Table of contents
ausI nst r uct i on manual
8 Intended use . . . . . . . . . . . . . . . . 5
( Safety instructions. . . . . . . . . . . . 5
Before you switch ON the
appliance . . . . . . . . . . . . . . . . . . . . . 5
Delivery. . . . . . . . . . . . . . . . . . . . . . . . 5
Installation. . . . . . . . . . . . . . . . . . . . . . 6
In daily use . . . . . . . . . . . . . . . . . . . . . 7
Damage . . . . . . . . . . . . . . . . . . . . . . . 7
Disposal . . . . . . . . . . . . . . . . . . . . . . . 7
Door lock . . . . . . . . . . . . . . . . . . . . . . 9
7 Environmental protection . . . . . 10
Packaging. . . . . . . . . . . . . . . . . . . . . 10
Old appliances . . . . . . . . . . . . . . . . . 10
* Getting to know your
appliance . . . . . . . . . . . . . . . . . . 11
Control panel . . . . . . . . . . . . . . . . . . 11
Appliance interior . . . . . . . . . . . . . . . 11
Overview of menu. . . . . . . . . . . . . . . 12
, Rinse aid . . . . . . . . . . . . . . . . . . . 14
Setting amount of rinse aid. . . . . . . . 14
Detergent with a rinse aid
component . . . . . . . . . . . . . . . . . . . . 14
Switching off rinse aid refill
indicator . . . . . . . . . . . . . . . . . . . . . . 14
- Utensils. . . . . . . . . . . . . . . . . . . . 15
Not suitable . . . . . . . . . . . . . . . . . . . . 15
Glass and utensil damage. . . . . . . . . 15
Loading the dishwasher . . . . . . . . . . 15
Upper basket. . . . . . . . . . . . . . . . . . . 15
Lower basket. . . . . . . . . . . . . . . . . . . 16
Cutlery basket . . . . . . . . . . . . . . . . . . 16
Cutlery drawer . . . . . . . . . . . . . . . . . . 16
Etagere . . . . . . . . . . . . . . . . . . . . . . . 17
Folding spikes . . . . . . . . . . . . . . . . . . 18
Small items holder. . . . . . . . . . . . . . . 18
Knife rack . . . . . . . . . . . . . . . . . . . . . 18
Baking sheet spray head. . . . . . . . . . 19
Unloading the dishwasher . . . . . . . . . 19
Adjusting the height of the
basket . . . . . . . . . . . . . . . . . . . . . . . . 19
. Detergent . . . . . . . . . . . . . . . . . . 21
Adding detergent. . . . . . . . . . . . . . . . 21
/ Overview of programmes . . . . . 23
Programme selection . . . . . . . . . . . . 24
Information for test institutes . . . . . . . 24
0 Additional functions . . . . . . . . . 25
Express Wash/ Speed Perfect
(VarioSpeed) . . . . . . . . . . . . . . . . . . . 25
Half load . . . . . . . . . . . . . . . . . . . . . . 25
hygienePlus (HygienePlus) . . . . . . . . 25
intensiveZone . . . . . . . . . . . . . . . . . . 25
Extra Dry . . . . . . . . . . . . . . . . . . . . . . 25
aus
4
1 Operating the appliance . . . . . . 26
Changing the settings . . . . . . . . . . . .26
AquaSensor . . . . . . . . . . . . . . . . . . . .26
Remaining running time display. . . . .26
Sensor setting . . . . . . . . . . . . . . . . . .26
ExtraDry . . . . . . . . . . . . . . . . . . . . . . .27
Auto Power Off . . . . . . . . . . . . . . . . .27
EmotionLight . . . . . . . . . . . . . . . . . . .27
TimeLight . . . . . . . . . . . . . . . . . . . . . .27
Infolight . . . . . . . . . . . . . . . . . . . . . . .27
Changing start programme . . . . . . . .27
Tone volume . . . . . . . . . . . . . . . . . . .27
Button volume . . . . . . . . . . . . . . . . . .28
Factory setting . . . . . . . . . . . . . . . . . .28
Switching on the appliance . . . . . . . . 28
Time preselection . . . . . . . . . . . . . . .28
Programme end. . . . . . . . . . . . . . . . .28
Switching off the appliance . . . . . . . .28
Interrupting the programme . . . . . . . .29
Terminating the programme . . . . . . .29
Changing the programme . . . . . . . . .29
2 Cleaning and maintenance . . . 29
Overall status of the dishwasher . . . . 29
EasyClean . . . . . . . . . . . . . . . . . . . . .30
Rinse aid . . . . . . . . . . . . . . . . . . . . . .31
Filters. . . . . . . . . . . . . . . . . . . . . . . . .31
Spray arms . . . . . . . . . . . . . . . . . . . .32
3 Fault, what to do? . . . . . . . . . . .32
Waste water pump . . . . . . . . . . . . . . 33
Fault table . . . . . . . . . . . . . . . . . . . . 34
4 Customer service . . . . . . . . . . . .41
5 Installation and connection. . . .41
Contents of package . . . . . . . . . . . . 41
Safety instructions . . . . . . . . . . . . . . 41
Delivery . . . . . . . . . . . . . . . . . . . . . . 42
Technical specifications . . . . . . . . . . 42
Installation . . . . . . . . . . . . . . . . . . . . 42
Drainage connection . . . . . . . . . . . . 42
Drinking water connection . . . . . . . . 43
Hot water connection . . . . . . . . . . . . 43
Electrical connection . . . . . . . . . . . . 44
Removal . . . . . . . . . . . . . . . . . . . . . . 44
Transporting . . . . . . . . . . . . . . . . . . . 45
Protection against frost
(Emptying the appliance) . . . . . . . . . 45
Intended use aus
5
8 Intended use
I nt ended use
■ This appliance is intended
for use in the home and
domestic environments.
■ Use the dishwasher only in
the home and only for its
designated purpose: for
washing domestic dishes.
■ This appliance is intended
for use up to a maximum
altitude of 4000 metres
above sea level.
( Safety instructions
Safety instructions
This appliance may be used by
children over the age of 8 years
old and by persons with
reduced physical, sensory or
mental capabilities or by
persons with a lack of
experience or knowledge if they
are supervised or are instructed
by a person responsible for
their safety how to use the
appliance safely and have
understood the associated
hazards.
Children must not play with, on,
or around the appliance.
Children must not clean the
appliance or carry out general
maintenance unless they are at
least 8 years old and are being
supervised.
Keep children below the age of
8 years old at a safe distance
from the appliance and power
cable.
Before you switch ON the
appliance
Please read the instructions for
use and installation carefully.
They contain important
information on how to install,
use and maintain the appliance.
Retain all documents for later
use or for the subsequent
owner.
You can download the
instructions for use from our
website free of charge. The
relevant Internet address can
be found overleaf on these
instructions for use.
Delivery
1. Check the packaging and
dishwasher immediately for
damage caused in transit.
Do not switch on a damaged
appliance, but contact your
supplier.
2. Please dispose of the
packaging material in an
environmentally friendly
manner.
3. Do not let children play with
packaging and its parts.
There is a risk of suffocation
from collapsible boxes and
film.
aus Safety instructions
6
Installation
■ Following installation, ensure
that the back of the
dishwasher is not freely
accessible (protection
against contact due to hot
surface).
■ Install and connect the
appliance according to the
installation and assembly
instructions.
■ Prior to installation,
disconnect the dishwasher
from the power supply.
■ Ensure that the protective
conductor system of the
domestic supply has been
correctly installed.
■ The electrical connection
conditions must correspond
with the specifications on the
dishwasher rating plate 92.
■ If the power cord of this
appliance is damaged, it
must be replaced with a
particular power cord.
To prevent injury, the power
cord may be purchased from
customer service only.
■ If the dishwasher is installed
in a high-sided unit, the unit
must be secured properly.
■ If the dishwasher is installed
below or above other
domestic appliances, follow
the information for
installation in combination
with a dishwasher in the
installation instructions for
the particular appliances.
■ Also follow the installation
instructions for the
dishwasher to ensure that all
appliances are operated
safely.
■ If there is no information or if
the installation instructions
do not include the
appropriate information,
contact the manufacturer of
these appliances to ensure
that the dishwasher can be
installed above or below
these appliances.
■ If you cannot obtain any
information from the
manufacturer, you must not
install the dishwasher above
or below these appliances.
■ If you install a microwave
oven above the dishwasher,
the microwave oven may be
damaged.
■ Install built-under or
integratable appliances only
under continuous worktops
which have been screwed to
adjacent cupboards to
ensure stability.
■ Do not install the appliance
near heat sources (radiators,
heat storage tanks, cookers
or other appliances which
generate heat) and do not
install under a hob.
Safety instructions aus
7
■ Please note that the
insulation material of the
dishwasher power cord may
melt next to heat sources
(e.g. heating / hot water
installations) or hot
appliance parts. Make sure
that the power cord of the
dishwasher never comes into
contact with heat sources or
hot appliance parts.
■ After installing the appliance,
ensure that the plug is easily
accessible. ~ "Electrical
connection" on page 44
■ For some models:
The plastic housing on the
water connection contains an
electric valve. The supply
hose contains electrical
connection cables. Do not
cut through the supply hose.
Do not immerse the plastic
housing in water.
In daily use
Read and observe the safety
information and instructions for
use on the packaging for
cleaning and rinsing agents.
Damage
■ The appliance may be
repaired and opened up by a
technician only. To do this,
disconnect the appliance
from the power supply. Pull
out the mains plug or switch
off the fuse. Turn off the tap.
■ If the appliance is damaged,
especially the control panel
(cracks, holes, broken
buttons), or the door function
is impaired, stop operating
the appliance. Pull out the
mains plug or switch off the
fuse. Turn off tap, call
customer service.
Disposal
1. Make redundant appliances
unusable to prevent
subsequent accidents.
2. Dispose of the appliance in
an environmentally friendly
manner.
aus Safety instructions
8
:Warning
Risk of injury!
■ To prevent injuries, e.g.
caused by stumbling, open
the dishwasher only briefly in
order to load and unload the
dishwasher.
■ Knives and other utensils
with sharp points must be
placed with the points
downwards in the cutlery
basket*1Z or horizontally
on the knife shelf* or in the
cutlery drawer*1*.
■ Do not lean or sit on the
open door.
■ In the case of free-standing
appliances, ensure that the
baskets are not overloaded.
The appliance could tip.
■ If the appliance is not in a
cavity and a side panel is
accessible, the door hinge
area must be covered at the
side for reasons of safety
(risk of injury). The covers
are available as optional
accessories from customer
service or specialist outlets.
* depending on the features of
your dishwasher
:Warning
Risk of explosion!
Do not add any solvents to the
rinsing compartment. Danger of
explosion!
:Warning
Risk of scalding!
Open the door carefully when
the programme is still running.
There is a risk of hot water
spraying out of the appliance.
:Warning
Risk to children!
■ If fitted, use the childproof
lock.
■ Do not allow children to play
with or operate the
appliance.
■ Keep children away from
detergents and rinse aid.
These may cause chemical
burns in the mouth, throat
and eyes or asphyxiation.
Safety instructions aus
9
■ Keep children away from
open dishwasher. There may
be small parts in the
dishwasher which children
could swallow and the water
inside the dishwasher is not
drinking water as it may
contain detergent residue.
■ Ensure that children do not
place fingers in the tablet
collecting tray 1B. Small
fingers could become caught
in the slots.
■ When opening and closing
the door on an eye-level
appliance, ensure that
children do not become
jammed or crushed between
the appliance door and the
cupboard door below.
■ Children could become
locked in the appliance
(danger of suffocation) or get
into another dangerous
situation.
Redundant appliances: Pull
out the mains plug, sever
and dispose of the power
cord. Destroy the door lock
so that the door can no
longer be closed.
Childproof lock (door lock) *
Door lock
The child-proof lock (door lock)
protects children from potential
hazards which the dishwasher
poses.
:Warning
Risk of suffocation!
Children may become locked in
the dishwasher and suffocate.
Always completely close the
appliance door when leaving
the dishwasher.
Activate the child-proof lock
(door lock) as follows:
1. Pull the catch of the
child-proof lock towards
yourself (1).
2. Close the door (2).
The child-proof lock is
activated.
aus Environmental protection
10
Open the door with activated
child-proof lock (door lock) as
follows:
1. Press the catch of the
child-proof lock to the right
(1).
2. Open the door (2).
Deactivate the child-proof lock
(door lock) as follows:
1. Press the catch of the
child-proof lock to the right
(1).
2. Press the catch of the
child-proof lock backwards
(2).
The childproof lock is
deactivated.
* depending on the features of
your dishwasher
7 Environmental
protection
Env i r o n ment al pr ot ec t i on
Both the packaging of new appliances
and the old appliances themselves
contain valuable raw materials and
recyclable materials.
Please dispose of the individual parts
separated according to type.
Please ask your dealer or inquire at
your local authority about current means
of disposal.
Packaging
All plastic parts of the appliance are
identified with internationally
standardised abbreviations (e.g. PS
polystyrene). Therefore, plastic waste
can be sorted out when the appliance is
being disposed of.
Please follow the safety instructions
under “Delivery” ~ Page 5.
Old appliances
Please follow the safety instructions
under “Disposal of your appliance”
~ Page 7.
This appliance has been
identified in accordance with the
European Directive 2012/19/EU
on Waste Electrical and
Electronic Equipment (WEEE).
The directive provides a
framework for the collection and
recycling of old appliances,
which is valid across the EU.
Getting to know your appliance aus
11
* Getting to know your
appliance
Get t i ng to k now your appl i ance
Diagrams of the control panel and the
interior of the appliance can be found at
the front of the manual. Individual
positions are referred to in the text.
Control panel
See Fig. ~ Page 2
* depending on the features of your
dishwasher
** number depending on the features of
your dishwasher
Appliance interior
See Fig. ~ Page 2
* depending on the features of your
dishwasher
( On/off switch
0 Programme buttons **
8 Display "Check water supply"
@ Rinse aid refill indicator
H Selection buttons
P Time preselection
X Additional functions/programme
buttons **
` START button
h Display window
)" Door opener
1" Interior light *
1* Cutlery drawer *
12 Top basket
1: Upper spray arm
1B Tablet collecting tray
1J Lower spray arm
1R Filters
1Z Cutlery basket *
1b Bottom basket
1j Dispenser for rinse aid
9" Detergent dispenser
9* Lock for detergent dispenser
92 Rating plate
aus Getting to know your appliance
12
Overview of menu
The dishwasher has been preset with
certain settings for your convenience.
The settings can be found in the
individual chapters. You can change
these factory settings.
Here’s how to change the settings:
1. Switch on ON/OFF switch (.
2. Press and hold the ‹ button
for 3 seconds.
In the display window h you will
see §:‹... and ‘ .
3. Press the ‹ button to access
the individual settings.
4. Adjust the setting using the buttons
+ and - H.
5. Press and hold the ‹ button
for 3 seconds.
The chosen setting has now been
stored in your dishwasher.
You have the option of resetting all
changed settings back to the original
factory settings.
Tip: If you want to change a number of
settings, first make all your changes one
after another. Then press the ‹
button for 3 seconds. All the settings
will then be stored in the dishwasher.
Setting up Factory setting Description
§ Rinse aid
§:‹‹ - §:‹‡
§:‹† Amount of rinse aid affects drying. When
using Multitabs, select setting 0.
†“ Sensor setting
†“:‹‹ - †“:‹ƒ
†“:‹‹ Adjustment of soiling detection for
optimum cleaning result.
š ExtraDry
š:‹‹ - š:‹‚
š:‹‹ / Off Improved drying for glasses and plastic
tableware.
‘ Hot water *
‘:‹‹ - ‘:‹‚
‘:‹‹ / Off The dishwasher can be connected to
either hot (40-60°C) or cold water
(<40°C).
˜ Auto Power Off
˜:‹‹ - ˜:‹ƒ
˜:‹‚ Appliance automatically switches off at
the end of each wash.
“ EmotionLight *
“:‹‹ - “:‹‚
“:‹‚ / On Interior light.
† TimeLight *
†:‹‹ - †:‹‚
†:‹‚ / On While a programme is running, status
information is projected onto the floor.
‚ Infolight *
‚:‹‹ - ‚:‹‚
‚:‹‚ / On Light is projected to signal an active
washing cycle.
* depending on the configuration of your specific dishwasher
Getting to know your appliance aus
13
--------
†˜ Start up programme
†˜:‹‹ - †˜:‹‚
†˜:‹‹ When you switch on, the most recently
selected programme appears.
†– Tone volume *
†–:‹‹ - †–:‹„
†–:‹ƒ Volume of the signal at the end of a
programme.
›– Button volume *
›–:‹‹ - ›–:‹„
›–:‹ƒ Volume when using button.
§“ Factory setting ¢:“†
Confirm with +
Reset to the factory setting.
Setting up Factory setting Description
* depending on the configuration of your specific dishwasher
aus Rinse aid
14
, Rinse aid
Ri n s e ai d
The rinse aid ensures stain-free dishes
and clear glasses. Use only rinse aid
for domestic dishwashers. As soon as
the rinse aid refill indicator @ lights up
in the control panel, there is still a rinse
aid reserve of 1-2 rinse cycles. Top up
the rinse aid.
Top up the rinse aid as follows:
1. Open dispenser 1j; press lug on
the lid (1) and lift (2).
2. Add rinse aid up to the max. mark.
3. Close the lid.
The lid "clicks" into position.
4. Remove overflowed rinse aid with a
cloth.
This prevents excessive frothing
during the next rinse cycle.
Setting amount of rinse aid
You can set the amount of rinse aid that
should be added to a value between
§:‹‹ and §:‹‡. Setting the amount of
rinse aid to be dispensed to §:‹† will
give you a very good drying result. The
factory setting is §:‹†. Do not change
the amount of rinse aid unless there are
streaks or water stains on the utensils.
Set a lower level to avoid streaks. Set a
higher level to avoid water stains.
Here’s how to set the amount of rinse
aid:
1. Switch on ON/OFF switch (.
2. Press and hold the ‹ button
for 3 seconds.
The value §:‹... and ‘ will appear in
the display window h. .
3. Adjust the setting using the buttons -
and + H.
4. Press and hold the ‹ button
for 3 seconds.
The chosen setting has now been
stored in your dishwasher.
Using detergent with a rinse
aid component
Det er gent wi t h a ri nse ai d component
In general, you can use detergent with
a rinse aid component up to a water
hardness level of 21 °dH (37 °fH, 26
°Clark, 3.7 mmol/L) without adding
rinse aid. Above a water hardness value
of 21 °dH, use additional rinse aid.
Switching off rinse aid refill
indicator
If the rinse aid refill indicator @
bothers you (e.g. if you are using a
combination detergent with a rinse aid
component), you can switch off the
rinse aid refill indicator.
Proceed as described under "Setting
rinse aid quantity" and set the level to
§:‹‹. The rinse aid refill indicator @ is
switched off.
2
1
PD[
Utensils aus
15
- Utensils
Ut ensi l s
Not suitable
■ Cutlery and utensils made of wood.
■ Delicate decorative glasses, craft
and antique utensils. These decors
are not dishwasher-proof.
■ Plastic parts not resistant to heat.
■ Copper and tin utensils.
■ Utensils which are soiled with ash,
wax, lubricating grease or ink.
Aluminium and silver parts have
a tendency to discolour and fade during
the wash cycle. Even some types of
glass (e.g. crystal glass objects) may
turn cloudy after many wash cycles.
Glass and utensil damage
Causes:
■ Glass type and glass production
process.
■ Chemical composition of the
detergent.
■ Water temperature of the wash
programme.
Recommendation:
■ Use only glasses and porcelain
which the manufacturer designates
as dishwasher-proof.
■ Use a detergent which protects
utensils.
■ Take glass and cutlery out of
the dishwasher as soon as possible
after the programme ends.
Loading the dishwasher
1. Remove large food remnants. It
is not necessary to prerinse utensils
under running water.
2. Place the utensils so that
– they are secure and cannot tip
over.
– all utensils with their openings
face down.
– parts with curves or indentations
are at an angle, thereby allowing
water to drain.
– does not obstruct rotation of the
two spray arms 1: and 1J.
Very small utensils should not be
washed in the machine, as they may fall
out of the baskets.
Upper basket
Arrange cups and glasses in the upper
basket 12.
* depending on the features of your
dishwasher
aus Utensils
16
Note: Utensils must not be placed
above the tablet collecting tray 1B.
These may block the lid of the detergent
dispenser and prevent it from opening
fully.
Lower basket
Arrange pots and plates in the lower
basket 1b.
* depending on the features of your
dishwasher
Tip: Heavily soiled utensils (pans)
should be placed in the lower basket.
The more powerful spray jet provides a
better dishwashing result.
Tip: Other examples, such as the best
way of loading your dishwasher, can be
found on our homepage. These can be
downloaded free of charge. The
corresponding Internet address can be
found on the back page of these
instructions for use.
Cutlery basket *
Cu t l e r y basket
Place cutlery, always unsorted with the
tips face down, in the cutlery basket *.
To prevent injuries, place long, pointed
implements and knives on the knife
shelf *.
* depending on the features of your
dishwasher
Cutlery drawer *
Cu t l e r y dr awer
Arrange the cutlery in the cutlery drawer
1* as illustrated. Separately arranged
utensils are easier to remove after
washing.
Utensils aus
17
You can take out the cutlery drawer.
Depending on the features of your
dishwasher, you can fold down the side
shelves to provide more room for taller
items of cutlery. The front rows of
prongs can be folded down to provide
room for wider handles.
* depending on the features of your
dishwasher
Etagere *
Et a g e r e
The etagere and the space underneath
can be used for small cups and glasses
or for larger items of cutlery, such as
wooden spoons or serving cutlery. If
you do not require the etagere, it can be
folded up.
* Depending on the features of your
dishwasher, you can adjust the etagere
3 times the height.
Adjust the height of the etagere as
follows:
1. Position the etagere vertically and
pull upwards.
2. Push etagere at a slight angle
downwards to the required height
(1, 2, or 3).
3. Engage etagere.
Etagere “clicks” into position.
CLICK
&/,&.
aus Utensils
18
Folding spikes *
Fol d i n g spi kes
* Depending on the features of your
dishwasher, the spikes can be folded
down. This facilitates arrangement of
pots, bowls and glasses.
Fold down the spikes as follows:
1. Press lever forwards (1).
2. Fold down spikes (2).
Small items holder *
Smal l items hol der
* Depending on the features of your
dishwasher, the upper basket is fitted
with small items holders. The small
items holders can be used to securely
attach light plastic parts.
Knife rack *
Kni f e rack
* Depending on the features of your
dishwasher, the upper basket is fitted
with a knife shelf. Long knives and other
utensils can be placed in the knife shelf.
Utensils aus
19
Baking sheet spray head *
Ba k i n g s heet spr ay head
* depending on the features of your
dishwasher
Large trays or grilles as well as large
plates (gourmet plates, pasta plates,
dinner plates) can be cleaned with this
spray head.
Insert the spray head as follows:
1. Remove upper basket 12.
2. Insert spray head as illustrated and
turn to the right.
Spray head is engaged.
To ensure that the spray jet can reach
all parts, arrange the baking sheets as
illustrated (max. 2 baking sheets and 2
grilles).
Note: Ensure that the dishwasher is
always operated with upper basket 12
or baking tray spray head.
Unloading the dishwasher
To prevent water from dripping off the
upper basket onto the utensils in the
lower basket, it is recommended
to empty the appliance from the bottom
up.
Tip: Hot utensils are sensitive to shock!
Therefore, when the programme ends,
leave the utensils to cool down in the
dishwasher until they can be handled.
Note: When the programme ends,
water droplets can still be seen inside
the appliance. This does not affect the
drying of the utensils.
Adjusting the height of the
basket *
Ad j u s t i n g the he i g ht of the bask et
* depending on the features of your
dishwasher
If required, the height of the upper
basket 12 can be adjusted to create
more space for taller utensils either in
the upper or lower basket.
Appliance height 81.5 cm
With cutlery basket Upper
basket
Lower
basket
Setting 1 max. ø 22 cm 31 cm
Setting 2 max. ø 24.5 cm 27.5 cm
Setting 3 max. ø 27 cm 25 cm
With cutlery drawer Upper
basket
Lower
basket
Setting 1 max. ø 16 cm 31 cm
Setting 2 max. ø 18.5 cm 27.5 cm
Setting 3 max. ø 21 cm 25 cm
aus Utensils
20
Appliance height 86.5 cm
Arrange large plates up to a diameter of
31/34* cm in the lower basket 1b as
illustrated.
* depending on the features of your
dishwasher
Upper basket with side levers
1. Pull out upper basket 12.
2. Hold the sides of the basket along
the upper edge.
This prevents it from suddenly
dropping.
3. To lower the upper basket; press in
both levers on the left and right on
the outside of the basket. The upper
basket lowers.
4. To lift the upper basket; grip the
sides of the upper basket along the
upper edge and lift.
5. Ensure that both sides of the upper
basket are at the same height.
6. Push in upper basket.
Upper basket with upper and
lower pairs of rollers
1. Pull out upper basket 12.
2. Remove upper basket.
3. Re-attach upper basket to the upper
(Setting 3) or lower (Setting 1)
rollers.
4. Push in upper basket.
With cutlery basket Upper
basket
Lower
basket
Setting 1 max. ø 24 cm 34 cm
Setting 2 max. ø 26.5 cm 30.5 cm
Setting 3 max. ø 29 cm 28 cm
With cutlery drawer Upper
basket
Lower
basket
Setting 1 max. ø 18 cm 34 cm
Setting 2 max. ø 20.5 cm 30.5 cm
Setting 3 max. ø 23 cm 28 cm
detergent aus
21
. Detergent
det er gent
You can use tablets as well as powder
or liquid detergents for dishwashers, but
never use washing-up liquid. The
dosage can be individually adjusted
with powder or a liquid detergent
according to the degree of soiling.
Tablets contain an adequately large
amount of active ingredients for all
cleaning tasks. Modern, powerful
detergents predominantly use a
low-alkaline formulation with enzymes.
Enzymes break down starch and
remove protein. To remove coloured
stains (e.g. tea, ketchup), oxygen-based
bleaching agents are generally used.
Note: To ensure a good washing result,
always follow the instructions on the
detergent packaging!
If you have further questions,
we recommend that you contact
the detergent manufacturers’ helplines.
:Warning
Risk of injury and damage due to
non-observance of the safety
instructions for detergent and
rinse-aid products!
Always follow the safety instructions for
detergent products and rinse-aid
products.
Adding detergent
1. If the detergent dispenser 9" is still
closed, actuate locking bar 9* to
open it.
2. Pour detergent into the dry detergent
dispenser 9" only (insert tablet flat,
not on its edge).
3. Dosage: see manufacturer’s
instructions on the packaging. Use
graduated detergent dispenser.
Usually 20 ml–25 ml are adequate
for normal soiling. If using tablets,
one tablet is adequate.
15 ml
25 ml
50 ml
aus detergent
22
4. Close cover on the detergent
dispenser.
Cover “clicks” into position.
The detergent dispenser opens
automatically at the optimum time
depending on the programme. The
powder or liquid detergent is
distributed in the appliance and is
dissolved, the tablet falls into the
tablet collecting tray where it
dissolves in doses.
Tip: If the utensils are only lightly
soiled, slightly less than the indicated
amount of detergent is usually
adequate.
Suitable detergents and care products
can be purchased online via our
website or via customer service (see
back page).
Notes
■ If programmes are short, tablets
may not have full cleaning effect
due to different dissolving properties
and there may even be undissolved
detergent residue. It is
recommended to use washing
powder for these programmes.
■ The Intensive programme (on some
models) requires one tab only. When
using washing powder, you can
apply some of this cleaning agent
to the inside of the appliance’s door.
■ If using detergents in a water-soluble
protective cover: Take hold of the
cover with dry hands only and put
the detergent into an absolutely
dry detergent dispenser only,
otherwise the detergent may stick.
■ If you switch from combined
detergents to solo detergents,
ensure that the water softening
system * and amount of rinse aid
have been set to the correct value.
* depending on the features of your
dishwasher
CLICK
Overview of programmes aus
23
/ Overview of programmes
Over vi ew of pr ogr ammes
The max. possible number of programmes is illustrated in this overview. The
corresponding programmes for your appliance can be found on the fascia. The
programme data has been measured in the laboratory according to AS/NSZ 2007.
Note: The consumption figures depend on the selected programme and additional
functions. The programme duration will be different if the machine is short of rinse
additive or the function is turned off.
Type of utensils
and soiling
Programme Programme data
1.) Duration:
hs/mins
2.) Energy
consumption in
kWh
3.) Water
consumption in
litres
4.) With
Aquasensor
Possible
additional
options
Programme sequence
Pots, utensils and
cutlery
Highly soiled
± / °
Chef
70°
1.) 2:35 - 2:45
2.) 1,50 - 1,60
3.) 15
4.) 12
all
Intensive:
Prerinse
Clean 70°
Intermediate rinse
Final rinse 72°
Dry
Utensils and
cutlery
Normally soiled
Á / Ù
Auto
45° - 65°
1.) 1:45 - 2:55
2.) 0,95 - 1,60
3.) -
4.) 7 - 18
all
Sensor-controlled:
Is optimised according
to the soiling with the aid
of sensors.
Utensils and
cutlery
Normally soiled
â / à
Eco
45°
1.) 2:50
2.) 0,64
3.) 12
4.) -
all
Most economical
programme:
Prerinse
Clean 45°
Intermediate rinse
Final rinse 45°
Dry
sensitive utensils,
cutlery,
temperature-sensi
tive plastic and
glasses
slightly adhesive,
fresh food
remnants
é / è
Glass
40°
1.) 1:25 - 1:30
2.) 0,85 - 0,90
3.) 14
4.) 11
IntensivZone
VarioSpeed
Half load
Extra Dry
Particularly gentle:
Pre-rinse
Clean 40°
Intermediate rinse
Final rinse 60°
Drying
aus Overview of programmes
24
--------
Programme selection
You can select a suitable programme
according to the type of utensils and
type of soiling.
Information for test institutes
Test institutes can request the
conditions for running comparison tests
by sending an e-mail to
Quote the appliance number (ENr.)
and the production date (FD) which you
can find on the rating
plate 92 on the appliance door.
Utensils and
cutlery
Normally soiled
1h
65°
1.) 1:00
2.) 1,30
3.) 10
4.) -
Extra Dry
Time-optimised:
Clean 65°
Intermediate rinse
Final rinse 70°
Dry
Utensils and
cutlery
Lightly soiled
ñ / ð
Quick
45°
1.) 0:29
2.) 0,80
3.) 10
4.) -
Extra Dry
Time-optimised:
Clean 45°
Intermediate rinse
Final rinse 55°
all types
of utensils
Lightly soiled
ù / ø
Prerinse
1.) 0:15
2.) 0,05
3.) 4
4.) -
none
Cold rinse:
Prerinse
-
‰ / Š
Machine Care
1.) 1:30
2.) 0,90 - 1,06
3.) 9,5 - 12,5
4.) -
none
Machine cleaning
cycle 70°
Type of utensils
and soiling
Programme Programme data
1.) Duration:
hs/mins
2.) Energy
consumption in
kWh
3.) Water
consumption in
litres
4.) With
Aquasensor
Possible
additional
options
Programme sequence
Additional functions aus
25
0 Additional functions
Addi t i onal f unct i ons
* Depending on the features of your
dishwasher, you can select different
additional functions X.
Ÿ Express Wash/ Speed
Perfect/ (VarioSpeed) *
Ex p r e s s Wash/ Speed Pe r f e c t ( Var i oSpeed)
This function can reduce the running
time by approx. 20% to 50% depending
on the selected rinse programme. To
obtain optimum cleaning and drying
results at a reduced running time, water
and energy consumption are increased.
§ Half load *
Ha l f l oad
If you have only a few items to wash
(e.g. glasses, cups, plates), you can
switch to “half load”. This will save
water, energy and time. It is
recommended to put a little less
detergent in the detergent dispenser
than for a full load.
μ hygienePlus
(HygienePlus) *
hygi enePl us ( Hy gi enePl us )
This function increases the
temperatures and retains them for an
extra long time to obtain a defined
disinfection performance. Continuous
use of this function increases the
hygiene status. This additional option is
ideal for cleaning e.g. chopping boards
and baby bottles.
Ï intensiveZone *
i nt ensi veZone
Perfect for a mixed load. You can wash
very soiled pots and pans in the lower
basket together with normally soiled
utensils in the upper basket. The spray
pressure in the lower basket
is intensified, the rinsing temperature
is increased slightly.
¿ Extra Dry *
Ex t r a Dr y
An increased temperature during the
final rinse and an extended drying
phase ensure that even plastic parts dry
better. There is a slight increase in the
energy consumption.
aus Operating the appliance
26
1 Operating the
appliance
Oper at i ng the appl i ance
Changing the settings
The dishwasher has been preset with
certain settings for your convenience.
You can change these factory settings.
Here’s how to change the settings:
1. Switch on ON/OFF switch (.
2. Press and hold the ‹ button
for 3 seconds.
In the display window h you will
see §:‹... and ‘ .
3. Press the ‹ button to access
the individual settings.
4. Adjust the setting using the buttons -
and + H.
5. Press and hold the ‹ button
for 3 seconds.
The chosen setting has now been
stored in your dishwasher.
Tip: If you want to change a number of
settings, first make all your changes one
after another. Then press the ‹
button for 3 seconds. All the settings
will then be stored in the dishwasher.
AquaSensor *
AquaSensor
* depending on the features of your
dishwasher
The Aqua sensor is an optical
measuring device (light barrier) which
measures the turbidity of the rinsing
water.
The AquaSensor is used according
to the programme. If the AquaSensor is
active, “clean” rinsing water can be
transferred to the next rinse bath and
water consumption can be reduced by
3–6 litres. If the turbidity is greater,
the water is drained and is replaced
with fresh water. In the automatic
programmes the temperature
and running time can also be adjusted
to the degree of soiling.
Remaining running time
display
When the programme is selected, the
remaining programme time is indicated
in the display window h.
*After the programme has started, the
remaining running time is displayed on
the floor (only for settings Timelight
†:‹‚ and †:‹ƒ).
The running time is determined during
the programme by the water
temperature, the quantity of dishes as
well as the degree of soiling and may
vary (depending on the selected
programme).
* depending on the features of your
dishwasher
Sensor setting
In its automatic programmes the
appliance uses sensors to optimise
their operation. The sensors adjust the
strength of the automatic programmes
according to the amount and type of
soiling. You can choose from three
levels of sensitivity for the sensors.
Sensor setting †“:‹‹: This setting is
ideal for a mixed load and heavily soiled
utensils, but it also saves energy and
water.
Sensor setting †“:‹‚: This setting
adjusts the programme strength for the
effective removal of food remnants,
even if the amount of soiling is low. The
energy and water consumption is
adjusted accordingly.
Sensor setting †“:‹ƒ: This setting
adjusts the programme strength for
difficult conditions of use, for example
firmly dried on food remnants. This
setting is recommended if you are using
biological or eco detergents which
contain smaller quantities of active
agents. The energy and water
consumption is adjusted accordingly.
Operating the appliance aus
27
ExtraDry
The final rinse uses a higher
temperature which improves the drying
result (be careful if you have delicate
tableware). The running time may
increase slightly. You can switch the
function ExtraDry on š:‹‚ or off š:‹‹.
Auto Power Off (Automatic
switch off after end of
programme)
Au t o Powe r Off
To save energy, the dishwasher is
switched off 1 minute after
the programme ends. You can also
change this setting.
Possible settings are:
■ ˜:‹‹: The dishwasher does not
switch off automatically.
■ ˜:‹‚: The dishwasher switches off
after 1 minute.
■ ˜:‹ƒ: The dishwasher switches off
after 2 hours.
Note: Note that with the settings ˜:‹‚
and ˜:‹ƒ the interior lighting 1" is
switched off. To activate the interior
lighting, press the ON/OFF switch (.
EmotionLight (Interior
lighting) *
Emot i onLi ght
* depending on the configuration of
your specific dishwasher
EmotionLight 1" is the interior lighting
for your dishwasher. You can switch the
interior lighting on “:‹‚ or off “:‹‹.
Notes
■ Depending on the setting of
AutoPowerOff, the interior lighting is
either switched on or off.
■ Note that when the appliance is
switched on and the door is open,
the interior lighting will automatically
be switched off after 1 hour.
TimeLight (optical display
while a programme is
running) *
Ti meLi ght
*Depending on the features of your
dishwasher
While a programme is running, an
optical display (additional programme
information) is projected onto the floor
at the bottom of the appliance door. If
the base panel is pulled forwards or if
the appliance is installed at eye-level
flush with the furniture then this display
will not be visible. You can switch the
optical display on †:‹‚ or off †:‹‹.
Infolight *
Infoli ght
* depending on the configuration of
your specific dishwasher
While the programme is running, a light
spot shines on the floor under the
appliance door. Do not open the
appliance door until the light point is no
longer visible on the floor. If the
appliance door is not completely
closed, the light spot will flash *. If the
appliance is installed at eye-level, with
flush furniture front, the light point will
not be visible. You can switch the
Infolight on ‚:‹‚ or off ‚:‹‹.
Changing start programme *
Changi ng st ar t pr ogr amme
* depending on the features of your
dishwasher
You can change the “Start programme”
setting.
Tone volume
The end of the programme is indicated
by an audible signal. You can adjust the
tone volume from †–:‹‹ - †–:‹„.If the
signal tone at the end of the programme
is annoying, set the value to †–:‹‹
(tone volume off).
aus Operating the appliance
28
Button volume
When you are operating the dishwasher,
a signal sounds whenever a button is
pressed. You can adjust the volume of
the tone from ›–:‹‹ - ›–:‹„. If the
signal tone is annoying, set the value to
›–:‹‹ (button volume off).
Factory setting
You can reset all settings to the factory
setting.
Switching on the appliance
1. Turn tap fully on.
2. Switch on ON/OFF switch (.
The displays for the last programme
and last additional function selected
flash. These settings will be retained
unless another 0 programme key
is pressed. The expected
programme duration flashes on the
digital display h.
3. Press the START button `.
Programme sequence starts.
Time preselection *
Ti me pr esel ec t i on
* depending on the configuration of
your specific dishwasher
You can delay the start of the
programme by up to 24 hours.
Here’s how to set up the delay:
1. Switch on ON/OFF switch (.
2. Press the timer programming button
P - or +.
The display window h shows
‹‹h:‹‹m.
3. Keep pressing the timer
programming button P - or + until
the desired time is displayed.
4. Press START button `.
The delay timer has been activated.
5. To clear the specified delay, press
the button P - or + repeatedly until
the display window h shows
‹‹h:‹‹m.
Programme end
The programme has finished when the
value ‹‹h:‹‹m appears in the display
window h. If a value has been set for
the signal volume, then the end of the
programme is also indicated audibly by
a buzzer.
* The end of the programme is
displayed on the floor – provided the
TimeLight (optical display) is switched
on and is visible.
* depending on the features of your
dishwasher
Switching off the appliance
Shortly after the end of the
programme:
1. Switch off ON/OFF switch (.
2. Turn off water supply (does not
apply to appliances with Aqua-Stop).
3. Remove the utensils when they have
cooled down.
Note: When the programme ends,
leave the appliance to cool down a
while before opening it. This will prevent
steam from escaping and causing
long-term damage to your built-in
furniture.
Cleaning and maintenance aus
29
Interrupting the programme
Caution!
Expansion (overpressure) may cause
the appliance door to jump open and/or
water to escape! If the door was opened
on an appliance which has a hot water
connection or is heated, always leave
the door ajar for several minutes and
then close it.
1. Switch off ON/OFF switch (.
The LEDs go out. The programme is
saved.
2. Switch on the ON/OFF switch (
again to continue the programme.
Terminating the programme
(Reset)
Ter minating the pr ogr amme
1. Open the door.
2. Press the START button ` and
hold it down for about 3 seconds.
The value ‹‹h:‹‚m appears in the
display window h.
3. Close the door. The programme
sequence lasts about 1 minute.
The value ‹‹h:‹‹m appears in the
display window h.
4. Open the door.
5. Switch off ON/OFF switch (.
6. Close the door.
Changing the programme
When the START button ` has been
pressed, the programme cannot be
changed. The only way a programme
can be changed is by Cancel
programme (Reset).
2 Cleaning and
maintenance
Cl ea ni ng and mai nt enance
A regular inspection and maintenance
of your machine will help to prevent
faults. This saves time and prevents
problems.
Overall status of the
dishwasher
*The interior of your dishwasher is
predominantly self-cleaning. In order to
remove deposits, your dishwasher
automatically changes the running of
the programme (such as by increasing
the cleaning temperature) at certain
intervals. This will lead to higher
consumption values when running this
programme.
*Depending on the features of your
dishwasher
If you should find deposits in the
interior of the dishwasher in spite of
this, remove these deposits as
follows:
1. Fill the detergent dispenser 9" with
detergent.
2. Select the programme with the
highest temperature.
3. Start the programme without dishes.
:Warning
Health hazard due to detergents
containing chlorine!
Always use chlorine-free detergents.
aus Cleaning and maintenance
30
Notes
■ Only clean the appliance with
special detergents/appliance
cleaners which are suitable for use
with dishwashers.
■ Regularly wipe the door seals using
a damp cloth and a little washing-up
liquid. This will keep the door seal
clean and hygienic.
■ Leave the door open slightly if the
appliance will not be used for a
while. This will prevent an unpleasant
odour from developing.
■ Never clean the dishwasher using a
steam cleaner. The manufacturer
is not liable for any consequential
damage.
■ Wipe the front of the dishwasher and
the control panel regularly using a
damp cloth and a little washing-up
liquid.
■ Do not use sponges with a rough
surface or abrasive detergents.
These could scratch the surface.
■ For dishwashers with a stainless
steel front, avoid using sponge
cloths, or rinse these thoroughly
several times before using them for
the first time. This will prevent
corrosion.
Easyclean Š *
EasyCl ean
Easyclean used in combination with
commercially available machine
cleaning detergent is a suitable
programme for cleaning your
dishwasher. Deposits such as grease
and limescale can cause your
dishwasher to malfunction. In order to
avoid such faults and to reduce the
development of odours, we recommend
cleaning the dishwasher at regular
intervals.
* As soon as the Easyclean display
lights up in the control panel, or you are
advised to do so on the front display,
run the Machine cleaning programme
Easyclean without loading any
tableware. After you have run the
Easyclean the display in the control
panel will go out.
If your dishwasher does not have a
reminder function, follow the instructions
for use on the machine cleaning
detergents.
Cleaning and maintenance aus
31
Notes
■ Remove any coarse soiling in the
interior using a damp cloth.
■ Run the programme without dishes,
and in combination with a machine
cleaning detergent.
■ Use a special machine cleaning
detergent, and not dishwasher
detergent.
■ Observe the safety instructions and
the instructions for use on the
machine cleaning detergent
packaging.
■ * After three washing cycles, the
display in the control panel will go
out automatically, even if you have
not run the Easyclean programme.
* depending on the features of your
dishwasher
Rinse aid
Fill the rinse aid as soon as the refill
indicator @ lights up in the control
panel.
Filters
The filters 1R keep large foreign
objects in the rinsing water away from
the pump. hese foreign objects may
occasionally block the filters.
The filter system consists of
■ a coarse filter
■ a flat fine filter
■ a microfilter
1. After each washing cycle check
the filters for residue.
2. Unscrew filter cylinder as illustrated
and take out filter system.
3. Remove any residue and clean
filters under running water.
4. Re-install filter system in reverse
sequence and ensure that the arrow
marks are opposite each other after
closing the filter system.
aus Fault, what to do?
32
Spray arms
Limescale and contaminants in the
rinsing water may block nozzles and
bearings on the spray arms 1: and
1J.
1. Check outlet nozzles on the spray
arms for blockages.
2. Unscrew the upper spray arm 1:
(1) and remove downwards (2).
3. Remove the lower spray arm 1J
upwards.
4. Clean spray arms under running
water.
5. Re-engage or screw on spray arms.
3 Fault, what to do?
Faul t , wh a t to do?
Experience has shown that you can
rectify most faults which occur in daily
operation yourself. This ensures that the
appliance is quickly available to you
again. In the following overview you can
find possible causes of malfunctions
and helpful information for rectifying
them.
Note: If the appliance stops during
dishwashing or does not start for no
obvious reason, first run the Abort
programme function (Reset)
~ "Operating the appliance"
on page 26.
:Warning
Improper
repairs or use of non-original spare
parts may cause considerable damage
and put the user at considerable risk!
Always have repairs carried out by
technicians. If a component has to be
replaced, always use original spare
parts.
Fault, what to do? aus
33
Waste water pump
Large food remnants or foreign objects
which were not captured by the filters
may block the waste water pump. The
rinsing water will then be above the
filter.
:Warning
Danger of cutting!
Sharp and pointed objects or glass
fragments may block the waste water
pump.
Always carefully remove foreign objects.
Clean the waste water pump as
follows:
1. Disconnect the dishwasher from the
power supply.
2. Take out top basket 12 and bottom
basket 1b.
3. Remove the filters 1R.
4. Scoop out water, use a sponge if
required.
5. Prise off the pump cover (as shown)
using a spoon. Grip the pump cover
by the crosspiece and lift diagonally
inwards (1). Remove cover
completely.
6. Check impeller wheel and remove
any foreign objects.
7. Place pump cover in the original
position (2) and press down until it
engages (3).
8. Install filters.
9. Re-insert baskets.
1
CLICK
aus Fault, what to do?
34
Fault table
Fault Reason Solution
“Check water supply”
display 8 lights up.
Supply hose kinked. Install supply hose without kinks.
Tap turned off. Turn on the tap.
Tap jammed or calcified. Turn on the tap.
Flow rate must be at least 10 l/min. when
water supply is open.
Filter in the water supply blocked. Switch off the appliance and pull out the
mains plug. Turn off the tap. Unscrew
water connection.
Clean filter in the supply hose. Screw
water connection on again. Check for
leaks. Reconnect power supply. Switch on
the appliance.
Fault code “:‹ˆ is lit. Intake opening (on right inside of
appliance) covered by utensils.
Arrange utensils so that the intake
opening is not obstructed.
Fault code “:‚ƒ is lit. Heating element soiled. Clean appliance with dishwasher cleaning
agent.
Fault code “:‚… is lit. Water protection active. Turn off tap.
Call customer service and quote the fault
code.
Fault code “:‚† is lit.
Fault code “:‚‡ is lit. Constant water supply.
Fault code “:ƒƒ is lit. Filters 1R are soiled or
blocked.
Clean filters.~ "Filters" on page 31
Fault code “:ƒ… is lit. Wastewater hose kinked or
blocked.
Install hose without kinks, remove any
residue.
Siphon connection still sealed. Check connection to siphon and open if
required.
Cover on the wastewater pump
loose.
Lock cover correctly.~ "Waste water
pump" on page 33
Fault code “:ƒ† is lit. Wastewater pump blocked or
cover on the wastewater pump is
not locked in position.
Clean pump and lock cover correctly.
~ "Waste water pump" on page 33
Fault, what to do? aus
35
Fault code “:ƒˆ is lit. Mains voltage too low. No appliance fault, have the mains voltage
and electrical installation checked.
A different fault code is
indicated on the digital
display.
(“:‹‚ to “:„‹)
A technical fault has probably
occurred.
Switch off the appliance with the ON/OFF
switch (.After a short time, restart the
appliance.
If the problem recurs, turn off the tap and
pull out the mains plug.
Call customer service and mention the
fault code.
p or • appears on the
digital display h. *
Not a fault! See TurboSpeed 20 min. in the chapter
“Overview of programmes”. *
Refill indicator for rinse aid
@ is lit.
No rinse aid. Refill rinse aid.
Refill indicator for rinse aid
@ is not lit.
Refill indicator switched off. Activation/Deactivation.
There is still enough special rinse
aid available.
Check the filling level, refill indicator.
Water is left in the
appliance at the end of the
programme.
Filter system or area under the
filters 1R is blocked.
Clean filters and area underneath (see
“Waste water pump”).
Programme not finished yet Wait until programme ends or reset (see
“Terminating the programme”).
Fault Reason Solution
aus Fault, what to do?
36
Utensils not dry. Not enough rinse aid in the
dispenser, or none at all.
Refill rinse aid.
Programme without drying was
selected.
Select programme with drying.
Water collecting in depressions
on the utensils and cutlery.
Arrange utensils in a sloping position,
arrange affected utensils as sloping as
possible.
The combined detergent used
has a poor drying performance.
Use different combination detergent with
better drying performance. Use of rinse
aid also improves the drying performance.
Extra dry to increase drying not
activated.
Activate Extra dry. ~ "Operating the
appliance" on page 26
Utensils were removed too early
or drying process had not ended
yet.
Wait until the programme ends, or wait
until 30 minutes after the end of the
programme before removing the utensils.
The eco rinse aid used has a poor
drying performance.
Use a name-brand rinse aid. Eco products
are much less effective.
Plastic utensils not dry. Special properties of plastic. Plastic has a lower heat storage capacity
and therefore dries less well.
Cutlery not dry. Cutlery not arranged properly in
the cutlery basket.
Separate cutlery if possible, prevent
contact points.
Cutlery not arranged properly in
the cutlery drawer.
Arrange cutlery properly and separate if
possible.
Appliance interior wet after
rinse cycle.
No appliance fault. On account of the “Condensation drying”
principle, water droplets are physically
induced and required in the container.The
humidity in the air condenses on the inner
walls of the dishwasher, drains and is
pumped out.
Fault Reason Solution
Fault, what to do? aus
37
Food remnants on the
utensils.
Utensils placed too closely
together, utensils basket
overfilled.
Arrange utensils with adequate clearance
between them ensuring that the spray jets
can reach the surface of the utensils.
Prevent contact points.
Spray arm rotation obstructed. Arrange utensils so that the spray arm can
rotate without obstruction.
Spray arm nozzles are blocked. Clean the spray arm
nozzles.~ "Cleaning and maintenance"
on page 29
Filters 1R dirty. Clean filters. ~ "Cleaning and
maintenance" on page 29
Filters 1R inserted incorrectly
and/or not engaged.
Insert and engage filters correctly.
Rinse programme too weak. Select a more intensive rinse programme.
Utensils precleaned too intensely;
sensors therefore decide on
weak programme sequence.
Stubborn soiling cannot be
completely removed.
Do not prerinse utensils.Remove only
large food remnants.
Tall narrow receptacles in corner
areas are not rinsed adequately.
Do not place tall narrow receptacles too
obliquely and do not place in the corner
area.
Top basket 12 on right and left
not set to same height.
Set top basket to same height using side
levers.
Detergent residue Detergent dispenser cover 9"
blocked by utensils and therefore
does not open fully.
Utensils must not be placed above the
tablet collecting tray 1B.These may
block the lid of the detergent dispenser
and prevent it from opening fully.
~ "Upper basket" on page 15
Do not place utensils or fragrance
dispenser in the tablet collecting tray.
Detergent dispenser cover 9"
blocked by the tablet.
Tablet must be inserted flat and not
upright.
Tablets used in the quick or short
programme.
Dissolving time of the detergent
is not reached in the selected
short programme.
Dissolving time of tablets too long for a
quick or short programme.
Use a detergent powder or select a more
intensive programme.
Washing effect and dissolving
performance are reduced after a
prolonged storage time or
detergent is very lumpy.
Change detergent.
Fault Reason Solution
aus Fault, what to do?
38
Water stains on plastic
parts.
Droplet formation on plastic
surface is physically unavoidable.
After drying, water stains are
visible.
Use a more intensive programme (more
water changes).
Arrange utensils in a sloping position.
Use rinse aid.
Washable or water-soluble
coatings in the container or
on the door.
Detergent substances are
deposited. These coatings cannot
usually be removed with
chemicals (appliance cleaner, ...).
Change detergent brand.
Clean appliance mechanically.
Only for glasses: Initial glass
corrosion – can only apparently
be wiped off.
See “Glass and utensil damage”
~ Page 15.
White, stubborn coatings;
limescale on the utensils,
container or door.
Detergent substances are
deposited. These coatings cannot
usually be removed with
chemicals (appliance cleaner, ...).
Change detergent brand.
Clean appliance mechanically.
Underdosing of detergent. Increase detergent dosage or change
detergent.
Rinse programme selected too
weak.
Select a more intensive rinse programme.
Tea or lipstick residue on
the utensils.
Rinsing temperature too low. Select programme with higher rinsing
temperature.
Too little or unsuitable detergent. Use suitable detergent at correct dosage.
Utensils precleaned too intensely;
sensors therefore decide on
weak programme sequence.
Stubborn soiling cannot be
completely removed.
Do not prerinse utensils.Remove only
large food remnants.
Coloured (blue, yellow,
brown), difficult to remove
to non-removable coatings
in the appliance or on
stainless steel utensils.
Film formation consisting of
ingredients from vegetables (e.g.
cabbage, celery, potatoes,
noodles, ...) or the tap water (e.g.
manganese).
Can be partly removed with machine
cleaner or by mechanical cleaning.
Coatings are harmless.
Film formation caused by metallic
components on silver or
aluminium utensils.
Can be partly removed with machine
cleaner or by mechanical cleaning.
Discolouration of the
plastic parts inside the
appliance.
Plastic parts inside the appliance
may become discoloured during
the service life of the dishwasher.
Discolouration is normal and will not
impair the function of the dishwasher.
Fault Reason Solution
Fault, what to do? aus
39
Plastic parts discoloured. Rinsing temperature too low. Select programme with higher rinsing
temperature.
Utensils precleaned too intensely;
sensors therefore decide on
weak programme sequence.
Stubborn soiling cannot be
completely removed.
Do not prerinse utensils.Remove only
large food remnants.
Removable streaks on
glasses, glasses with
metallic appearance and
cutlery.
Too much rinse aid. Set rinse aid amount to lower setting
setting.
No rinse aid added or setting too
low.
Add rinse aid and check dosage
(recommended Level 4–5).
Detergent residue in the final
rinse. Detergent dispenser cover
blocked by utensils (cover does
not open fully).
Detergent dispenser cover must not be
obstructed by utensils.
Do not place utensils or fragrance
dispenser in the tablet collecting tray.
Utensils precleaned too intensely;
sensors therefore decide on
weak programme sequence.
Stubborn soiling cannot be
completely removed.
Do not prerinse utensils.Remove only
large food remnants.
Initial or existing,
irreversible clouding of
glass.
Glasses not dishwasher-proof,
only suitable for dishwasher.
Use dishwasher-proof glasses.
Avoid long steam phase (standing time
after rinse cycle ends).
Use rinse cycle at lower temperature.
Use detergent with glass protection
component.
Rust spots on the cutlery. Cutlery is not sufficiently
rust-resistant.Knife blades are
frequently more severely
affected.
Use rust-resistant cutlery.
Cutlery will also rust if rusting
parts are rinsed at the same time
(pan handles, damaged utensil
baskets, etc.).
Do not wash rusting parts.
Appliance does not start. The mains fuse has tripped. Check mains fuse.
Power cord not inserted. Ensure that the power cord is plugged all
the way into the back of the appliance and
into the socket. Check that the socket
functions.
The appliance door has not been
shut properly.
Close the door.
Programme starts
automatically.
You did not wait until programme
ended.
Perform reset.
(See “Terminating the programme”)
Fault Reason Solution
aus Fault, what to do?
40
--------
The door is difficult to
open.
Child-proof lock is activated. Deactivate child-proof lock.(See
instructions for use at the back)
Door cannot be closed. Door lock has been activated. Close door with increased force.
Door cannot be closed due to
installation.
Check appliance installation: Door or
attached parts must close without
obstruction.
Cover on the detergent
dispenser cannot be
closed.
Detergent dispenser or cover
guide blocked by sticky detergent
residue
Remove detergent residue.
Detergent residue in the
detergent dispenser or in
the tablet collecting tray.
Spray arms blocked by utensils,
therefore detergent is not rinsed
out.
Ensure that the spray arms can rotate
freely.
The detergent dispenser was
damp when filled.
Pour detergent into the dry detergent
dispenser only.
Appliance stops during the
programme or programme
is interrupted.
Door not closed properly. Close the door.
Do not place utensils or fragrance
dispenser in the tablet collecting
tray.
Top basket presses against the
door and prevents door from
being closed securely.
Check whether rear panel is being
pressed in, e.g. by socket or by hose
holder which has not been removed.
Power and/or water supply
interrupted.
Restore power and/or water supply.
Filling valves making
striking noises.
Depends on domestic installation,
as appliance is not defective. No
effect on appliance function.
No remedial action possible.
Knocking or rattling noise. Spray arm strikes the utensils,
utensils not positioned correctly.
Position utensils so that the spray arms do
not strike the utensils.
If there is a low load, the water
jets strike the washing tank
directly.
Load the appliance with more utensils or
distribute the utensils more evenly in the
dishwasher.
Light utensils move during the
rinse cycle.
Arrange light utensils securely.
Unusual foam formation. Hand washing-up liquid in the
rinse aid dispenser.
Immediately refill rinse aid dispenser with
rinse aid.
Rinse aid spilled. Remove rinse aid with a cloth.
Fault Reason Solution
Customer service aus
41
4 Customer service
Cu s t o mer ser vi c e
If you are unable to rectify the fault,
please contact your customer service.
We will always find an appropriate
solution in order to avoid unnecessary
visits by engineers. Contact information
for your nearest customer service can
be found on the back of these
instructions for use or on the enclosed
customer service list. When calling,
please state the appliance number
(E-Nr. = 1) and the production number
(FD = 2) which can be found on the
rating plate 92 on the appliance door.
Trust the expertise of the
manufacturer. Contact us for
assistance. You can therefore be sure
that the repair is carried out by trained
service technicians who carry original
spare parts for your domestic
appliances.
5 Installation and
connection
Instal lation and c onnect i on
The dishwasher must be connected
correctly, otherwise it will not function
properly. The specifications for the inlet
and outlet as well as the electrical
connected loads must correspond with
the required criteria as
specified in the following paragraphs
or in the installation instructions.
Install the appliance in the correct
sequence:
1. Checking appliance on delivery
2. Installation
3. Drainage connection
4. Drinking water connection
5. Electrical connection
Contents of package
If you have any complaints, contact the
dealer from whom you purchased the
appliance or our customer services.
■ Dishwasher
■ User manual
■ Installation instructions
■ Quick reference guide*
■ Warranty*
■ Installation materials
■ Steam guard plate*
■ Rubber apron*
■ Power cord
* depending on the features of your
dishwasher
Safety instructions
Please follow the safety instructions
under ~ "Installation" on page 6.
)'
(1U
aus Installation and connection
42
Delivery
Your dishwasher has been checked
thoroughly in the factory to ensure that
it is in working order. This may cause
small water stains. These will disappear
after the first wash cycle.
Technical specifications
■ Weight:
up to 60 kg
■ Voltage:
220–240 V, 50 Hz or 60 Hz
■ Connected load:
2000 - 2400 W.
■ Fuse:
10/16 A (UK 13 A).
■ Power input:
off mode (Po)* 0.50 W.
left on mode (Pl)* 0.50 W.
*according to regulations (EU) nos.
1016/2010 and 1059/2010.
Additional functions and settings
may increase the power input.
■ Water pressure:
at least 0.05 MPa (0.5 bar),
maximum 1 MPa (10 bar).
At a higher water pressure:
connect pressure-reducing valve
ahead.
■ Inlet rate:
minimum 10 litres/minute
■ Water temperature:
cold water.
Hot water:
Maximum temperature 60 °C.
■ Capacity:
12–15 place settings (depending on
the features of your dishwasher).
Installation
The required installation dimensions
can be found in the installation
instructions. Level the appliance with
the aid of the height-adjustable feet.
Ensure that the appliance is situated
securely on the floor.
■ A built-under or integrated appliance
which is installed subsequently as a
free-standing appliance must be
secured to prevent it from
overturning, e.g. by screwing it to the
wall or by installing it under a
continuous worktop which is
screwed to adjacent cupboards.
■ The appliance can easily be installed
in a fitted kitchen between wooden
and plastic walls.
Drainage connection
1. The required work sequence can be
found in the installation instructions.
If required, fit a siphon with an
drainage connection.
2. Connect the waste-water hose
to the drainage
connection of the siphon with
the enclosed parts.
Ensure that the drainage hose is not
kinked, crushed or twisted and that
there is no cover
plate in the drainage to prevent
the waste water from flowing out!
Installation and connection aus
43
Drinking water connection
1. Fasten the drinking water connection
to the tap according
to the installation instructions using
the enclosed parts.
Ensure that the drinking water
connection is not kinked, crushed
or twisted.
2. When replacing the appliance,
always use a new water supply
hose.
Water pressure:
at least 0.05 MPa (0.5 bar), maximum 1
MPa (10 bar).
At a higher water pressure:
connect pressure-reducing valve ahead.
Inlet rate:
minimum 10 litres/minute
Water temperature:
cold water.
Hot water:
Maximum temperature 60 °C.
Hot water connection *
Ho t wa t e r connect i on
* depending on the features of your
dishwasher
The dishwasher can be connected to
cold or hot water up to max. 60°C.
Connection to hot water is
recommended if the hot water can be
supplied by energetically favourable
means and from a suitable installation,
e.g. solar heating system with
circulation line. This will save energy
and time. The “Hot water” setting allows
you to adjust your dishwasher optimally
to operate with hot water. It is
recommended to have a water
temperature (temperature of the
incoming water) of at least 40 °C and
no more than 60 °C. It is not
recommended to connect the appliance
to hot water if the water is supplied from
an electric boiler.
Here’s how to change the hot water
setting:
1. Switch on ON/OFF switch (.
2. Press and hold the ‹ button
for 3 seconds.
The value §:‹... and ‘ will appear in
the display window h.
3. Press the ‹ button repeatedly
until the factory setting value ‘:‹‹
appears in the display window h.
4. Adjust the setting using the buttons
+ and - H.
5. Press and hold the ‹ button
for 3 seconds.
The chosen setting has now been
stored in your dishwasher.
aus Installation and connection
44
Electrical connection
■ Connect the appliance to an
alternating current only, ranging from
220 V to 240 V and 50 Hz or 60 Hz
via a correctly installed socket with
protective earth conductor. See
rating plate for required fusing 92.
■ The socket must be near the
appliance and freely accessible
following installation.
If the plug is not freely accessible, an
allpole disconnector with a contact
opening of at least 3 mm must be
fitted on the installation side to
satisfy the relevant safety
instructions.
■ The connection may be modified
by technicians only.
■ A power cord extension may be
purchased from customer service
only.
■ Use only a residual current operated
circuit-breaker which features the
symbol ‚. Only this extension
guarantees compliance with
the currently valid regulations.
■ The appliance features a water
damage protection system. Please
note the system will function only
when the power supply
is connected.
Removal
Also observe
the sequence of worksteps here.
1. Disconnect the appliance from the
power supply.
2. Turn off the tap.
3. Undo the waste water and drinking
water connection.
4. Loosen fastening screws for the
furniture parts.
5. If fitted, remove the base panel.
6. Pull out the appliance, carefully
pulling the hose behind.
Installation and connection aus
45
Transporting
Empty the dishwasher and secure loose
parts.
Drain the appliance according to the
following steps:
1. Turn on water supply.
2. Open the door.
3. Switch on ON/OFF switch (.
4. Select programme with the highest
temperature.
The estimated programme duration
appears in the display window h.
5. Press START button `.
6. Close the door.
Programme sequence starts.
7. Open the door after
approx. 4 minutes.
8. Press and hold the START button
` for about 3 seconds.
The value ‹‹h:‹‚m appears in the
display window h.
9. Close the door.
10. Open the door after approx.
1 minute.
The value ‹‹h:‹‹m appears in the
display window h.
11. Switch off ON/OFF switch (.
12. Turn off water supply, disconnect
supply hose and drain water.
Note: Always transport the dishwasher
upright. This prevents residual water
from getting into the machine’s controls
and causing the programme sequence
to malfunction.
Protection against frost
Pr ot ec t i on agai nst frost (Empt y i ng the appl i anc e)
If the appliance is in a room where
there is a risk of frost (e.g. holiday
home), empty the appliance completely
(see Transportation).
6XEMHFWWRFKDQ
J
HV
$48$6723JXDUDQWHH
GRHVQRWDSSO\WRDSSOLDQFHVZLWKRXW$TXD6WRS
,QDGGLWLRQWRZDUUDQW\FODLPVDJDLQVWWKHVHOOHUEDVHG
RQWKHSXUFKDVHFRQWUDFWDQGLQDGGLWLRQWRRXUDSSOLDQFH
ZDUUDQW\ZHZLOOSD\GDPDJHVXQGHUWKH
IROORZLQJFRQGLWLRQV
,IRXU$TXD6WRSV\VWHPLVGHIHFWLYHDQGFDXVHVZDWHUGDPDJHZHZLOOPDNHJRRGWKH
GDPDJHIRUSULYDWHXVHUV7RHQVXUHZDWHUGDPDJHSURWHFWLRQWKHDSSOLDQFHPXVW
EHFRQQHFWHGWRWKHSRZHUVXSSO\
7KLVOLDELOLW\JXDUDQWHHLVYDOLGIRUWKHVHUYLFHOLIHRIWKHDSSOLDQFH
$SUHUHTXLVLWHIRUWKHZDUUDQW\FODLPLVWKDWWKHDSSOLDQFHKDVEHHQFRUUHFWO\LQVWDOOHGDQG
FRQQHFWHGZLWK$TXD6WRSDFFRUGLQJWRRXULQVWUXFWLRQV7KLVDOVRLQFOXGHVWKHFRUUHFW
LQVWDOODWLRQRIWKH$TXD6WRSH[WHQVLRQRULJLQDODFFHVVRU\
2XUZDUUDQW\GRHVQRWH[WHQGWRGHIHFWLYHIHHGOLQHVRUILWWLQJVXSWRWKH
$TXD6WRSFRQQHFWLRQRQWKHWDS
,I\RXUDSSOLDQFHLVILWWHGZLWK$TXD6WRS\RXFDQOHDYH\RXUDSSOLDQFHXQDWWHQGHGGXULQJ
RSHUDWLRQDQGOHDYHWKHWDSWXUQHGRQDIWHUZDUGV7KHWDSVKRXOGRQO\EHWXUQHGRIILI\RX
DUHDEVHQWIURPKRPHIRUDSURORQJHGSHULRGHJVHYHUDOZHHNVKROLGD\
.
.
.
7RERRNDQHQJLQHHUYLVLWDQGSURGXFWDGYLFH
*%
,(
3OHDVHILQGWKHFRQWDFWGDWDRIDOOFRXQWULHVLQWKHHQFORVHG
FXVWRPHUVHUYLFHOLVW
&DOOVIURPD%7ODQGOLQHZLOOEHFKDUJHGDWXSWRSHQFH
SHUPLQXWH$FDOOVHWXSIUHHRIXSWRSHQFHPD\DSSO\
½SHUPLQXWHDWSHDN2IISHDN½SHUPLQXWH
*9001354169*
9001354169
(9801) 642 MW
