Fab Glass Frameless Rectangle Mirror
Installation Manual
www.fabglassandmirror.com Call: +1 888-474-2221 Fax: (614)-334-4919
Office Timing: 8:30 - 18:00 EST [email protected]
Drill/Driver Level Tape Measure Screw Driver Hammer Lead Pencil
Thank you for your purchase! It is our desire to make your entire experience from
purchase to installation as easy as possible. We ask that you read each step of this
installation manual thoroughly to ensure proper installation of your new Mirror. Our
installation techniques are very important. Installing your Mirror in any manner other
than the steps outlined in this manual may lead to structural failure of your Mirror.
Safety Backing Mirror:
A single sided woven tape is laminated onto the back of the mirror for security reasons
if ever the glass is broken, the adhesive film holds the shattered pieces together, which
significantly decreases the risk of injury.
It is your responsibility to see that your Mirror is properly assembled, installed, and
cared for. Failure to follow instructions in this manual could result in serious injury. Use
this product with Mirror cautions.
Tools Needed
Hardware Included With This Order
CAUTION
Anchor
( Qty - 4/6)
Screw
( Qty - 4/6)
1
2
3
4
By using your cutting
tool, carefully open
the package and
remove the mirror.
On the back side of
the mirror, use your
pencil to mark the
center point.
1
Page
Measure the distance
between the center
point of the clips and
write down the result.
Measure the distance
between the center
point of the clips and
write down the result.
Mirror Back Side
Center Point
5
6
7
8
Hold the mirror against
the wall where you want
to install it, and mark
the wall at the top edge
of the mirror with your
pencil.
Using the results from
the Steps 3 and 4, measure
down from the top edge
mark to the center point
between the clips and
place another mark,
then from that mark
measure out to the
center of the clip body
on each side and mark
the wall in both spots.
Drill two holes in the
wall at the clip body
center locations.
Using your drill,
insert the anchor
bolts in the holes.
Anchor
2
Page
12
Hang the mirror on the
wall by inserting the
screw heads into the
clips, and press gently
against the bottom of
the mirror to attach
the sticky pads firmly
to the wall.
Now Fix the clip holes
on screws
9
10
13
Leave ¼ “ of space
between the wall
and the screw head.
Now install the screw
in the anchor with
your drill.
3
Page
Distance From Wall
Wall
(Side View)
Space from
wall
Congratulations!
You have successfully installed your
frameless rectangle mirror. Enjoy!
