For WRX735SDHW.

25 cu. ft. French Door Refrigerator
WRX735SDH
Key Features & Benefits
Capacity
Total Capacity 25 cu. ft.
Refrigerator Capacity 18 cu. ft.
Freezer Capacity 7 cu. ft.
General Features & Properties
Adjustable Gallon Door Bins
Fingerprint Resistant
Measured Fill
LED Interior Lighting
Adaptive Defrost
Accu-Chill
Temperature Management
System
ENERGY STAR
®
Certied
Spillproof Glass Shelves
Exterior Temperature Controls
Electrical Details
Amps 20
Volts 115
Certifications
ENERGY STAR
®
Certied Yes
Technical Details
Refrigerator Type French Door
Number of Doors 4
Number of Interior
Refrigerator Shelves
5
Number of Refrigerator
Door Bins
3 Adjustable,
3 Fixed
Number of Interior
Freezer Shelves
1 Plastic,
1 Wire
Number of Freezer Door Bins N/A
Lighting Type LED
Ice Maker
Factory
Installed
Ice Maker Location Refrigerator
Dispenser Type
Exterior Ice
and Water
Dimensions
Product Dimensions
(H x W x D)
70-1/8" x
35-5/8" x
34-5/8"
Depth with Door Open 90° 48"
Cutout Dimensions
Allow extra
1/2" on sides
and top
Allow extra 1"
on rear
Reference Material
Dimension Guide
Use & Care Guide
Energy Guide
Warranty
Fingerprint-Resistant Stainless
WRX735SDHZ
Also available in:
White
WRX735SDHW
Black
WRX735SDHB
Fingerprint-
Resistant Black
Stainless
WRX735SDHV
Refrigerated Exterior Drawer
Keep items in easy reach with the refrigerated
exterior drawer.
Tap Touch Controls
Clean these controls as easily
as you use them.
Exterior Ice and Water Dispenser
with EveryDrop
®
Filtration
Access fresh ltered water and ice without
ever opening the refrigerator door.
NOTE: Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specications subject to
change without notice.
