Model: CZK-5642 | Brand: ZGZUXO
Overview
The ZGZUXO Tire Inflator is a portable air compressor designed for inflating car tires, motorcycle tires, bicycle tires, balls, and other inflatables. It features a cordless, battery-powered design with a 12V DC backup power option, a digital pressure gauge, and an integrated LED light.
The unit is compact and lightweight (0.99 lbs / 450 g) with dimensions of 6.3 x 5 x 16.1 cm, making it easy to store in a vehicle or carry in a bag.
Features
Dual Power Source
The inflator can be powered in two ways:
- Built-in Rechargeable Battery: For cordless, portable operation.
- 12V DC Backup: Connect to a vehicle's cigarette lighter socket using the included DC charger for continuous power when the battery is low.
Digital Pressure Gauge & Auto-Stop
The dual LCD display shows both the real-time pressure and the preset target pressure simultaneously. The unit supports four pressure units: PSI, Bar, kPa, and kg/cm².
- Preset Modes: Car, Motorcycle, Bicycle, Ball, and Custom mode.
- Custom Mode: Allows you to set any target pressure between 3 and 150 PSI.
- Auto-Stop: The compressor automatically shuts off when the preset pressure is reached, preventing over-inflation.
LED Flashlight
The unit includes a built-in LED flashlight with multiple modes (illumination and strobe) for use in low-light conditions or emergency situations.
Additional Functions
- USB Power Bank: Can charge mobile phones or other digital devices via a USB port.
- Included Accessories: 4 extra nozzles (air nozzle, long tapered nozzle, Presta valve needle, ball air nozzle), 40 cm air hose, Type-C charging cable, DC charger, storage bag, and user manual.
Use Guide
Before First Use
- Fully charge the built-in battery using the provided Type-C charging cable. The charging indicator will show the status.
- Familiarize yourself with the control buttons and the dual LCD display.
- Select the appropriate nozzle for your application and attach it securely to the air hose.
Step-by-Step Inflation
Using the LED Light
Press the light button to cycle through modes: Constant On → Strobe → Off.
Using as a Power Bank
Connect your device to the USB output port on the inflator using a standard USB cable. The unit will begin charging automatically.
Specifications
| Brand | ZGZUXO |
| Model | CZK-5642 |
| Voltage | 12 Volts (DC) |
| Power Source | Battery Powered & Corded Electric (12V DC) |
| Maximum Pressure | 150 PSI (2.5 Bars) |
| Hose Length | 14.96 inches (40 cm) |
| Item Weight | 0.99 Pounds (450 g) |
| Dimensions (L x W x H) | 6.3 x 5 x 16.1 cm |
| Included Components | 4 Extra Nozzles, 40cm Air Hose, Charging Cable, DC Charger, User Manual, Storage Bag |
| Special Features | Automatic Shut-Off, Battery & 12V DC Dual Power, Cordless, LED Light, Portable |
Troubleshooting
- Unit does not power on: Ensure the battery is charged. If the battery is depleted, connect the 12V DC adapter to a vehicle power outlet.
- Inflation is slow or stops prematurely: Check for air leaks at the nozzle connection. Ensure the preset pressure is set correctly. The unit may have reached the preset value and auto-stopped.
- Display shows error or no reading: Turn the unit off and on again. If the problem persists, contact ZGZUXO support.
- LED light does not work: Ensure the unit is powered on. Press the light button to cycle through modes.
Safety & Maintenance
- Do not exceed the maximum pressure rating of the inflatable object.
- Do not immerse the unit in water or use it in wet conditions.
- Store the inflator in a cool, dry place when not in use.
- Regularly inspect the air hose and nozzles for damage.
- Use only the provided charging cable and DC adapter.
Warranty & Support
For warranty information and customer support, please contact the manufacturer:
- Manufacturer: ZGZUXO
- Contact: Visit the ZGZUXO store on Amazon for support options.
Note: No specific warranty period or contact details were provided in the product listing. Please refer to the packaging or contact the seller for detailed warranty terms.
