Specifications
Number of input
channels
Mono (MIC/LINE) 2
Stereo (TRS) 1
Input and output channels
Number of output
channels
Stereo (PHONES) 2
Type XLR/TRS combo jacks
(XLR: 2 HOT, TRS: TIP HOT)
Input gain −∞ – +58 dB / −∞ – +50 dB (when
set to GUITAR)
Input impedance XLR: 2.7 kΩ
TRS: 18 kΩ / 330 kΩ (when set to
GUITAR)
Maximum input level XLR: +6 dBu
TRS: +22 dBu / +8.5 dBu (when set
to GUITAR)
Input 1–2
Phantom +48 V
Type TRS phone jacks (impedance
balanced)
Maximum output
level
+10 dBu (at 0 dBFS)
OUTPUT A
(standard phone jacks)
Output impedance 100 Ω
Type 3.5mm stereo mini jacks
30 mW + 30 mW (32 Ω load)
OUTPUT A–B
(headphone jacks)
Output impedance 10 Ω
USB USB Type-C (audio interface
function)
• Use a USB cable that supports
data transfer. USB bus power is
supported.
Connectors
DC 5V USB Type-C (for power supply)
Frequency response 44.1 kHz: ±1 dB (20 Hz – 20 kHz)
96 kHz: ±1.5 dB (20 Hz – 40 kHz)
Equivalent input noise –120 dBu or less (IHF-A) at
+58dB/150Ω input
Input and output
channels
Recording: 2 channels
Playback: 4 channels
Audio interface
Sampling frequencies 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz
36
