned on and its Bluetooth feature
is activated.
5
Pair the headphones with the
mobile phone. For detailed
information, refer to the user
manual of your mobile phone.
The following example shows you
how to pair the headphones with your
mobile phone.
1
Activate the Bluetooth feature of
your mobile phone, select BASS+
On-Ear.
2
Enter the headset password "0000"
(4 zeros) if prompted. For those
mobile phones featuring Bluetooth
3.0 or higher, no need to enter a
password.
BASS+ On-Ear
SHB4405
6
EN
4 Use your
headphones
Connect the headphones
to a Bluetooth device
1
Turn on your mobile
phone/Bluetooth device.
2
Press and hold for 2 seconds to
turn the headphones on.
» The blue LED ashes.
» The headphones are
reconnected to the
last connected mobile
phone/Bluetooth device
automatically. If the last one is
not available, the headphones
try to reconnect to the second
last connected device.
Tip
• If you turn on the mobile phone/Bluetooth
device or activate the Bluetooth feature
after turning on the headphones, you have
to reconnect the headphones and mobile
phone/Bluetooth device manually.
Note
• If the headphones fail to connect to any
Bluetooth device within range in 5 minutes, it
will switch o automatically to save the battery
life.
Manage your calls and
music
On/o
Task Button Operation
Turn the
headphones
on.
Press and
hold for 2
seconds.
Turn the
headphones
o.
Press and
hold for 6
seconds.
» The white
LED is on
and fades
out.
Music control
Task Button Operation
Play or pause
music.
Press once.
Adjust
volume.
+/- Press
once/press
and hold.
Skip forward. Press twice.
Skip
backward.
Press and
hold for 2
seconds.
Call control
Task Button Operation
Pick up/hang
up a call.
Press once.
» 1 beep.
Reject an
incoming call.
Press and
hold for 2
seconds.
» 1 beep.
Switch caller
during a call.
Press and
hold for 2
seconds.
7EN
Mute/unmute
the microphone
in a call.
Press once.
» 1 beep.
Voice control
Task Button Operation
Siri/Google
Now.
Press and hold
for 2 seconds.
Other headphones indicator status
Headphones
status
Indicator
The headphones
are connected
to a Bluetooth
device, while the
headphones in
standby mode
or while you are
listening to music.
The blue LED
ashes for every 8
seconds.
The headphones
are ready for
pairing.
The LED ashes
blue and white
alternately.
The headphones
are on but not
connected to a
Bluetooth device.
The blue LED
ashes quickly.
If no connection
can be made, the
headphones will
turn itself o within
5 minutes.
Low battery level. The white LED
ashes 3 times for
every 150 seconds
until it is out of
power.
Battery is fully
charged.
The white LED is
o.
Wear your headset
Adjust the headband to t your head.
8
EN
5 Technical
data
• Music time: 12 hours
• Talk time: 12 hours
• Standby time: 166 hours
• Normal time for a full charge: 3
hours
• Rechargeable lithium polymer
battery (240 mAh)
• Bluetooth 4.1, Bluetooth mono
support (Headset Prole - HSP,
Hands-Free Prole - HFP),
Bluetooth stereo supported
(Advanced Audio Distribution
Prole - A2DP; Audio Video Remote
Control Prole - AVRCP)
• Frequency range: 2.402-2.480GHz
• Transmitter power: <20dBm
• Operating range: Up to 10 meters
(33 feet)
• Digital echo & noise reduction
• Auto power o
Note
• Specications are subject to change without
notice.
9EN
6 Notice
Notice of compliance
Notice for US
This set complies with the FCC rules,
Part 15 and with 21 CFR 1040.10.
Operation is subject to the following
two conditions:
a This device may not cause harmful
interference, and
b This device must accept any
interference received, including
interference that may cause
undesired operation.
FCC rules
This equipment has been tested and
found to comply with the limits for
a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instruction manual, may
cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio
or television reception, which can be
determined by turning the equipment
o and on, the user is encouraged to
try to correct the interference by one or
more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between
equipment and receiver.
• Connect the equipment into an
outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an
experienced radio/TV technician for
help.
FCC Radiation Exposure Statement:
This equipment complies with FCC
radiation exposure limits set forth for
an uncontrolled environment. This
equipment should be installed and
operated with a minimum distance of
20cm between the radiator and your
body. This transmitter must not be co-
located or operated in conjunction with
any other antenna or transmitter.
Warning: Changes or modications
made to this equipment not expressly
approved by Gibson Innovations may
void the FCC authorization to operate
this equipment.
Model number: BASS+ On-Ear
(SHB3075)
Trade Name: Philips
Responsible party: Gibson Innovations
USA Inc. P.O.Box 100572 Nashville TN
37224
Notice for Canada:
This device complies with Industry
Canada licence-exempt RSS
standard(s). Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference,
and (2) this device must accept any
interference received, including
interference that may cause undesired
operation.
This Class B digital apparatus complies
with Canadian ICES-003.
IC Radiation Exposure Statement:
This equipment complies with Canada
radiation exposure limits set forth for
uncontrolled environments.
This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
10
EN
Disposal of your old
product and battery
Your product is designed and
manufactured with high quality
materials and components, which can
be recycled and reused.
This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or visit www.recycle.philips.
com.
This product contains non-removable
batteries:
• Do not incinerate. Batteries may
explode if overheated.
• For disposal or recycling
information, please contact your
local authorities or visit www.
recycle.philips.com.
Trademarks
Bluetooth
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Gibson Innovations Limited is
under license.
Siri
Siri is a trademark of Apple Inc.,
registered in
the U.S. and other countries.
Google
Google and the Google Logo are
registered trademarks of Google Inc.
7 Frequently
asked
questions
My Bluetooth headphones do not
switch on.
The battery level is low. Charge the
headphones.
I cannot pair my Bluetooth headphones
with a mobile phone.
The Bluetooth is disabled. Enable
the Bluetooth feature on your mobile
phone and turn on the mobile phone
before you turn on the headphones.
Pairing does not work.
Make sure the headphones are in
pairing mode.
• Follow the steps described in
this user manual (see ‘Pair the
headphones with your mobile
phone” on page 5).
• Make sure that the LED light ashes
blue and white alternately before
you release . Do not stop holding
the button if you see the blue LED
only.
The mobile phone cannot nd the
headphones.
• The headphones may be
connected to a previously paired
device. Turn o the connected
device or move it out of range.
• Pairing may have been reset or the
headphones have been previously
paired with another device. Pair
the headphones with the mobile
phone again as described in
the user manual (see ‘Pair the
headphones with your mobile
phone” on page 5).
My Bluetooth headphones are
connected to a Bluetooth stereo
enabled mobile phone, but music only
plays on the mobile phone speaker.
Refer to the user manual of your mobile
phone. Select to listen to music through
the headphones.
The audio quality is poor and crackling
noise can be heard.
The Bluetooth device is out of range.
Reduce the distance between your
headphones and Bluetooth device, or
remove obstacles between them.
The audio quality is poor when
streaming from the mobile phone is very
slow, or audio streaming does not work
at all.
Make sure your mobile phone not only
supports (mono) HSP/HFP but also
supports A2DP (see ‘Technical data” on
page 8).
I hear but cannot control music on my
Bluetooth device (e.g. play/pause/skip
forward/backward).
Make sure the Bluetooth audio source
supports AVRCP (see ‘Technical data”
on page 8).
For further support, visit www.philips.
com/support.
BC
2017 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold under the responsibility
of Gibson Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in
relation to this product.
Philips and the Philips’ Shield Emblem are registered
trademarks of Koninklijke Philips N.V.
UM_SHB3075_27_EN_V1.0
WK1704
