LG Electronics 24M45VQ-B 24" Class Full HD LED Monitor User Manual

www.lg.com

22M45VQ

23M45VQ

24M45VQ

27M45VQ

LED LCD MONITOR MODEL

ENGLISH

OWNER’S MANUAL

LED LCD MONITOR

Please read this manual carefully before operating

your set and retain it for future reference.

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 ASSEMBLINGANDPREPAR-

ING

3 Unpacking

4 Partsandbuttons

5 MovingandLiftingtheMonitor

6 SettinguptheMonitorset

6 - AttachingtheStandBase

7 - DetachingtheStandBase

8 - Mountingonatable

8 - Usingthecableholder

10 - Mountingonawall

11 USINGTHEMONITORSET

11 ConnectingtoaPC

11 - D-SUBconnection

11 - DVI-Dconnection

11 - HDMIconnection

12 ConnectingtoAVDevices

12 - HDMIconnection

12 ConnectingtoExternalDevices

12 - Peripheraldeviceconnection

14 CUSTOMIZINGSETTINGS

15 CustomizingSettings

15 - MenuSettings

16 -Picture

17 -Color

18 -Display

18 -Audio

19 -Others

20 READERSetting

21 FUNC.Setting

21 -SUPERENERGYSAVING

22 -PictureMode

23 -DUALDISPLAY

23 -DUALWEB

24 TROUBLESHOOTING

26 SPECIFICATIONS

26 22M45VQ

27 23M45VQ

28 24M45VQ

29 27M45VQ

30 PresetModes(Resolution)

30 Indicator

31 PROPERPOSTURE

31 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.



Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.



Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.



Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.



Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

CD(Owner'sManual)/

Card

(Dependingonthecountry) (Dependingonthecountry)

PowerCord

AC-DCAdapter

or

D-SUBCable

HDMICable

StandBody

(22M45VQ/23M45VQ/24M45VQ)

StandBase

StandBody

TwoScrews

DVI-DCable

(Dependingonthecountry)

27M45VQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator



LightingOn:Turnedon



LightingOff:Turnedoff

Connectionpanel(Seep.11~12)

Button(Seep.14)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

MovingandLiftingtheMonitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.



Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.



Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.



Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.



Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.



Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.





Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.



Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

Attachthe

StandBody

tothemonitorset.

Attachthe

StandBase

Tightenthescrewtotheright.

SettinguptheMonitorset

AttachingtheStandBase

 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION



StandBase

StandBody

22M45VQ/23M45VQ/24M45VQ

27M45VQ

Attachthe

StandBody

tothemonitorset.

Usetwoscrewstofixthe

StandBody

and

monitorset.

Attachthe

StandBase

Tightenthescrewtotheright.

StandBody

StandBase

ENG

ENGLISH

ASSEMBLING AND PREPARING

22M45VQ/23M45VQ/24M45VQ

27M45VQ

DetachingtheStandBase

 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

StandBase

StandBody



Pulloutthe

StandBody

and

StandBase



fromthemonitorset.

Turnthescrewtotheleft.

Pulloutthe

StandBase



Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.



Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

Turnthescrewtotheleft.

Pulloutthe

StandBase

fromthe

StandBody

Removetwoscrewsandpulloutthe

Stand

Body

fromthemonitorset.

StandBody

StandBase

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

Cableholder

or

ENG

ENGLISH

ASSEMBLING AND PREPARING

UsingtheKensingtonsecuritysystem

TheKensingtonsecuritysystemconnectoris

locatedatthebackoftheMonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweentheMonitorsetandatable.

TheKensingtonsecuritysystemisoptional.

Youcanobtainitfrommostelectronicsstores.

NOTE

Whenyouadjusttheangle,donotholdthe

bottomoftheMonitorsetframeasshownon

thefollowingillustration,asmayinjureyour

fingers.

Donottouchorpressthescreenwhen

adjustingtheangleofthemonitor.

Donotholdthissetlikebelowpicture.Monitor

screencandetachfromstandbaseandinjure

yourbody.

WARNING

Tiltfrom+20to-3degreesupordowntoadjust

theangleoftheMonitorsettosuityourview.

NOTE

Front Rear

Tiltfrom+20to-5degreesupordowntoadjust

theangleoftheMonitorsettosuityourview.

NOTE

Front Rear

22M45VQ/23M45VQ/24M45VQ

27M45VQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonawall

Forproperventilation,allowaclearanceof10cm

oneachsideandfromthewall.Detailed

instructionsareavailablefromyourdealer,seethe

optionalTiltWallMountingBracketInstallationand

SetupGuide.

IfyouintendtomounttheMonitorsettoawall,

attachWallmountinginterface(optionalparts)to

thebackoftheset.

WhenyouinstalltheMonitorsetusingawall

mountinginterface(optionalparts),attachit

carefullysoitwillnotdrop.

Please,Usethescrewandwallmountinterface

inaccordancewithVESAStandards.

Ifyouusescrewlongerthanstandard,the

monitormightbedamagedinternally.

Ifyouuseimproperscrew,theproductmightbe

damagedanddropfrommountedposition.In

thiscase,LGElectronicsisnotresponsiblefor

it.

VESAcompatibleonlywithrespecttoscrew

mountinginterfacedimensionsandmounting

screwspecifications.

PleaseuseVESAstandardasbelow.



784.8mm(30.9inch)andunder

*WallMountPadThickness:2.6mm

*Screw:Φ4.0mmxPitch0.7mmx

Length10mm



787.4mm(31.0inch)andabove

*PleaseuseVESAstandardwallmountpad

andscrews.

10 cm

Model

 

VESA(AxB) 75x75 100x100

Standard

screw

M4 M4

Numberof

screws

4 4

22M45VQ

23M45VQ

24M45VQ

27M45VQ



Disconnectthepowercordfirst,andthen

moveorinstalltheMonitorset.Otherwise

electricshockmayoccur.



IfyouinstalltheMonitorsetonaceilingor

slantedwall,itmayfallandresultinsevere

injury.



UseonlyanauthorizedLGwallmount

andcontactthelocaldealerorqualified

personnel.



Donotovertightenthescrewsasthismay

causedamagetotheMonitorsetandvoid

yourwarranty.



Useonlyscrewsandwallmountsthat

meettheVESAstandard.Anydamages

orinjuriesbymisuseorusinganimproper

accessoryarenotcoveredbythewarranty.



Screwlengthfromoutersurfaceofback

covershouldbeunder8mm.



UsethescrewsthatarelistedontheVESA

standardscrewspecifications.



Thewallmountkitwillincludeaninstallation

manualandnecessaryparts.



Thewallmountbracketisoptional.Youcan

obtainadditionalaccessoriesfromyourlocal

dealer.



Thelengthofscrewsmaydifferdepending

onthewallmount.Besuretousetheproper

length.



Formoreinformation,refertothe

instructionssuppliedwiththewallmount.

CAUTION

NOTE

BackCover

WallmountPad

BackCover

Standardscrew

Max.8mm

ENG

ENGLISH

USING THE MONITOR SET

USINGTHEMONITORSET

ConnectingtoaPC



YourMonitorsetsupportsPlug&Play*.

*Plug&Play:APCrecognizesaconnected

devicethatusersconnecttoaPCandturn

on,withoutdeviceconfigurationoruser

intervention.

D-SUBconnection

TransmitsanalogvideofromyourPCtothe

Monitorset.ConnectthePCandtheMonitorset

withthesuppliedD-sub15pinsignalcableas

showninthefollowingillustrations.



Macadapter

ForAppleMacintoshuse,aseparateplug

adapterisneededtochangethe15pin

highdensity(3row)D-SUBVGAconnector

onthesuppliedcabletoa15pin2row

connector.



WhenusingaD-Subsignalinputcable

connectorforMacintosh

NOTE

HDMIconnection

Transmitsthedigitalvideoandaudiosignalsfrom

yourPCtotheMonitorset.ConnectthePCand

theMonitorsetwiththeHDMIcableasshownin

thefollowingillustrations.



IfyouuseHDMIPC,itcancausecompatibility

problem.

NOTE

DVI-Dconnection

TransmitsadigitalvideosignalfromyourPCto

theMonitorset.ConnectthePCandtheMonitor

setwithaDVIcableasshowninthefollowing

illustrations.

ENG

ENGLISH

USING THE MONITOR SET



Connectthesignalinputcable

andtightenitbyturningthe

screwsclockwise.



Donotpressthescreenwith

yourfingerforalongtimeasthismay

resultintemporarydistortiononthescreen.



Avoiddisplayingafixedimageonthe

screenforalongperiodoftimetoprevent

imageburn.Useascreensaverifpossible.

CAUTION



WhenyouwanttousetwoPCinourMonitor,

pleaseconnectthesignalcable(D-SUB/

DVI-D/HDMI)respectivelyinMonitorset.



IfyouturntheMonitorsetonwhileitiscold,

thescreenmayflicker.Thisisnormal.



Somered,green,orbluespotsmayappear

onthescreen.Thisisnormal.

NOTE

ConnectingtoAVDevices

HDMIconnection

Transmitsthedigitalvideoandaudiosignalsfrom

yourAVdevicestothemonitor.ConnectyourAV

devicetothemonitorwiththeHDMIcableasil-

lustratedbelow.



UsingaDVItoHDMIcablemaycausecom-

patibilityissues.

NOTE

ConnectingtoExternalDevices

Peripheraldeviceconnection

Connectperipheraldevicestothemonitorusing

headphoneports.



Peripheraldevicesaresoldseparately.



Cableswithangledplugsmayhaveclear-

anceissues,usestraightplugswhenpos-

sible.

AngleType StraightType

NOTE



Headphonesorspeakersmaynotworknor-

mally,dependingontheserverPCsettings.

ENG

ENGLISH

USING THE MONITOR SET



"SelfImageSetting"Function.

Thisfunctionprovidestheuserwithoptimal

displaysettings.Whentheuserconnects

themonitorforthefirsttime,thisfunction

automaticallyadjuststhedisplaytooptimal

settingsforindividualinputsignals.(Only

supportedinAnalogMode)



‘AUTO’Function.

Whenyouencounterproblemssuchas

blurryscreen,blurredletters,screenflicker

ortiltedscreenwhileusingthedeviceor

afterchangingscreenresolution,pressthe

AUTOfunctionbuttontoimproveresolution.

(OnlysupportedinAnalogMode)

NOTE

SelfImageSettingFunction

Pressthepowerbuttononthebottompanelto

turnthepoweron.Whenmonitorpoweristurned

on,the"

SelfImageSetting

"Functionisexecuted

automatically.(OnlysupportedinAnalogMode)

ENG

ENGLISH

CUSTOMIZING SETTINGS

CUSTOMIZINGSETTINGS

 PressthedesiredbuttononthebottomoftheMonitorset.

 ChangethevalueofthemenuitembypressingthebuttonsonthebottomoftheMonitorset.

Toreturntotheuppermenuorsetothermenuitems,usetheuparrow( )button.

 Select

EXIT

toleavetheOSDmenu.

MonitorsetButtons

Button Description

Accessesthemainmenus.(Seep.15)

OSDLocked/OSD

Unlocked

Thisfunctionallowyoutolockthecurrentcontrolsettings,so

thattheycannotbeinadvertentlychanged.

PressandholdtheMENUbuttonforseveralseconds.Then

OSDof“OSDLock”willappear.Afterthat,usercanselect

lockorunlockbypressingleft/rightbutton.

Ifuserselectsthe“Lock”iconbypressingthe“OK”button,

themessage“OSDLocked”willappear.Otherwise,“OSD

Unlocked”willappear.Afterselectingthe“Lock”,Ifyouwant

tochangetoUnlock,youcanpushthe“MENU”buttonfor

severalseconds.Themessage“OSDUnlocked”willappear.

UsethisbuttontoenterReaderModemenu.Itsfunctionworkstodisplayscreenas

paper-likepictureforEyecomfort.Ifyouwanttomoreinformation(Seep.20).

UsethisbuttontoenterSUPERENERGYSAVING,PictureMode,DUALDISPLAY,

DUALWEBmenus.(Seep.21~23)

Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR

SETUPOSD.(OnlysupportedinAnalogMode)

Thebestdisplaymode 1920x1080

Youcanchoosetheinputsignal.

• Whentwoinputsignalsareconnected,youcanselecttheinputsignal(D-SUB/DVI-D/

HDMI)youwant.

• Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis

D-SUB.

EXIT

EXITtheOSD(OnScreenDisplay).

(PowerButton)

Turnsthepoweronoroff.

PowerIndicator Thepowerindicatorstayswhiteifthedisplayisrunning

properly(OnMode).IfthedisplayisinSleepMode,thepower

indicatorblinkswhite.

FUNC.

AUTO

INPUT

EXIT

READER

ENG

ENGLISH

CUSTOMIZING SETTINGS

CustomizingSettings

MenuSettings

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu Analog Digital HDMI Description

Brightness ● ● ●

Toadjustthebrightness,contrastofthescreen.

Contrast ● ● ●

ResponseTime

● ● ●

Youcansetaresponsetimefordisplayedpicturesbasedonthespeed

ofthescreen.Foranormalenvironment,itisrecommendedthatyou

use'Off'.Forafast-movingpicture,itisrecommendedthatyouuse

'High'.

Wide/Original

● ● ●

Wide

Switchtofullscreenmodeaccordingtoinputimagesignal.

Original

Changetheinputimagesignalratiotooriginal.

*ThisfunctionworksonlyifinputresolutionislowerthanMonitorset

ratio(16:9).

Reset

● ● ●

Restoreallfactorydefaultsettings.Pressthe

◄



,

►

buttonstoreset

immediately.

Menu>NextMenu Analog Digital HDMI Description

Picture Sharpness ● ● ●

Toadjusttheclearnessofthescreen

BlackLevel ●

Tosetoffsetlevel

OverScan ●

Toimprovetheclarityandstabilityofthescreen

Color Gamma

● ● ●

Tocustomizethecolorofthescreen

ColorTemp

Display Horizontal

●

Toadjustthepositionofthescreen

Vertical

Clock

●

Toimprovetheclarityandstabilityofthescreen

Phase

Audio

Volume ●

Toadjustthevolume

Others Language

● ● ●

Tocustomizethescreenstatusforauser'soperating

environment

PowerIndicator

AutomaticStandby ● ● ●



Analog:

D-SUB(Analogsignal)input.



Digital:

DVI-D(Digitalsignal)input.



HDMI:

HDMI(Digitalsignal)input.

ENG

ENGLISH

CUSTOMIZING SETTINGS


 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Enterto


bypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu>Picture Description

Sharpness Toadjusttheclearnessofthescreen.

BlackLevel Youcansettheoffsetlevel.Ifyouselect'High',thescreenwillbebrightandif

youselect‘Low’,thescreenwillbedark.(onlyforHDMIinput)

*Offset?Asthecriteriaforvideosignal,itisthedarkestscreenthemonitorcan

show.

OverScan ToselecttherangeofoutputimageforDTVtiminginHDMIinput.(onlyforHDMI

input)RecommendoverscanfunctiontoturnonwhenconnectAVequipment.

ENG

ENGLISH

CUSTOMIZING SETTINGS

Color

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

Color

bypressingthe►button.

 Enterto

Color

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu>Color Description

Gamma Setyourowngammavalue.:Gamma0,Gamma1,Gamma2onthemonitor,

highgammavaluesdisplaywhitishimagesandlowgammavaluesdisplay

blackishimages.

ColorTemp Custom

•Red:

Setyourownredcolorlevels.

•Green:

Setyourowngreencolorlevels.

•Blue:

Setyourownbluecolorlevels.

Selectthescreencolor.

Warm:

Setthescreentowarmcolortemperature(morered).

Medium:

Setthescreentomediumcolortemperature.

Cool:

Setthescreentocoolcolortemperature(moreblue).

ENG

ENGLISH

CUSTOMIZING SETTINGS

Display

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

Display

bypressingthe►button.

 Enterto

Display

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Audio

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

Audio

bypressingthe►button.

 Enterto

Volume

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu>Display Description

Horizontal Tomoveimageleftandright.

Vertical Tomoveimageupanddown.

Clock Tominimizeanyverticalbarsorstripesvisibleonthescreenbackground.The

horizontalscreensizewillalsochange.

Phase Toadjustthefocusofthedisplay.Thisitemallowsyoutoremoveanyhorizontal

noiseandclearorsharpentheimageofcharacters.

Menu>NextMenu>Audio Description

Volume Toadjustthevolumeofheadphone/earphone.(OnlyforHDMIinput)

ENG

ENGLISH

CUSTOMIZING SETTINGS

Others

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

Others

bypressingthe►button.

 Enterto

Others

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu>Others Description

Language Tochoosethelanguageinwhichthecontrolnamesaredisplayed.

PowerIndicator Usethisfunctiontosetthepowerindicatoronthebottomsideofthemonitorto

OnorOff.IfyousetOff,itwillgooff.

IfyousetOnatanytime,thepowerindicatorwillautomaticallybeturnedon.

AutomaticStandby Ifyoudonotpressanybuttononthemonitorsetforacertainperiod,themonitor

setwillautomaticallyswitchtostandbymode.

ENG

ENGLISH

CUSTOMIZING SETTINGS

READERSetting

 Press

READER

buttononthebottomoftheMonitor

settodisplaythe

ReaderMode

OSD.

 Settheoptionsbypressingthe◄buttons.

ReaderMode Description

Reader1 Itisamodethatthescreenisadjustedtothebestforthenewspaper.Ifyou

wantscreenmorebright,youcancontrolbrightnessinMenuOSD.

Reader2 Itisamodethatthescreenisadjustedtothebestforthecartoon.Ifyouwant

screenmorebright,youcancontrolbrightnessinMenuOSD.

ReaderOff Itisamodethatreadermodeisoff.

Eachoptionisexplainedbelow.



NOTE

IfoptionofReaderModeisReader1orReader2,PictureModewillautomaticallybeCustomand

SuperEnergySavingwillautomaticallybeOff.

ENG

ENGLISH

CUSTOMIZING SETTINGS

SUPERENERGYSAVING

Press

FUNC.

buttononthebottomoftheMonitorsetto

displaythe

FUNC.

OSD.

 Enterto

SUPERENERGYSAVING

bypressingthe▼

button.

 Settheoptionsbypressingthe◄or►or▼buttons.

 Select

EXIT

toleavetheOSDmenu.Toreturntothe

uppermenuorsetothermenuitems,usetheuparrow

( )button.

Eachoptionisexplainedbelow.

SUPERENERGYSAVING Description

High

EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-highefficientfunction.

Low

EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-lowefficientfunction.

Off DisablesSUPERENERGYSAVING.





TOTALPOWERREDUCTION

:Howmuchpowerissavedwhileusingthemonitor.



TOTALCO2REDUCTION

:ChangetheTOTALPOWERREDUCTIONtoCO2.



SAVINGDATA(W/h)

546mm

(21.5inch)

584mm

(23inch)

600mm

(23.6inch)

686mm

(27inch)

SUPERSAVING(High)

4W/h 4W/h 4W/h 6W/h

SUPERSAVING(Low)

2W/h 2W/h 2W/h 3W/h



SavingDatadependsonthePanel.So,thosevaluesshouldbedifferentfromeachpanelandpanel

vendor.IfoptionofSuperEnergySavingisHighorLow,monitorluminancebecomehigherorlower

dependonsource.



LGcalculatedthesevaluesbyusing

“broadcastvideosignal”

(includingbroadcastvideo:IEC62087)



SUPERSAVINGreferstohowmuchpowercanbesavedusingtheSUPERENERGYSAVING

function.



IfoptionofSuperEnergySavingisHighorLow,PictureModewillautomaticallybeCustomand

ReaderModewillautomaticallybeReaderOff.

NOTE

FUNC.Setting

ENG

ENGLISH

CUSTOMIZING SETTINGS

PictureMode

 Press

FUNC.

buttonon thebottomoftheMonitorset

todisplaythe

FUNC.

OSD.

 Select

PictureMode

bypressingthe►button.

 Enterto

PictureMode

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

Select

EXIT

toleavetheOSDmenu.Toreturntothe

uppermenuorsetothermenuitems,usetheup

arrow( )button.

PictureMode Description

Custom Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.

Text Itisamodethatthescreenisadjustedtothebestforthetextworks.

Photo Itisamodethatthescreenisadjustedtothebesttoviewpictures.

Cinema Itisamodethatthescreenisadjustedtothebesttoviewthevideos.

Game Itisamodethatthescreenisadjustedtothebesttoplayagame.

Eachoptionisexplainedbelow.

PictureMode Description

Custom Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.

Vivid1 Adjuststhevideoimagefortheretailenvironmentbyenhancingthecontrast,brightness,Colour,

andsharpness.

Vivid2

Standard Adjuststheimageforthenormalenvironment.

Cinema Itisamodethatthescreenisadjustedtothebesttoviewthevideos.



NOTE

IfoptionofPictureModeisnon-Custom,ReaderModewillautomaticallybeReaderOffandSuper

EnergySavingwillautomaticallybeOff.

ENG

ENGLISH

CUSTOMIZING SETTINGS



NOTE



Whenmonitorgoestopowersavingmodewithpcsavingoption->Pressinganybutton->OSD

appearandusershouldpressdualbutton->Usercanbringbacktonormalmode.

DUALDISPLAY

Press

FUNC.

buttononthebottomoftheMonitorset

todisplaythe

FUNC.

OSD.

 Select

DUALDISPLAY

bypressingthe►button.

 Enterto

DUALDISPLAY

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

 Select

EXIT

toleavetheOSDmenu.Toreturntothe

uppermenuorsetothermenuitems,usetheup

arrow( )button.

*Beforeusingbelowfunctions,pleaseinstallDUALSMARTSOLUTIONprogramme.

Eachoptionisexplainedbelow.

DUALDISPLAY Description

Clone ByselectingClone,usercanusesecondarymonitorasdonemodeofprimarymonitor.

Extended ByselectingExtended,usercanusesecondarymonitorasextendedmodeofprimary

monitor.

Off IfselectOff,DUALDISPLAYisoff.

DUALWEB

Press

FUNC.

buttononthebottomoftheMonitorset

todisplaythe

FUNC.

OSD.

 Select

DUALWEB

bypressingthe►button.

 Enterto

DUALWEB

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

 Select

EXIT

toleavetheOSDmenu.Toreturntothe

uppermenuorsetothermenuitems,usetheup

arrow( )button.

*Beforeusingbelowfunctions,pleaseinstallDUALSMARTSOLUTIONprogramme.

Eachoptionisexplainedbelow.

DUALWEB Description

On Helpusertobrowsewebefficientlybydividinginhalf.Helptoarrangeandmove

windowsonscreen.Helpusertocontroldividedwindowsratio.

Off IfselectOff,DUALWEBisoff.

ENG

ENGLISH

TROUBLESHOOTING

Checkthefollowingbeforecallingforservice.

Noimageappears

Isthepowercordofthedisplay

connected?





Checkandseeifthepowercordisconnectedproperlytothepower

outlet.

Isthepowerindicatorlighton?





PressthePowerbutton.

Isthepoweronandthepower

indicatorWhite?





Adjustthebrightnessandthecontrast.

Isthepowerindicatorflickering?





Ifthedisplayisinpowersavingmode,trymovingthemouseor

pressinganykeyonthekeyboardtobringupthescreen.





TrytoturnonthePC.

Doyouseean"OUTOFRANGE"

messageonthescreen?





ThismessageappearswhenthesignalfromthePC(videocard)is

outofhorizontalorverticalfrequencyrangeofthedisplay.Seethe

'Specifications'sectionofthismanualandconfigureyourdisplay

again.

Doyouseea"NOSIGNAL"

messageonthescreen?





Whenthemonitorison"No-Signal"in5minutes,themonitorgoesto

DPMmode.

Doyouseea"OSDLOCKED"messageonthescreen?

Doyousee“OSDLOCKED”when

youpushMENUbutton?





Youcansecurethecurrentcontrolsettings,sothattheycannotbe

inadvertentlychanged.YoucanunlocktheOSDcontrolsatanytime

bypushingtheMENUbuttonforseveralseconds:themessage“OSD

UNLOCKED”willappear.

Displayimageisincorrect

DisplayPositionisincorrect.





Pressthe

AUTO

buttontoautomaticallyadjustyourdisplayimageto

theidealsetting.

Onthescreenbackground,vertical

barsorstripesarevisible.





Pressthe

AUTO

buttontoautomaticallyadjustyourdisplayimageto

theidealsetting.

Anyhorizontalnoiseappearingin

anyimageorcharactersarenot

clearlyportrayed.





Pressthe

AUTO

buttontoautomaticallyadjustyourdisplayimageto

theidealsetting.





Check

ControlPanel►Display►Settings

andadjustthedisplay

totherecommendedresolutionoradjustthedisplayimagetotheideal

setting.Setthecolorsettinghigherthan24bits(truecolor).

ENG

ENGLISH

TROUBLESHOOTING

Displayimageisincorrect

Thescreencolorismonoor

abnormal.





Checkifthesignalcableisproperlyconnectedanduseascrewdriver

tofastenifnecessary.





Makesurethevideocardisproperlyinsertedintheslot.





Setthecolorsettinghigherthan24bits(truecolor)at

ControlPanel



►



Settings

Thescreenblinks.





Checkifthescreenissettointerlacemodeandifyes,changeittothe

recommendresolution.

Doyouseean"Unrecognizedmonitor,Plug&Play(VESADDC)monitorfound"message?

Haveyouinstalledthedisplay

driver?





BesuretoinstallthedisplaydriverfromthedisplaydriverCD(or

diskette)thatcomeswithyourdisplay.Or,youcanalsodownloadthe

driverfromourwebsite:http://www.lg.com.





MakesuretocheckifthevideocardsupportsPlug&Playfunction.





Check

ControlPanel►Display►Settings

andseeifthefrequencyortheresolutionwere

changed.Ifyes,readjustthevideocardtotherecommendresolution.



Iftherecommendedresolution(optimalresolution)isnotselected,lettersmaybeblurredandthe

screenmaybedimmed,truncatedorbiased.Makesuretoselecttherecommendresolution.



ThesettingmethodcandifferbycomputerandO/S(OperationSystem),andresolutionmentioned

abovemaynotbesupportedbythevideocardperformance.Inthiscase,pleaseasktothecomputer

orthevideocardmanufacturer.

CAUTION

Thescreenisflickering.

Didyouselecttherecommended

resolution?





IftheselectedresolutionisHDMI

1080i

60/50Hz,thescreenmay

beflickering.Changetheresolutiontotherecommendedresolution

1080P

ENG

ENGLISH

SPECIFICATIONS

SPECIFICATIONS

Display ScreenType 54.6cm(21.5inch)FlatPanelActivematrix-TFTLCDAnti-

Glarecoating

Visiblediagonalsize:54.6cm

PixelPitch 0.247mmx0.247mm(PixelPitch)

SyncInput HorizontalFrequency 30kHzto83kHz(Automatic)

VerticalFrequency 56Hzto75Hz(D-SUB/DVI-D)

56Hzto61Hz(HDMI)

InputForm SeparateSync.Digital

VideoInput SignalInput 15pinD-SUBConnector/DVI-DConnector(Digital)

HDMIConnector

InputForm RGBAnalog(0.7Vp-p/75ohm),Digital

Resolution Max D-SUB(Analog):1920x1080@60Hz

DVI/HDMI(Digital):1920x1080@60Hz

Recommend VESA1920x1080@60Hz

Plug&Play DDC2B(Analog,Digital,HDMI)

Power

Consumption

OnMode:21W(ENERGYSTAR®standard)*

SleepMode≤0.3W

OffMode≤0.3W

PowerInput 19V

1.2A

AC-DCAdapter

TypeADS-40SG-19-319025G,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPG-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPBR-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPI-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPCU-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPB-2,manufacturedbySHENZHENHONORELECTRONIC

orTypeLCAP21,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-A,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-E,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-I,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-B,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypePSAB-L203A,manufacturedbyLGInnotekCo.,Ltd

orTypePSAB-L202B,manufacturedbyLGInnotekCo.,Ltd

orTypePSAB-L202C,manufacturedbyLGInnotekCo.,Ltd

orTypePSAB-L202D,manufacturedbyLGInnotekCo.,Ltd

OUTPUT:

19V 1.3A

Dimensions

(WidthxHeightx

Depth)

WithStand 50.8cmx41.7cmx18.8cm

WithoutStand 50.8cmx31.6cmx6.0cm

Weight 2.6kg

TiltRange -3°to20°

Environmental

conditions

OperatingTemperature

OperatingHumidity

10°Cto35°C

10%to80%

StorageTemperature

StorageHumidity

-20°Cto60°C

5%to90%non-Condensing

StandBase Attached(),Detached(O)

Powercord Wall-outlettype

Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct

functions.

*Thepowerconsumptionlevelcanbedifferentbyoperatingconditionandmonitorsetting.

*TheOnmodepowerconsumptionismeasuredwithENERGYSTAR®teststandard.

*ENERGYSTAR®isaUSregisteredmarkoftheUnitedStatesEnvironmentalProtectionAgency.

22M45VQ

ENG

ENGLISH

SPECIFICATIONS

SPECIFICATIONS

Display ScreenType 58.4cm(23inch)FlatPanelActivematrix-TFTLCDAnti-

Glarecoating

Visiblediagonalsize:58.4cm

PixelPitch 0.265mmx0.265mm(PixelPitch)

SyncInput HorizontalFrequency 30kHzto83kHz(Automatic)

VerticalFrequency 56Hzto75Hz(D-SUB/DVI-D)

56Hzto61Hz(HDMI)

InputForm SeparateSync.Digital

VideoInput SignalInput 15pinD-SUBConnector/DVI-DConnector(Digital)

HDMIConnector

InputForm RGBAnalog(0.7Vp-p/75ohm),Digital

Resolution Max D-SUB(Analog):1920x1080@60Hz

DVI/HDMI(Digital):1920x1080@60Hz

Recommend VESA1920x1080@60Hz

Plug&Play DDC2B(Analog,Digital,HDMI)

Power

Consumption

OnMode:21W(ENERGYSTAR®standard)*

SleepMode≤0.3W

OffMode≤0.3W

PowerInput 19V

1.3A
