You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:
• Visiting our website - docs.hotpoint.eu
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product’s identi cation plate.
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.hotpoint.eu/register
EN
Quick guide
Before using the appliance carefully read the Safety Instructions.
xxxxxxxxxxxx
xxxx
PROGRAMMES
1.Mixed kg 4
This programme is ideal for drying cotton and synthetic fabrics
together.
2.Eco Cotton kg Max*
Standard cotton programme, suitable to dry normally wet
cotton laundry. Most ecient programme in terms of energy
consumption for drying cotton laundry. The values on the Energy
Label are based on this programme.
3.Synthetics kg 4
This programme is suitable for synthetic garments or cotton
blends/synthetic.
4.Wool kg 1
Programme for drying wool clothing. It is advisable to turn the
garments inside out before drying. Leave to dry naturally the heaviest
edges that are still damp.
5.Silk kg 0,5
Gentle drying of silk garments.
6.Anti Allergy kg Max*
This cycle has the “Allergy UK” approval of “The British Allergy
Foundation” attesting the eective reduction and elimination of
allergens. It can be used both with damp load (drying and treatment)
and dry load (half load only).
7.Daily kg 2
Ideal for drying garments of cotton blends or synthetics spun at
high speed in the washing machine.
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dyrer is properly xed,
either to the dryers's water tank or to the domestic sewage
system.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before you use your dryer ensure that it has been in a upright
position for at least 6 hours.
Should you wish to change the opening side of the door, please
contact our After-sales Service. (See phone number in the
warranty booklet).
DAILY USE
Doing this will keep your machine working at its BEST!
Remember to empty your water tank after each drying cycle.
Remember to clean your lters after each drying cycle. (Refer to
section Care & Maintanence).
1. Open the door and load garments. Always refer to instructions
on clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door lter.
2. Close the door.
3. Press the button On/O.
4. Select the programme according to the laundry type.
5. Select the options, if necessary.
6. To start the cycle, press the Start/Pause button.
7. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Pull the load out
immediately to prevent the formation of creases on laundry.
8. Turn the machine o by pressing the button On/O, open the
door and pull clothing out. If the machine is not switched o
manually, after about a quarter of an hour from the cycle end, the
appliance turns o automatically to save energy.
If this last stage is not carried out immediately, some machines
and/or some programmes/options are equipped with Crease Care
system. For some hours, after the end of drying, the drum rotates
at regular intervals to prevent the formation of creases.
In case of power failure, it is necessary to press the button Start/
Pause to restart the cycle.
OPENING OF THE DOOR DURING THE CYCLE
During operation, it is possible to open the door. After having
closed it, press the button Start/Pause again to restart the dryer.
*MAX LOAD 8 Kg (Dry load)
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
CONTROL PANEL
1 ON/OFF button (Reset if long pressed)
2 Programme selection Knob
3 Start/Pause button
4 Active Care
Options Buttons*
5 Dryness Level
6 Start Delay
7 Timed Drying
8 Cycle End
9 Gentle (Key lock if long pressed)
10 Crease Care (Mute if long pressed)
*Note: some models may have the wording in full instead of the icons
INDICATORS
Dryness Level: Iron Dry - Hanger Dry - Cupboard Dry - Extra Dry
Cycle Phase: Drying - Cool Down - END of cycle -
Empty Water tank - Clean Door lter - Clean Bottom lter -
Refer to Troubleshooting section: Failure: Call after Sales Service
DEMO
Demo Mode
3 “
3 “
END
1
3
2
4
10
8
9
5 67
DEMO
